DIAGRAMS
7-1. CIRCUIT BOARDS LOCATION
Note:pA is including in AUDIO board.
pB is including in PANEL board.
POWER board
AUDIO board
(including
p A)
LEAF SWITCH board
p A
MOTOR board
TRANS board
SURROUND board
MOTOR (TURN) board
CONNECTOR board
SENSOR board
BD board
MOTOR (SLIDE) board
CD SW board
PANEL board
(including
p B)
HP/MIC board
TC SW board
MAIN board
p B
ENCAPSULATED COMPONENT
(Except AEP, UK, G, EE, CIS)
TCB board (AEP, UK, G, EE, CIS)
•Abbreviation
CND:Canadian model
G :German model
EE :East European model
DECO board
(Exept D90AV/RX100AV: US, CND)
