Sony HCD-DP900D - Electrical Parts List - DSP Section (Cont.); DSP Section Resistors List (Cont.)

73
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP900D
FB606 1-216-805-11 METAL CHIP 47 5% 1/16W
FB607 1-500-445-21 FERRITE 0UH
FB608 1-500-445-21 FERRITE 0UH
FB609 1-500-445-21 FERRITE 0UH
< IC >
IC601 8-759-698-76 IC CXD9617R
IC602 8-759-827-81 IC IS61LV6416-15T(T&R)
IC603 8-759-238-47 IC TC74HCT7007AF(EL)
IC604 8-759-825-15 IC LC89056W-E
IC605 8-759-657-47 IC AK4527
IC607 8-749-018-85 IC M61512FP
IC608 8-759-549-25 IC SN74LVU04APWR
IC609 8-749-923-04 IC TOTX178A (DIGITAL OUT OPTICAL)
IC610 8-759-835-63 IC NJM2391DL1-26-TE1
< JACK >
J601 1-770-890-11 JACK, PIN 6P (GAME/MD(VIDEO))
J602 1-774-785-11 JACK, PIN 1P (SUB WOOFER OUT)
< JUMPER RESISTOR >
JR602 1-216-864-11 METAL CHIP 0 5% 1/16W
JR604 1-216-864-11 METAL CHIP 0 5% 1/16W
JR620 1-216-864-11 METAL CHIP 0 5% 1/16W
JR621 1-216-864-11 METAL CHIP 0 5% 1/16W
JR622 1-216-864-11 METAL CHIP 0 5% 1/16W
JR630 1-216-864-11 METAL CHIP 0 5% 1/16W
< TRANSISTOR >
Q601 8-729-801-93 TRANSISTOR 2SD1387-3
Q603 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q604 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q605 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q606 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q607 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q611 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q612 8-729-113-69 TRANSISTOR FN1F4M-M32
Q613 8-729-113-13 TRANSISTOR FA1A4M-L33
< RESISTOR >
R601 1-216-809-11 METAL CHIP 100 5% 1/16W
R602 1-216-813-11 METAL CHIP 220 5% 1/16W
R603 1-216-809-11 METAL CHIP 100 5% 1/16W
R604 1-216-809-11 METAL CHIP 100 5% 1/16W
R605 1-216-809-11 METAL CHIP 100 5% 1/16W
R606 1-216-809-11 METAL CHIP 100 5% 1/16W
R608 1-216-809-11 METAL CHIP 100 5% 1/16W
R609 1-216-809-11 METAL CHIP 100 5% 1/16W
R611 1-216-809-11 METAL CHIP 100 5% 1/16W
R612 1-216-809-11 METAL CHIP 100 5% 1/16W
R613 1-216-809-11 METAL CHIP 100 5% 1/16W
R614 1-216-809-11 METAL CHIP 100 5% 1/16W
R615 1-216-809-11 METAL CHIP 100 5% 1/16W
R616 1-216-809-11 METAL CHIP 100 5% 1/16W
R617 1-216-809-11 METAL CHIP 100 5% 1/16W
R618 1-216-809-11 METAL CHIP 100 5% 1/16W
R619 1-216-809-11 METAL CHIP 100 5% 1/16W
R620 1-216-809-11 METAL CHIP 100 5% 1/16W
R621 1-216-809-11 METAL CHIP 100 5% 1/16W
R623 1-216-833-11 METAL CHIP 10K 5% 1/16W
R628 1-216-809-11 METAL CHIP 100 5% 1/16W
R629 1-216-809-11 METAL CHIP 100 5% 1/16W
R630 1-216-809-11 METAL CHIP 100 5% 1/16W
R631 1-216-809-11 METAL CHIP 100 5% 1/16W
R632 1-216-809-11 METAL CHIP 100 5% 1/16W
R633 1-216-809-11 METAL CHIP 100 5% 1/16W
R634 1-216-809-11 METAL CHIP 100 5% 1/16W
R635 1-216-809-11 METAL CHIP 100 5% 1/16W
R636 1-216-809-11 METAL CHIP 100 5% 1/16W
R637 1-216-809-11 METAL CHIP 100 5% 1/16W
R638 1-216-809-11 METAL CHIP 100 5% 1/16W
R639 1-216-809-11 METAL CHIP 100 5% 1/16W
R640 1-216-809-11 METAL CHIP 100 5% 1/16W
R641 1-216-809-11 METAL CHIP 100 5% 1/16W
R642 1-216-809-11 METAL CHIP 100 5% 1/16W
R644 1-216-815-11 METAL CHIP 330 5% 1/16W
R645 1-216-815-11 METAL CHIP 330 5% 1/16W
R646 1-216-815-11 METAL CHIP 330 5% 1/16W
R647 1-216-815-11 METAL CHIP 330 5% 1/16W
R648 1-216-815-11 METAL CHIP 330 5% 1/16W
R649 1-216-817-11 METAL CHIP 470 5% 1/16W
R650 1-216-817-11 METAL CHIP 470 5% 1/16W
R651 1-216-817-11 METAL CHIP 470 5% 1/16W
R652 1-216-817-11 METAL CHIP 470 5% 1/16W
R667 1-216-809-11 METAL CHIP 100 5% 1/16W
R668 1-216-809-11 METAL CHIP 100 5% 1/16W
R669 1-216-809-11 METAL CHIP 100 5% 1/16W
R670 1-216-809-11 METAL CHIP 100 5% 1/16W
R671 1-216-809-11 METAL CHIP 100 5% 1/16W
R672 1-216-809-11 METAL CHIP 100 5% 1/16W
R673 1-216-809-11 METAL CHIP 100 5% 1/16W
R674 1-216-809-11 METAL CHIP 100 5% 1/16W
R675 1-216-809-11 METAL CHIP 100 5% 1/16W
R676 1-216-809-11 METAL CHIP 100 5% 1/16W
R677 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R678 1-216-833-11 METAL CHIP 10K 5% 1/16W
R679 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R680 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R681 1-216-839-11 METAL CHIP 33K 5% 1/16W
R682 1-216-809-11 METAL CHIP 100 5% 1/16W
R683 1-216-809-11 METAL CHIP 100 5% 1/16W
R684 1-216-809-11 METAL CHIP 100 5% 1/16W
R685 1-216-809-11 METAL CHIP 100 5% 1/16W
R686 1-216-809-11 METAL CHIP 100 5% 1/16W
R687 1-216-809-11 METAL CHIP 100 5% 1/16W
R688 1-216-809-11 METAL CHIP 100 5% 1/16W
R689 1-216-821-11 METAL CHIP 1K 5% 1/16W
R690 1-216-857-11 METAL CHIP 1M 5% 1/16W
R691 1-216-815-11 METAL CHIP 330 5% 1/16W
R692 1-216-809-11 METAL CHIP 100 5% 1/16W
R693 1-216-809-11 METAL CHIP 100 5% 1/16W
R694 1-216-809-11 METAL CHIP 100 5% 1/16W
R695 1-216-821-11 METAL CHIP 1K 5% 1/16W
R696 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R697 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R698 1-216-852-11 METAL CHIP 390K 5% 1/16W
R699 1-216-852-11 METAL CHIP 390K 5% 1/16W
R700 1-216-833-11 METAL CHIP 10K 5% 1/16W
R701 1-216-833-11 METAL CHIP 10K 5% 1/16W
R702 1-216-857-11 METAL CHIP 1M 5% 1/16W
R703 1-216-857-11 METAL CHIP 1M 5% 1/16W
R704 1-216-845-11 METAL CHIP 100K 5% 1/16W
DSP
