Sony HCD-D670AV - Compact Disk Deck Receiver - Page 76

— 118 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R99 1-249-399-11 CARBON 33 5% 1/4W F
< VARIABLE RESISTOR >
RV41 1-238-601-11 RES, ADJ, CARBON 22K
RV42 1-238-600-11 RES, ADJ, CARBON 10K
< TERMINAL >
TM1 1-537-488-11 TERMINAL BOARD (ANT) (ANTENNA)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-760-220-11 FILTER, CERAMIC (10.7MHz)
X42 1-527-981-00 FILTER, CERAMIC (450KHz)
X43 1-577-075-11 OSCILLATOR, CERAMIC (456KHz)
**************************************************************
* 1-659-218-11 TRANS BOARD (D670AV)
********************
* 1-660-805-11 TRANS BOARD (N555AV)
********************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C1600 1-164-159-21 CERAMIC 0.1uF 50V
C1601 1-164-159-21 CERAMIC 0.1uF 50V (N555AV)
< CONNECTOR >
* CN1601 1-535-139-00 BASE POST 14MM (10MMPITCH) 2P
(N555AV:E,PX,MX)
CN1601 1-774-108-11 PIN, CONNECTOR (PC BOARD)
(D670AV/N555AV:AEP,UK,G,IT,AUS,AR)
CN1604 1-564-524-11 PLUG, CONNECTOR 9P
< FUSE >
! F1601 1-532-506-31 FUSE, TIME-LAG (6.3A 250V)(N555AV)
! F1602 1-532-506-31 FUSE, TIME-LAG (6.3A 250V)(N555AV)
! F1603 1-532-504-31 FUSE, TIME-LAG (4A 250V)(N555AV:E,PX,MX,AR)
! F1603 1-533-420-11 FUSE, GLASS CYLINDRICAL (DIA.5)(5A 125V)
(D670AV:US)
! F1603 1-533-419-11 FUSE, GLASS CYLINDRICAL (DIA.5)(4A 125V)
(D670AV:CND)
! F1604 1-532-465-31 FUSE, TIME-LAG (3.15A 250V)
(N555AV:AEP,UK,G,IT,E,AUS,PX,AR)
< RESISTOR >
! R1600 1-202-725-00 SOLID 3.3M 10% 1/2W
(D670AV)
! R1601 1-219-124-81 FUSIBLE 0.68 5% 1/4W F
! R1602 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R1603 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
< TRANSFORMER >
! T1601 1-429-338-11 TRANSFORMER, POWER (N555AV:AEP,UK,G,IT)
! T1601 1-429-339-11 TRANSFORMER, POWER (D670AV)
! T1601 1-429-340-11 TRANSFORMER, POWER
(N555AV:E,AUS,PX,MX,AR)
< SWITCH >
! VS1601 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)(N555AV:E,PX,AR)
**************************************************************
MISCELLANEOUS
*************
3 1-751-688-11 WIRE (FLAT TYPE)(13 CORE)
3 1-773-011-11 WIRE (FLAT TYPE)(15 CORE)(N555AV:AEP,UK)
* 57 1-659-414-11 MIC BOARD (N555AV:E,AUS,PX,MX,AR)
* 152 1-659-218-11 TRANS BOARD (D670AV)
* 152 1-660-805-11 TRANS BOARD (D555AV)
153 1-751-688-11 WIRE (FLAT TYPE)(13 CORE)
156 1-769-069-11 WIRE (FLAT TYPE)(16 CORE)(N555AV:AEP)
156 1-773-011-11 WIRE (FLAT TYPE)(15 CORE)(N555AV:AEP,UK)
157 1-777-046-11 WIRE (FLAT TYPE)(19 CORE)
158 1-765-338-11 WIRE (FLAT TYPE)(21 CORE)
159 1-769-949-11 WIRE (FLAT TYPE)(11 CORE)
160 1-590-578-11 WIRE (FLAT TYPE)(19 CORE)
160 1-773-153-11 WIRE (FLAT TYPE)(21 CORE)
160 1-773-219-11 WIRE (FLAT TYPE)(25 CORE)
162 1-569-007-11 ADAPTER, CONVERSION 2P (N555AV:PX)
162 1-569-008-11 ADAPTER, CONVERSION 2P (N555AV:AR)
162 1-569-008-21 ADAPTER, CONVERSION 2P (N555AV:AR)
* 357 1-452-538-11 MAGNET
! 401 8-848-387-01 OPTICAL PICK-UP KSS-213BA/S-N
402 1-769-069-11 WIRE (FLAT TYPE)(16 CORE)
! CNP1601 1-558-943-51 CORD, POWER (N555AV:E,PX,MX)
! CNP1601 1-575-042-21 CORD, POWER (D670AV)
! CNP1601 1-575-651-21 CORD, POWER (N555AV:AEP,G,IT,AR)
! CNP1601 1-696-845-11 CORD, POWER (N555AV:AUS)
! CNP1601 1-751-522-11 CORD, POWER (N555AV:UK)
! F1601 1-532-506-31 FUSE, TIME LAG (6.3A, 250V)(N555AV)
! F1602 1-532-506-31 FUSE, TIME LAG (6.3A, 250V)(N555AV)
! F1603 1-532-504-31 FUSE, TIME LAG (4A, 250V)
(N555AV:E,PX,MX,AR)
! F1603 1-533-420-11 FUSE, GLASS CYLINDRICAL (DIA.5)(5A, 125V)
(D670AV:US)
! F1603 1-533-419-11 FUSE, GLASS CYLINDRICAL (DIA.5)(4A, 125V)
(D670AV:CND)
! F1604 1-532-465-31 FUSE, TIME-LAG (3.15A 250V)
(N555AV;AEP,UK,G,IT,E,AUS,PX,AR)
FL501 1-517-490-21 INDICATOR TUBE, FLUORESCENT
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE)
M1 X-3371-223-1 MOTOR ASSY (CAPSTAN)
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
TRANS
TCB
