Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
Q407 8-729-900-80 TRANSISTOR DTC114ES
Q408 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q409 8-729-900-80 TRANSISTOR DTC114ES
Q601 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q602 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q904 8-729-040-20 TRANSISTOR RT1P137L-TP
Q905 8-729-900-36 TRANSISTOR DTC124ES
Q906 8-729-040-20 TRANSISTOR RT1P137L-TP
Q907 8-729-900-63 TRANSISTOR DTA124ES
Q912 8-729-900-36 TRANSISTOR DTC124ES
Q941 8-729-118-01 TRANSISTOR 2SB1116
Q951 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q961 8-729-111-29 TRANSISTOR 2SD1616A-K
Q962 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R121 1-249-424-11 CARBON 3.9K 5% 1/4W F
R122 1-247-887-00 CARBON 220K 5% 1/4W
R123 1-249-417-11 CARBON 1K 5% 1/4W F
R124 1-249-441-11 CARBON 100K 5% 1/4W
R125 1-249-421-11 CARBON 2.2K 5% 1/4W F
R126 1-249-441-11 CARBON 100K 5% 1/4W
R127 1-249-421-11 CARBON 2.2K 5% 1/4W F
R128 1-249-426-11 CARBON 5.6K 5% 1/4W
R129 1-249-429-11 CARBON 10K 5% 1/4W
R130 1-249-441-11 CARBON 100K 5% 1/4W
R131 1-249-437-11 CARBON 47K 5% 1/4W
(GR10AV/RX100AV)
R132 1-247-843-11 CARBON 3.3K 5% 1/4W
(GR10AV/RX100AV)
R133 1-249-429-11 CARBON 10K 5% 1/4W
(GR10AV/RX100AV)
R134 1-249-417-11 CARBON 1K 5% 1/4W F
(GR10AV/RX100AV)
R135 1-249-441-11 CARBON 100K 5% 1/4W
(GR10AV/RX100AV)
R136 1-249-417-11 CARBON 1K 5% 1/4W F
(GR10AV/RX100AV)
R137 1-249-429-11 CARBON 10K 5% 1/4W
(GR10AV/RX100AV)
R138 1-249-441-11 CARBON 100K 5% 1/4W
(GR10AV/RX100AV)
R171 1-249-424-11 CARBON 3.9K 5% 1/4W F
R172 1-247-887-00 CARBON 220K 5% 1/4W
R173 1-249-417-11 CARBON 1K 5% 1/4W F
R174 1-249-441-11 CARBON 100K 5% 1/4W
R178 1-249-426-11 CARBON 5.6K 5% 1/4W
R179 1-249-429-11 CARBON 10K 5% 1/4W
R201 1-249-425-11 CARBON 4.7K 5% 1/4W F
R202 1-249-425-11 CARBON 4.7K 5% 1/4W F
R203 1-249-437-11 CARBON 47K 5% 1/4W
R204 1-249-437-11 CARBON 47K 5% 1/4W
R205 1-249-441-11 CARBON 100K 5% 1/4W
R206 1-247-903-00 CARBON 1M 5% 1/4W
R207 1-247-887-00 CARBON 220K 5% 1/4W
R208 1-247-863-91 CARBON 22K 5% 1/4W
R209 1-249-419-11 CARBON 1.5K 5% 1/4W F
R210 1-249-429-11 CARBON 10K 5% 1/4W
R211 1-249-421-11 CARBON 2.2K 5% 1/4W F
R212 1-249-441-11 CARBON 100K 5% 1/4W
R213 1-249-429-11 CARBON 10K 5% 1/4W
R214 1-249-437-11 CARBON 47K 5% 1/4W
R215 1-249-441-11 CARBON 100K 5% 1/4W
R217 1-249-431-11 CARBON 15K 5% 1/4W
R222 1-247-903-00 CARBON 1M 5% 1/4W
R223 1-247-903-00 CARBON 1M 5% 1/4W
R230 1-247-863-91 CARBON 22K 5% 1/4W
R231 1-247-863-91 CARBON 22K 5% 1/4W
R232 1-247-856-00 CARBON 11K 5% 1/4W
R240 1-249-429-11 CARBON 10K 5% 1/4W
R241 1-249-429-11 CARBON 10K 5% 1/4W
R242 1-249-429-11 CARBON 10K 5% 1/4W
R243 1-249-417-11 CARBON 1K 5% 1/4W F
R244 1-249-417-11 CARBON 1K 5% 1/4W F
R245 1-249-417-11 CARBON 1K 5% 1/4W F
R251 1-249-425-11 CARBON 4.7K 5% 1/4W F
R252 1-249-425-11 CARBON 4.7K 5% 1/4W F
R253 1-249-437-11 CARBON 47K 5% 1/4W
R254 1-249-437-11 CARBON 47K 5% 1/4W
R255 1-249-441-11 CARBON 100K 5% 1/4W
R256 1-247-903-00 CARBON 1M 5% 1/4W
R257 1-247-887-00 CARBON 220K 5% 1/4W
R258 1-247-863-91 CARBON 22K 5% 1/4W
R259 1-249-419-11 CARBON 1.5K 5% 1/4W F
R260 1-249-429-11 CARBON 10K 5% 1/4W
R261 1-249-421-11 CARBON 2.2K 5% 1/4W F
R262 1-249-441-11 CARBON 100K 5% 1/4W
R263 1-249-429-11 CARBON 10K 5% 1/4W
R264 1-249-437-11 CARBON 47K 5% 1/4W
R265 1-249-441-11 CARBON 100K 5% 1/4W
R267 1-249-431-11 CARBON 15K 5% 1/4W
R273 1-247-903-00 CARBON 1M 5% 1/4W
R301 1-249-435-11 CARBON 33K 5% 1/4W
R304 1-249-426-11 CARBON 5.6K 5% 1/4W
R305 1-249-417-11 CARBON 1K 5% 1/4W F
R306 1-247-840-00 CARBON 2.4K 5% 1/4W
R307 1-247-863-91 CARBON 22K 5% 1/4W
R308 1-249-421-11 CARBON 2.2K 5% 1/4W F
R309 1-249-428-11 CARBON 8.2K 5% 1/4W F
R351 1-247-863-91 CARBON 22K 5% 1/4W
R354 1-249-426-11 CARBON 5.6K 5% 1/4W
R355 1-249-417-11 CARBON 1K 5% 1/4W F
R356 1-247-840-00 CARBON 2.4K 5% 1/4W
R357 1-247-863-91 CARBON 22K 5% 1/4W
R358 1-249-421-11 CARBON 2.2K 5% 1/4W F
R359 1-249-428-11 CARBON 8.2K 5% 1/4W F
R401 1-249-425-11 CARBON 4.7K 5% 1/4W F
R402 1-249-425-11 CARBON 4.7K 5% 1/4W F
R403 1-249-425-11 CARBON 4.7K 5% 1/4W F
R404 1-249-417-11 CARBON 1K 5% 1/4W F
R405 1-249-437-11 CARBON 47K 5% 1/4W
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R408 1-249-437-11 CARBON 47K 5% 1/4W
R410 1-249-430-11 CARBON 12K 5% 1/4W
R411 1-249-426-11 CARBON 5.6K 5% 1/4W
