Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C7 1-101-004-00 CERAMIC 0.01uF 50V
C8 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C9 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C10 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C16 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C19 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
C21 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C22 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C23 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C24 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C26 1-126-967-11 ELECT 47uF 20% 16V
C28 1-126-967-11 ELECT 47uF 20% 16V
C29 1-162-306-11 CERAMIC 0.01uF 30% 16V
C30 1-126-961-11 ELECT 2.2uF 20% 50V
C31 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C32 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C33 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C34 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C35 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C36 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C37 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C39 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C40 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C41 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C42 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C43 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C44 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C45 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C46 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C47 1-126-967-11 ELECT 47uF 20% 16V
C48 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C49 1-126-959-11 ELECT 0.47uF 20% 50V
C50 1-126-960-11 ELECT 1.0uF 20% 50V
C51 1-126-960-11 ELECT 1.0uF 20% 50V
C52 1-126-963-11 ELECT 4.7uF 20% 50V
C53 1-126-964-11 ELECT 10uF 20% 50V
C54 1-104-396-11 ELECT 10uF 20% 16V
C55 1-104-396-11 ELECT 10uF 20% 16V
C56 1-104-396-11 ELECT 10uF 20% 16V
C57 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C58 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C59 1-163-989-11 CERAMIC CHIP 33000PF 10% 25V
C60 1-163-989-11 CERAMIC CHIP 33000PF 10% 25V
C61 1-126-301-11 ELECT 1.0uF 20% 50V
C62 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C63 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C64 1-126-967-11 ELECT 47uF 20% 16V
C65 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C66 1-126-162-11 ELECT 3.3uF 20% 50V
C67 1-126-933-11 ELECT 100uF 20% 10V
C68 1-162-306-11 CERAMIC 0.01uF 30% 16V
C71 1-162-306-11 CERAMIC 0.01uF 30% 16V
C72 1-126-967-11 ELECT 47uF 20% 16V
C120 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C1701 1-162-294-31 CERAMIC CHIP 1000PF 10% 50V
C1702 1-130-014-00 FILM 470PF 5% 50V
C1703 1-126-959-11 ELECT 0.47uF 20% 50V
C1704 1-126-959-11 ELECT 0.47uF 20% 50V
C1705 1-163-035-00 CERAMIC CHIP 0.047uF 50V
C1706 1-126-960-11 ELECT 1.0uF 20% 50V
C1707 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C1710 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C1711 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C1712 1-130-736-11 FILM 0.01uF 5% 50V
C1713 1-130-736-11 FILM 0.01uF 5% 50V
C1714 1-126-960-11 ELECT 1.0uF 20% 50V
C1715 1-126-960-11 ELECT 1.0uF 20% 50V
C1716 1-126-960-11 ELECT 1.0uF 20% 50V
C1719 1-126-967-11 ELECT 47uF 20% 16V
C1720 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C1723 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C1724 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C1725 1-126-967-11 ELECT 47uF 20% 16V
C1726 1-126-960-11 ELECT 1.0uF 20% 50V
C1727 1-126-960-11 ELECT 1.0uF 20% 50V
C1728 1-126-966-11 ELECT 33uF 20% 16V
< FILTER >
CF1 1-567-389-11 FILTER, CERAMIC
CF3 1-567-389-11 FILTER, CERAMIC
CF3 1-760-393-11 FILTER, CERAMIC
< CONNECTOR >
* CN1 1-568-834-11 SOCKET, CONNECTOR 15P
< TRIMMER >
CT1701 1-141-444-11 CAP, CERAMIC TRIMMER 50PF
< DIODE >
D21 8-719-976-99 DIODE DTZ5.1B
D41 8-719-016-74 DIODE 1SS352
D42 8-719-016-74 DIODE 1SS352
D43 8-719-016-74 DIODE 1SS352
D1701 8-719-016-74 DIODE 1SS352
D1702 8-719-016-74 DIODE 1SS352
D1703 8-719-987-63 DIODE 1N4148
D1704 8-719-016-74 DIODE 1SS352
< FRONTEND >
FE1 1-693-335-11 FRONT END (3 GANG)
FE2 1-233-514-11 ENCAPSULATED COMPONENT
< IC >
IC21 8-759-288-54 IC LC72130
IC41 8-759-176-03 IC LA1835
IC1701 8-759-063-04 IC IR3R42
IC1702 8-759-140-53 IC uPD4053BC
< IFT >
IFT41 1-409-636-11 TRANSFORMER, IF (CERAMIC FILTER)
< JUMPER RESISTOR >
JR2 1-216-295-91 METAL CHIP 0 5% 1/10W
