— 112 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C607 1-126-160-11 ELECT 1uF 20% 50V
C608 1-162-294-31 CERAMIC 0.001uF 10% 50V
C609 1-162-282-31 CERAMIC 100PF 10% 50V
C610 1-162-282-31 CERAMIC 100PF 10% 50V
C611 1-162-282-31 CERAMIC 100PF 10% 50V
C612 1-162-282-31 CERAMIC 100PF 10% 50V
C613 1-162-282-31 CERAMIC 100PF 10% 50V
C614 1-162-282-31 CERAMIC 100PF 10% 50V
C615 1-162-282-31 CERAMIC 100PF 10% 50V
C616 1-162-282-31 CERAMIC 100PF 10% 50V
C617 1-162-282-31 CERAMIC 100PF 10% 50V
C618 1-162-282-31 CERAMIC 100PF 10% 50V
C619 1-162-282-31 CERAMIC 100PF 10% 50V
C620 1-162-282-31 CERAMIC 100PF 10% 50V
C621 1-162-282-31 CERAMIC 100PF 10% 50V
C622 1-162-282-31 CERAMIC 100PF 10% 50V
C623 1-162-282-31 CERAMIC 100PF 10% 50V
C624 1-162-282-31 CERAMIC 100PF 10% 50V
C625 1-162-294-31 CERAMIC 0.001uF 10% 50V
C626 1-124-589-11 ELECT 47uF 20% 16V
C627 1-162-306-11 CERAMIC 0.01uF 20% 16V
C628 1-162-306-11 CERAMIC 0.01uF 20% 16V
C629 1-162-306-11 CERAMIC 0.01uF 20% 16V
C630 1-162-306-11 CERAMIC 0.01uF 20% 16V
C636 1-126-160-11 ELECT 1uF 20% 50V
C637 1-136-161-00 FILM 0.047uF 5% 50V
C638 1-124-464-11 ELECT 0.22uF 20% 50V
C639 1-124-464-11 ELECT 0.22uF 20% 50V
C640 1-162-306-11 CERAMIC 0.01uF 20% 16V
C641 1-124-464-11 ELECT 0.22uF 20% 50V
C642 1-136-159-00 FILM 0.033uF 5% 50V
C643 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C644 1-124-464-11 ELECT 0.22uF 20% 50V
C646 1-130-470-00 MYLAR 820PF 5% 50V
C647 1-124-464-11 ELECT 0.22uF 20% 50V
C648 1-164-159-21 CERAMIC 0.1uF 20% 16V
C649 1-124-589-11 ELECT 47uF 20% 16V
C650 1-124-464-11 ELECT 0.22uF 20% 50V
C653 1-164-159-21 CERAMIC 0.1uF 50V
C654 1-162-294-31 CERAMIC 0.001uF 50V
< CONNECTOR >
CN601 1-568-860-11 SOCKET, CONNECTOR 17P
CN603 1-568-853-11 SOCKET, CONNECTOR 10P
(GR10AV/RX100AV:AEP,UK,G,EE,CIS)
* CN603 1-568-851-11 SOCKET, CONNECTOR 8P
(D90AV/RX100AV:US,CND)
CN609 1-691-645-11 SOCKET, CONNECTOR 9P
< DIODE >
D601 8-719-058-03 DIODE SEL5423E-TP15 (TUNER/BAND)
D602 8-719-057-44 DIODE HLMF-K305-2UP (DSP)
D604 8-719-058-04 DIODE SEL5223S-TP15 (EFFECT ON/OFF)
D605 8-719-058-04 DIODE SEL5223S-TP15 (JOG)
D606 8-719-057-44 DIODE HLMF-K305-2UP (+)
D607 8-719-057-44 DIODE HLMF-K305-2UP (–)
D608 8-719-057-44 DIODE HLMF-K305-2UP (+)
D609 8-719-057-44 DIODE HLMF-K305-2UP (=)
D610 8-719-057-30 DIODE HLMF-K205-2UL (ENTER/NEXT)
D611 8-719-057-97 DIODE SEL5923A-TP15 (PROLOGIC)
D612 8-719-057-97 DIODE SEL5923A-TP15 (PROLOGIC)
D614 8-719-057-44 DIODE HLMF-K305-2UP (GROOVE)
D615 8-719-058-04 DIODE SEL5223S-TP15 (NON-STOP)
D650 8-719-987-63 DIODE 1N4148M
D651 8-719-987-63 DIODE 1N4148M
D652 8-719-987-63 DIODE 1N4148M
D653 8-719-987-63 DIODE 1N4148M
D654 8-719-987-63 DIODE 1N4148M
D655 8-719-987-63 DIODE 1N4148M
D656 8-719-987-63 DIODE 1N4148M
< FERRITE BEAD >
FB601 1-412-473-21 INDUCTOR 0UH
< FLUORESCENT INDICATOR >
FL601 1-517-618-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-446-27 IC TMP87CH75F-6543
IC602 8-759-332-18 IC GP1U27XB
< COIL >
L601 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q601 8-729-118-00 TRANSISTOR 2SB1116-L
Q602 8-729-118-00 TRANSISTOR 2SB1116-L
Q603 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q604 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q605 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q606 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q607 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q608 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R601 1-247-903-00 CARBON 1M 5% 1/4W
R602 1-247-807-31 CARBON 100 5% 1/4W
R603 1-249-429-11 CARBON 10K 5% 1/4W
R604 1-249-429-11 CARBON 10K 5% 1/4W
R605 1-249-429-11 CARBON 10K 5% 1/4W
R606 1-249-429-11 CARBON 10K 5% 1/4W
R607 1-249-429-11 CARBON 10K 5% 1/4W
R608 1-247-843-11 CARBON 3.3K 5% 1/4W
R609 1-247-843-11 CARBON 3.3K 5% 1/4W
R610 1-247-807-31 CARBON 100 5% 1/4W
R611 1-247-807-31 CARBON 100 5% 1/4W
R612 1-249-429-11 CARBON 10K 5% 1/4W
R613 1-249-421-11 CARBON 2.2K 5% 1/4W F
R614 1-247-863-91 CARBON 22K 5% 1/4W
R615 1-249-429-11 CARBON 10K 5% 1/4W
R616 1-249-429-11 CARBON 10K 5% 1/4W
R617 1-247-804-11 CARBON 75 5% 1/4W
R618 1-247-804-11 CARBON 75 5% 1/4W
R619 1-249-401-11 CARBON 47 5% 1/4W F
R620 1-249-419-11 CARBON 1.5K 5% 1/4W F
PANEL
