— 117 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
JR2 1-216-295-91 METAL CHIP 0 5% 1/10W
(N555AV:AEP,UK)
JR3 1-216-295-91 METAL CHIP 0 5% 1/10W
(N555AV:IT,G)
JR6 1-216-295-91 METAL CHIP 0 5% 1/10W
JR7 1-216-295-91 METAL CHIP 0 5% 1/10W
(N555AV:IT,G)
JR8 1-216-295-91 METAL CHIP 0 5% 1/10W
(N555AV:AEP,UK)
JR9 1-216-295-91 METAL CHIP 0 5% 1/10W
(N555AV:AEP,UK)
JR45 1-216-295-91 METAL CHIP 0 5% 1/10W
JR46 1-216-296-91 METAL CHIP 0 5% 1/8W
JR47 1-216-295-91 METAL CHIP 0 5% 1/10W
JR48 1-216-295-91 METAL CHIP 0 5% 1/10W
JR49 1-216-296-91 METAL CHIP 0 5% 1/8W
JR51 1-216-295-91 METAL CHIP 0 5% 1/10W
(N555AV:AEP,UK)
JR52 1-216-295-91 METAL CHIP 0 5% 1/10W
JR53 1-216-296-91 METAL CHIP 0 5% 1/8W
(N555AV:AEP,UK)
JR54 1-216-295-91 METAL CHIP 0 5% 1/10W
< JUMPER RESISTOR >
JW4 1-249-413-11 CARBON 470 5% 1/4W
JW5 1-249-413-11 CARBON 470 5% 1/4W
< COIL >
L2 1-414-142-11 MICRO INDUCTOR 1uH
L3 1-410-521-11 MICRO INDUCTOR 100uH
L4 1-410-515-11 INDUCTOR 33uH
L41 1-407-500-00 MICRO INDUCTOR 4.7mH (N555AV:AEP,UK)
L41 1-410-119-11 MICRO INDUCTOR (EL TYPE) 1mH (N555AV:IT,G)
< FILTER >
LPF41 1-239-845-11 FILTER, LOW PASS
LPF42 1-239-845-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-201-27 TRANSISTOR 2SC2715Y
Q2 8-729-201-27 TRANSISTOR 2SC2715Y
Q3 8-729-201-27 TRANSISTOR 2SC2715Y
Q4 8-729-201-27 TRANSISTOR 2SC2715Y
Q5 8-729-424-08 TRANSISTOR UN2111
Q9 8-729-216-22 TRANSISTOR 2SA1162-G (N555AV:AEP,UK)
Q11 8-729-421-22 TRANSISTOR UN2211 (N555AV:AEP,UK)
Q12 8-729-421-22 TRANSISTOR UN2211 (N555AV:AEP,UK)
Q13 8-729-421-22 TRANSISTOR UN2211 (N555AV:AEP,UK)
Q14 8-729-421-22 TRANSISTOR UN2211 (N555AV:AEP,UK)
< RESISTOR >
R1 1-249-401-11 CARBON 47 5% 1/4W F
R2 1-216-037-00 METAL CHIP 330 5% 1/10W
R3 1-216-037-00 METAL CHIP 330 5% 1/10W
R5 1-216-037-00 METAL CHIP 330 5% 1/10W
R6 1-216-081-00 METAL CHIP 22K 5% 1/10W
R7 1-216-037-00 METAL CHIP 330 5% 1/10W
R8 1-216-037-00 METAL CHIP 330 5% 1/10W
R9 1-216-081-00 METAL CHIP 22K 5% 1/10W
R10 1-216-037-00 METAL CHIP 330 5% 1/10W
R11 1-216-081-00 METAL CHIP 22K 5% 1/10W
R12 1-216-037-00 METAL CHIP 330 5% 1/10W
R13 1-216-037-00 METAL CHIP 330 5% 1/10W
R14 1-216-081-00 METAL CHIP 22K 5% 1/10W
R18 1-216-073-00 METAL CHIP 10K 5% 1/10W
(N555AV:AEP,UK)
R19 1-216-073-00 METAL CHIP 10K 5% 1/10W
(N555AV:AEP,UK)
R21 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R22 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R23 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R24 1-216-025-91 METAL CHIP 100 5% 1/10W
R25 1-249-417-11 CARBON 1K 5% 1/4W F
R26 1-249-437-11 CARBON 47K 5% 1/4W
R27 1-249-429-11 CARBON 10K 5% 1/4W
R28 1-249-417-11 CARBON 1K 5% 1/4W F
R29 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R30 1-216-186-00 METAL CHIP 330 5% 1/8W
R31 1-216-025-91 METAL CHIP 100 5% 1/10W
R32 1-249-425-11 CARBON 4.7K 5% 1/4W F
R33 1-249-425-11 CARBON 4.7K 5% 1/4W F
R34 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R35 1-216-214-00 METAL CHIP 4.7K 5% 1/8W
R36 1-216-025-11 METAL CHIP 100 5% 1/10W
R37 1-216-073-00 METAL CHIP 10K 5% 1/10W
R38 1-216-089-11 METAL CHIP 47K 5% 1/10W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R42 1-216-073-00 METAL CHIP 10K 5% 1/10W
R43 1-216-042-00 METAL CHIP 510 5% 1/10W
R44 1-216-013-00 METAL CHIP 33 5% 1/10W
R45 1-249-423-11 CARBON 3.3K 5% 1/4W F
R46 1-216-073-00 METAL CHIP 10K 5% 1/10W
R47 1-216-097-91 METAL CHIP 100K 5% 1/10W
R48 1-249-417-11 CARBON 1K 5% 1/4W F
R49 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R51 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R53 1-249-429-11 CARBON 10K 5% 1/4W
R55 1-216-162-00 METAL CHIP 33 5% 1/8W
R56 1-249-393-11 CARBON 10 5% 1/4W F
R91 1-216-295-91 METAL CHIP 0 5% 1/10W
(N555AV:AEP,UK)
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
(N555AV:AEP,UK)
