Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP900D
D871 8-719-510-68 DIODE D5SBA204101
D881 8-719-911-19 DIODE 1SS119-25
D891 8-719-911-19 DIODE 1SS119-25
D921 8-719-050-84 DIODE RB441Q-40T-77
D922 8-719-947-81 DIODE MTZJ-T-72-24A
< IC >
IC801 8-749-017-04 IC STK412-030
IC921 6-701-381-01 IC UPC24A12AHF
IC922 8-759-701-59 IC NJM7809FA
IC923 8-759-088-08 IC UPC7812AHF
< COIL >
L881 1-420-872-00 COIL, AIR-CORE
L882 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q816 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q817 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q821 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q822 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q823 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q831 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q832 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q833 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q834 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q835 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q836 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q837 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q881 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q882 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q921 8-729-209-60 TRANSISTOR 2SB1375
Q922 8-729-900-80 TRANSISTOR DTC114ES
Q923 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q924 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-438-11 CARBON 56K 5% 1/4W
R803 1-249-407-11 CARBON 150 5% 1/4W F
R804 1-249-438-11 CARBON 56K 5% 1/4W
0 R805 1-220-755-11 METAL 0.22 10% 2W
0 R806 1-220-755-11 METAL 0.22 10% 2W
R807 1-249-417-11 CARBON 1K 5% 1/4W F
R808 1-249-431-11 CARBON 15K 5% 1/4W
R809 1-249-441-11 CARBON 100K 5% 1/4W
R810 1-260-076-11 CARBON 10 5% 1/2W
0 R811 1-212-881-11 FUSIBLE 100 5% 1/4W
R812 1-260-330-11 CARBON 1.5K 5% 1/2W
R816 1-249-441-11 CARBON 100K 5% 1/4W
R817 1-249-441-11 CARBON 100K 5% 1/4W
R818 1-249-441-11 CARBON 100K 5% 1/4W
R819 1-249-429-11 CARBON 10K 5% 1/4W
0 R820 1-202-972-61 FUSIBLE 1 5% 1/4W
R821 1-249-421-11 CARBON 2.2K 5% 1/4W F
R822 1-249-433-11 CARBON 22K 5% 1/4W
R823 1-249-429-11 CARBON 10K 5% 1/4W
R824 1-249-421-11 CARBON 2.2K 5% 1/4W F
R825 1-249-439-11 CARBON 68K 5% 1/4W
R826 1-249-426-11 CARBON 5.6K 5% 1/4W
R827 1-249-431-11 CARBON 15K 5% 1/4W
R828 1-249-435-11 CARBON 33K 5% 1/4W
R830 1-249-425-11 CARBON 4.7K 5% 1/4W F
R831 1-249-425-11 CARBON 4.7K 5% 1/4W F
R832 1-249-417-11 CARBON 1K 5% 1/4W F
R833 1-249-425-11 CARBON 4.7K 5% 1/4W F
R834 1-249-433-11 CARBON 22K 5% 1/4W
R835 1-249-435-11 CARBON 33K 5% 1/4W
R836 1-249-429-11 CARBON 10K 5% 1/4W
R837 1-249-429-11 CARBON 10K 5% 1/4W
R839 1-249-437-11 CARBON 47K 5% 1/4W
R840 1-249-438-11 CARBON 56K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-438-11 CARBON 56K 5% 1/4W
R853 1-249-407-11 CARBON 150 5% 1/4W F
R854 1-249-438-11 CARBON 56K 5% 1/4W
0 R855 1-220-755-11 METAL 0.22 10% 2W
0 R856 1-220-755-11 METAL 0.22 10% 2W
R857 1-249-417-11 CARBON 1K 5% 1/4W F
R858 1-249-431-11 CARBON 15K 5% 1/4W
R859 1-249-441-11 CARBON 100K 5% 1/4W
R860 1-260-076-11 CARBON 10 5% 1/2W
0 R861 1-212-881-11 FUSIBLE 100 5% 1/4W
R862 1-260-330-11 CARBON 1.5K 5% 1/2W
R871 1-249-441-11 CARBON 100K 5% 1/4W
R872 1-249-441-11 CARBON 100K 5% 1/4W
0 R880 1-215-890-11 METAL OXIDE 470 5% 2W
R881 1-260-076-11 CARBON 10 5% 1/2W
R882 1-260-076-11 CARBON 10 5% 1/2W
R883 1-260-076-11 CARBON 10 5% 1/2W
R884 1-260-076-11 CARBON 10 5% 1/2W
R885 1-249-437-11 CARBON 47K 5% 1/4W
R886 1-249-437-11 CARBON 47K 5% 1/4W
R887 1-249-429-11 CARBON 10K 5% 1/4W
R888 1-249-437-11 CARBON 47K 5% 1/4W
R889 1-249-429-11 CARBON 10K 5% 1/4W
R890 1-249-441-11 CARBON 100K 5% 1/4W
R921 1-249-429-11 CARBON 10K 5% 1/4W
R924 1-249-429-11 CARBON 10K 5% 1/4W
R925 1-249-427-11 CARBON 6.8K 5% 1/4W F
< RELAY >
RY881 1-515-920-11 RELAY
< THERMISTOR >
TH801 1-807-796-11 THERMISTOR
< TERMINAL >
TM801 1-694-677-12 TERMINAL BOARD (4P) (FRONT SPEAKER)
******************************************************
A-2007-839-A HEAD (A) BOARD, COMPLETE
*********************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
******************************************************
FRONT AMP
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
HEAD (A)
