— 119 —
Ref. No. Part No. Description Remark
M2 A-2004-410-A MOTOR ASSY (TRIGGER)
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M201 A-4660-977-A MOTOR ASSY (TABLE)
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
! T1601 1-429-338-11 TRANSFORMER, POWER (N555AV:AEP,UK,G,IT)
! T1601 1-429-339-11 TRANSFORMER, POWER (D670AV)
! T1601 1-429-340-11 TRANSFORMER, POWER
(N555AV:E,AUS,PX,MX,AR)
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-473-608-11 REMOTE COMMANDER (RM-SE1AV)
* 4-979-431-01 CUSHION (BOTTOM)
* 4-980-140-01 CUSHION (UPPER)
4-981-643-01 COVER, BATTERY (for RM-SE1AV)
**************************************************************
*************
HARDWARE LIST
*************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-871-01 SCREW +BVTT 3X6 (S) (D670AV)
#3 7-682-560-04 SCREW +BVTT 4X6 (S)(N555AV)
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#5 7-621-770-67 SCREW +BVTT 2.6X6 (S)
#6 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#7 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#8 7-621-775-10 SCREW +B 2.6X4
#9 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#10 7-623-921-01 RING, RETAINING, CAPSTAN
#11 7-621-775-00 SCREW +B 2.6X3
#12 7-621-255-15 SCREW +P 2X3
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
