Sony HCD-DP900D - Electrical Parts List - MB and Related Boards; MB Board Parts List; OPT In Board Parts List; Panel Board Parts List

76
Ref. No. Part No. Description Remarks
Ref. No. Part No. Description Remarks
HCD-DP900D
A-2007-840-A HEAD (B) BOARD, COMPLETE
*********************
CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
******************************************************
A-2007-838-A LEAF SW BOARD, COMPLETE
*********************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
CN1001 1-784-459-11 CONNECTOR, FFC/FPC 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS119-25
D1002 8-719-911-19 DIODE 1SS119-25
< IC >
IC1001 8-749-016-76 IC RPI-321
IC1002 8-749-016-76 IC RPI-321
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
Q1001 8-729-900-65 TRANSISTOR DTA144ES
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K (HIGH SPEED)
RV1002 1-241-785-11 RES, ADJ, CARBON 10K (NORM SPEED)
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (DECK A HALF)
S1004 1-771-536-12 SWITCH, LEAF (DECK A 120/70)
S1005 1-771-536-12 SWITCH, LEAF (DECK A REC)
S1006 1-771-333-11 SWITCH, LEAF (DECK B HALF)
S1008 1-771-536-12 SWITCH, LEAF (DECK B 120/70)
S1009 1-771-536-12 SWITCH, LEAF (DECK B REC)
******************************************************
A-4676-757-A MAIN BOARD, COMPLETE (EA)
A-4727-085-A MAIN BOARD, COMPLETE (SP,MY)
A-4727-095-A MAIN BOARD, COMPLETE (E,MX)
A-4727-108-A MAIN BOARD, COMPLETE (TH)
*************************
< CAPACITOR >
C1 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C3 1-126-947-11 ELECT 47uF 20% 16V
C4 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C5 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C7 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C11 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C12 1-126-947-11 ELECT 47uF 20% 16V
C13 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C14 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C15 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C16 1-126-947-11 ELECT 47uF 20% 16V
C17 1-126-959-11 ELECT 0.47uF 20% 50V
C18 1-126-960-11 ELECT 1uF 20% 50V
C19 1-126-960-11 ELECT 1uF 20% 50V
C20 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C21 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C22 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C23 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C24 1-126-963-11 ELECT 4.7uF 20% 50V
C25 1-126-964-11 ELECT 10uF 20% 50V
C26 1-164-471-11 CERAMIC CHIP 680PF 5% 50V
C27 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C28 1-126-963-11 ELECT 4.7uF 20% 50V
C29 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C30 1-126-962-11 ELECT 3.3uF 20% 50V
C31 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C32 1-126-963-11 ELECT 4.7uF 20% 50V
C34 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C35 1-126-947-11 ELECT 47uF 20% 16V
C36 1-126-963-11 ELECT 4.7uF 20% 50V
C38 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C39 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C40 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C41 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C42 1-162-940-11 CERAMIC CHIP 9PF 0.5PF 50V
C43 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C46 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C51 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C52 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C53 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C56 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C57 1-126-947-11 ELECT 47uF 20% 16V
C58 1-126-961-11 ELECT 2.2uF 20% 50V
C59 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C60 1-126-947-11 ELECT 47uF 20% 16V
C61 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C62 1-126-959-11 ELECT 0.47uF 20% 50V
C63 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C69 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C105 1-126-964-11 ELECT 10uF 20% 50V
C111 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C112 1-126-963-11 ELECT 4.7uF 20% 50V
C113 1-126-965-91 ELECT 22uF 20% 50V
C114 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C121 1-107-721-11 ELECT 4.7uF 20% 100V
C141 1-126-964-11 ELECT 10uF 20% 50V
C143 1-126-964-11 ELECT 10uF 20% 50V
C155 1-126-964-11 ELECT 10uF 20% 50V
C171 1-107-721-11 ELECT 4.7uF 20% 100V
C271 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C272 1-126-916-11 ELECT 1000uF 20% 6.3V
C273 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C274 1-126-916-11 ELECT 1000uF 20% 6.3V
C275 1-126-935-11 ELECT 470uF 20% 10V
C276 1-162-974-11 CERAMIC CHIP 0.01uF 50V
HEAD (B)
LEAF SW
MAIN
Ver 1.1 2002.03
