Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C901 1-126-937-11 ELECT 4700uF 20% 16V
C902 1-126-768-11 ELECT 2200uF 20% 16V
C903 1-164-159-21 CERAMIC 0.1uF 50V
C904 1-164-159-21 CERAMIC 0.1uF 50V
C908 1-126-933-11 ELECT 100uF 20% 10V
C909 1-126-933-11 ELECT 100uF 20% 10V
C910 1-126-964-11 ELECT 10uF 20% 50V
C911 1-126-768-11 ELECT 2200uF 20% 16V
C913 1-126-964-11 ELECT 10uF 20% 50V
C914 1-126-767-11 ELECT 1000uF 20% 16V
C915 1-126-964-11 ELECT 10uF 20% 50V
C916 1-126-916-11 ELECT 1000uF 20% 6.3V
C917 1-126-925-11 ELECT 470uF 20% 10V
C918 1-126-933-11 ELECT 100uF 20% 10V
C919 1-126-964-11 ELECT 10uF 20% 50V
C920 1-126-933-11 ELECT 100uF 20% 10V
C943 1-162-294-31 CERAMIC 0.001uF 10% 50V
C944 1-126-947-11 ELECT 47uF 20% 35V
C951 1-126-967-11 ELECT 47uF 20% 10V
C952 1-136-165-00 FILM 0.1uF 5% 50V
C953 1-136-165-00 FILM 0.1uF 5% 50V
C961 1-162-306-11 CERAMIC 0.01uF 20% 16V
C991 1-162-306-11 CERAMIC 0.01uF 20% 16V
C992 1-162-306-11 CERAMIC 0.01uF 20% 16V
(GR10AV/RX100AV)
< CONNECTOR >
CN401 1-568-838-11 SOCKET, CONNECTOR 21P
* CN402 1-568-830-11 SOCKET, CONNECTOR 11P
* CN403 1-568-449-11 HOUSING, CONNECTOR (PC BOARD) 3P
* CN701 1-568-836-11 SOCKET, CONNECTOR 17P
* CN801 1-568-862-11 SOCKET, CONNECTOR 19P
* CN820 1-568-947-11 PIN, CONNECTOR 9P
* CN830 1-568-946-11 PIN, CONNECTOR 8P
* CN851 1-568-832-11 SOCKET, CONNECTOR 13P
(D90AV/GR10AV:E2,TH,AUS/RX100AV:US,CND)
* CN851 1-568-834-11 SOCKET, CONNECTOR 15P
(GR10AV:E3,EA,MY,SP,JE,HK,IA/RX100AV:AEP,UK,G,EE,CIS)
* CN901 1-770-734-11 CONNECTOR, BOARD TO BOARD 20P
* CN961 1-564-518-11 PLUG, CONNECTOR 3P
< DIODE >
D702 8-719-987-63 DIODE 1N4148M
D772 8-719-987-63 DIODE 1N4148M
D801 8-719-987-63 DIODE 1N4148M
D802 8-719-987-63 DIODE 1N4148M
D901 8-719-025-03 DIODE RBA-402-SL
D902 8-719-200-82 DIODE 11ES2
D904 8-719-987-63 DIODE 1N4148M
D905 8-719-200-82 DIODE 11ES2
D906 8-719-200-82 DIODE 11ES2
D907 8-719-987-63 DIODE 1N4148M
D908 8-719-200-82 DIODE 11ES2
D941 8-719-002-60 DIODE UZL-33L
D942 8-719-010-43 DIODE UZ-5.6BSC
D951 8-719-987-63 DIODE 1N4148M
D952 8-719-987-63 DIODE 1N4148M
D953 8-719-987-63 DIODE 1N4148M
D954 8-719-987-63 DIODE 1N4148M
< GROUND TERMINAL >
* EPT901 1-537-738-21 TERMINAL, EARTH
< FERRITE BEAD >
FB801 1-412-473-21 INDUCTOR 0UH
< IC >
IC102 8-759-000-48 IC MC14052BCP
IC105 8-759-634-51 IC M5218AP (GR10AV/RX100AV)
IC201 8-759-331-39 IC M62427FP
IC401 8-759-363-21 IC HA12203NT
IC402 8-759-822-09 IC LB1641
IC601 8-759-442-96 IC LA2786
IC602 8-759-442-97 IC LV1016
IC603 8-759-634-51 IC M5218AP
IC604 8-759-281-42 IC TC9210P
IC701 8-759-468-69 IC uPD780018YGF-017-3BA
IC841 8-749-923-04 IC TOTX178 (CD DIGITAL OUT OPTICAL)
IC861 8-759-634-51 IC M5218AP
IC901 8-759-288-53 IC LA5617
IC902 8-759-231-53 IC TA7805S
IC903 8-759-604-86 IC M5F7807L
IC904 8-759-231-58 IC TA7812S
IC905 8-759-604-38 IC M5F78M10L
IC951 8-759-635-63 IC M51943BSL
< JACK >
J101 1-695-188-31 JACK, PIN 4P (VIDEO/MD (AUDIO))
J102 1-774-785-11 JACK, PIN 1P (SUPER WOOFER)
(GR10AV/RX100AV)
< COIL >
L601 1-410-509-11 INDUCTOR 10uH
L602 1-410-509-11 INDUCTOR 10uH
L604 1-410-509-11 INDUCTOR 10uH
L769 1-410-521-11 INDUCTOR 100uH
L770 1-410-521-11 INDUCTOR 100uH
L772 1-410-521-11 INDUCTOR 100uH
L841 1-410-521-11 INDUCTOR 100uH
L851 1-410-521-11 INDUCTOR 100uH (RX100AV:AEP,UK,G)
L861 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q120 8-729-422-57 TRANSISTOR UN4111
Q121 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q122 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q123 8-729-422-57 TRANSISTOR UN4111
Q124 8-729-900-36 TRANSISTOR DTC124ES
Q130 8-729-141-26 TRANSISTOR 2SC3622A-LK
(GR10AV/RX100AV)
Q201 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q202 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q251 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q252 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q253 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q254 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q403 8-729-801-93 TRANSISTOR 2SD1387
Q406 8-729-900-80 TRANSISTOR DTC114ES
