Sony HCD-DP900D - Electrical Parts List - Front Amp Section; Front Amp Section Resistors List; Front Amp Section Capacitors List; Front Amp Section Connectors List

74
Ref. No. Part No. Description Remarks
Ref. No. Part No. Description Remarks
HCD-DP900D
R705 1-216-845-11 METAL CHIP 100K 5% 1/16W
R706 1-216-841-11 METAL CHIP 47K 5% 1/16W
R707 1-216-841-11 METAL CHIP 47K 5% 1/16W
R708 1-216-857-11 METAL CHIP 1M 5% 1/16W
R709 1-216-841-11 METAL CHIP 47K 5% 1/16W
R711 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R712 1-216-845-11 METAL CHIP 100K 5% 1/16W
R713 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R715 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R716 1-216-845-11 METAL CHIP 100K 5% 1/16W
R717 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R730 1-216-837-11 METAL CHIP 22K 5% 1/16W
R731 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R733 1-216-821-11 METAL CHIP 1K 5% 1/16W
R734 1-216-821-11 METAL CHIP 1K 5% 1/16W
R736 1-216-821-11 METAL CHIP 1K 5% 1/16W
R737 1-216-821-11 METAL CHIP 1K 5% 1/16W
R740 1-216-835-11 METAL CHIP 15K 5% 1/16W
R741 1-216-835-11 METAL CHIP 15K 5% 1/16W
R744 1-216-833-11 METAL CHIP 10K 5% 1/16W
R745 1-216-833-11 METAL CHIP 10K 5% 1/16W
R747 1-216-845-11 METAL CHIP 100K 5% 1/16W
R748 1-216-845-11 METAL CHIP 100K 5% 1/16W
R749 1-216-834-11 METAL CHIP 12K 5% 1/16W
R750 1-216-834-11 METAL CHIP 12K 5% 1/16W
R751 1-216-841-11 METAL CHIP 47K 5% 1/16W
R752 1-216-841-11 METAL CHIP 47K 5% 1/16W
R753 1-216-809-11 METAL CHIP 100 5% 1/16W
R754 1-216-809-11 METAL CHIP 100 5% 1/16W
R756 1-216-841-11 METAL CHIP 47K 5% 1/16W
R757 1-216-841-11 METAL CHIP 47K 5% 1/16W
R758 1-216-821-11 METAL CHIP 1K 5% 1/16W
R759 1-216-821-11 METAL CHIP 1K 5% 1/16W
R760 1-216-821-11 METAL CHIP 1K 5% 1/16W
R761 1-216-821-11 METAL CHIP 1K 5% 1/16W
R762 1-216-821-11 METAL CHIP 1K 5% 1/16W
R763 1-216-821-11 METAL CHIP 1K 5% 1/16W
R765 1-216-821-11 METAL CHIP 1K 5% 1/16W
R766 1-216-821-11 METAL CHIP 1K 5% 1/16W
R767 1-216-821-11 METAL CHIP 1K 5% 1/16W
R768 1-216-833-11 METAL CHIP 10K 5% 1/16W
R769 1-216-821-11 METAL CHIP 1K 5% 1/16W
R770 1-216-821-11 METAL CHIP 1K 5% 1/16W
R771 1-216-833-11 METAL CHIP 10K 5% 1/16W
R772 1-216-821-11 METAL CHIP 1K 5% 1/16W
R773 1-216-821-11 METAL CHIP 1K 5% 1/16W
R774 1-216-821-11 METAL CHIP 1K 5% 1/16W
R775 1-216-833-11 METAL CHIP 10K 5% 1/16W
R776 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R777 1-216-833-11 METAL CHIP 10K 5% 1/16W
R778 1-216-821-11 METAL CHIP 1K 5% 1/16W
R779 1-216-841-11 METAL CHIP 47K 5% 1/16W
R780 1-216-841-11 METAL CHIP 47K 5% 1/16W
R781 1-216-841-11 METAL CHIP 47K 5% 1/16W
< VIBRATOR >
X601 1-579-993-21 VIBRATOR, CERAMIC (13.5MHz)
******************************************************
A-4727-079-A FRONT AMP BOARD, COMPLETE (SP,MY,EA)
A-4727-091-A FRONT AMP BOARD, COMPLETE (E,MX)
A-4727-102-A FRONT AMP BOARD, COMPLETE (TH)
***************************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C801 1-126-964-11 ELECT 10uF 20% 50V
C802 1-162-292-31 CERAMIC 680PF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-126-933-11 ELECT 100uF 20% 16V
C805 1-102-936-00 CERAMIC 3.0PF +-0.25PF50V
C806 1-136-495-11 FILM 0.068uF 5% 50V
C807 1-136-495-11 FILM 0.068uF 5% 50V
C808 1-128-560-11 ELECT 22uF 20% 100V
C812 1-136-165-00 FILM 0.1uF 5% 50V
C816 1-162-306-11 CERAMIC 0.01uF 30% 16V
C821 1-128-562-11 ELECT 47uF 20% 100V
C822 1-126-968-11 ELECT 100uF 20% 50V
C831 1-126-964-11 ELECT 10uF 20% 50V
C832 1-126-382-11 ELECT 100uF 20% 10V
C833 1-126-961-11 ELECT 2.2uF 20% 50V
C834 1-104-665-11 ELECT 100uF 20% 10V
C851 1-126-964-11 ELECT 10uF 20% 50V
C852 1-162-292-31 CERAMIC 680PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-126-933-11 ELECT 100uF 20% 16V
C855 1-102-936-00 CERAMIC 3.0PF +-0.25PF50V
C856 1-136-495-11 FILM 0.068uF 5% 50V
C857 1-136-495-11 FILM 0.068uF 5% 50V
C858 1-128-560-11 ELECT 22uF 20% 100V
C862 1-136-165-00 FILM 0.1uF 5% 50V
C871 1-137-749-11 MYLAR 0.1uF 100V
C872 1-137-749-11 MYLAR 0.1uF 100V
C873 1-137-842-11 ELECT 2200uF 20% 80V
C874 1-137-842-11 ELECT 2200uF 20% 80V
C881 1-136-165-00 FILM 0.1uF 5% 50V
C882 1-136-165-00 FILM 0.1uF 5% 50V
C883 1-136-165-00 FILM 0.1uF 5% 50V
C884 1-136-165-00 FILM 0.1uF 5% 50V
C885 1-162-306-11 CERAMIC 0.01uF 30% 16V
C886 1-162-306-11 CERAMIC 0.01uF 30% 16V
C920 1-126-956-91 ELECT 0.1uF 20% 50V
C921 1-126-964-11 ELECT 10uF 20% 50V
C922 1-126-767-11 ELECT 1000uF 20% 16V
C923 1-126-964-11 ELECT 10uF 20% 50V
C924 1-126-926-11 ELECT 1000uF 20% 10V
C925 1-126-964-11 ELECT 10uF 20% 50V
C926 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN801 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
CN802 1-784-031-21 CONNECTOR, BOARD TO BOARD 8P
CN803 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< DIODE >
D801 8-719-911-19 DIODE 1SS119-25
D802 8-719-947-65 DIODE MTZJ-T-72-16B
D821 8-719-911-19 DIODE 1SS119-25
D830 8-719-911-19 DIODE 1SS119-25
D831 8-719-911-19 DIODE 1SS119-25
D851 8-719-911-19 DIODE 1SS119-25
D852 8-719-947-65 DIODE MTZJ-T-72-16B
DSP FRONT AMP
Ver 1.1 2002.03
