— 106 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-650-669-11 LEAF SWITCH BOARD
*****************
< CONNECTOR >
* CN1001 1-568-854-11 SOCKET, CONNECTOR 11P
< TRANSISTOR >
Q1001 8-749-010-90 TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H2
Q1002 8-749-010-90 TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H2
< RESISTOR >
R1001 1-247-818-11 CARBON 300 5% 1/4W
R1002 1-247-820-11 CARBON 360 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1 KEY)(A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY)(B PLAY)
S1003 1-572-248-11 SWITCH, LEAF (A HALF)
S1004 1-571-281-21 SWITCH, LEAF (A CrO2)
S1005 1-571-281-21 SWITCH, LEAF (REC A)
S1006 1-572-248-11 SWITCH, LEAF (B HALF)
S1008 1-571-281-21 SWITCH, LEAF (B CrO2)
S1009 1-571-281-21 SWITCH, LEAF (REC B)
**************************************************************
* A-4392-628-A MAIN BOARD, COMPLETE (GR10AV:E2)
********************************
* A-4392-629-A MAIN BOARD, COMPLETE
*********************
(GR10AV:E3,SP,JE,HK,IA)
* A-4392-630-A MAIN BOARD, COMPLETE (RX100AV:AEP,UK,G)
**************************************
* A-4392-631-A MAIN BOARD, COMPLETE (RX100AV:US,CND)
**************************************
* A-4398-048-A MAIN BOARD, COMPLETE (D90AV)
*****************************
* A-4398-054-A MAIN BOARD, COMPLETE (RX100AV:EE,CIS)
**************************************
* A-4398-057-A MAIN BOARD, COMPLETE (GR10AV:AUS)
**********************************
* A-4398-310-A MAIN BOARD, COMPLETE (GR10AV:TH)
*********************************
* A-4398-876-A MAIN BOARD, COMPLETE (GR10AV:EA)
*********************************
* A-4398-882-A MAIN BOARD, COMPLETE (GR10AV:MY)
*********************************
< CAPACITOR >
C110 1-162-306-11 CERAMIC 0.01uF 20% 16V
C121 1-162-286-21 CERAMIC 220PF 10% 50V
C122 1-162-286-21 CERAMIC 220PF 10% 50V
C125 1-124-499-11 ELECT 1uF 20% 50V
C127 1-162-306-11 CERAMIC 0.01uF 20% 16V
(GR10AV/RX100AV)
C128 1-162-306-11 CERAMIC 0.01uF 20% 16V
(GR10AV/RX100AV)
C129 1-162-292-31 CERAMIC 680PF 10% 50V
(GR10AV/RX100AV)
C130 1-126-964-11 ELECT 10uF 20% 50V
(GR10AV/RX100AV)
C131 1-162-286-21 CERAMIC 220PF 10% 50V
(GR10AV/RX100AV)
C171 1-162-286-21 CERAMIC 220PF 10% 50V
C172 1-162-286-21 CERAMIC 220PF 10% 50V
C201 1-126-957-11 ELECT 0.22uF 20% 50V
C202 1-126-957-11 ELECT 0.22uF 20% 50V
C203 1-136-495-11 FILM 0.068uF 5% 50V
C204 1-136-495-11 FILM 0.068uF 5% 50V
C205 1-136-156-00 FILM 0.018uF 5% 50V
C206 1-136-156-00 FILM 0.018uF 5% 50V
C207 1-130-480-00 MYLAR 0.0056uF 5% 50V
C208 1-130-479-00 MYLAR 0.0047uF 5% 50V
C209 1-130-474-00 MYLAR 0.0018uF 5% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-126-964-11 ELECT 10uF 20% 50V
C212 1-136-165-00 FILM 0.1uF 5% 50V
C213 1-136-165-00 FILM 0.1uF 5% 50V
C214 1-126-964-11 ELECT 10uF 20% 50V
C215 1-136-153-00 FILM 0.01uF 5% 50V
C230 1-136-167-00 FILM 0.15uF 5% 50V
C231 1-130-471-00 MYLAR 0.001uF 5% 50V
C234 1-126-933-11 ELECT 100uF 20% 10V
C235 1-164-159-21 CERAMIC 0.1uF 50V
C237 1-126-964-11 ELECT 10uF 20% 50V
C238 1-162-286-21 CERAMIC 220PF 10% 50V
C239 1-162-306-11 CERAMIC 0.01uF 20% 16V
C241 1-162-306-11 CERAMIC 0.01uF 20% 16V
C242 1-126-933-11 ELECT 100uF 20% 10V
C247 1-162-306-11 CERAMIC 0.01uF 20% 16V
C248 1-126-964-11 ELECT 10uF 20% 50V
C251 1-126-957-11 ELECT 0.22uF 20% 50V
C252 1-126-957-11 ELECT 0.22uF 20% 50V
C253 1-136-495-11 FILM 0.068uF 5% 50V
C254 1-136-495-11 FILM 0.068uF 5% 50V
C255 1-136-156-00 FILM 0.018uF 5% 50V
C256 1-136-156-00 FILM 0.018uF 5% 50V
C257 1-130-480-00 MYLAR 0.0056uF 5% 50V
C258 1-130-479-00 MYLAR 0.0047uF 5% 50V
C259 1-130-474-00 MYLAR 0.0018uF 5% 50V
C260 1-126-964-11 ELECT 10uF 20% 50V
C261 1-126-964-11 ELECT 10uF 20% 50V
C262 1-136-165-00 FILM 0.1uF 5% 50V
C263 1-136-165-00 FILM 0.1uF 5% 50V
C264 1-126-964-11 ELECT 10uF 20% 50V
C265 1-136-153-00 FILM 0.01uF 5% 50V
LEAF SWITCH MAIN
