Sony HCD-DP900D - Electrical Parts List - Main Board (Cont.); Main Board Diodes List; Main Board ICs List; Main Board IF Transformers List

78
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP900D
MAIN
CN502 1-779-291-11 CONNECTOR,FFC(LIF(NON-ZIF))23P
< DIODE >
D51 8-719-988-61 DIODE 1SS355TE-17
D111 8-719-988-61 DIODE 1SS355TE-17
D112 8-719-056-82 DIODE UDZ-TE-17-6.2B
D113 8-719-056-83 DIODE UDZ-TE-17-6.8B
D501 8-719-988-61 DIODE 1SS355TE-17
D502 8-719-988-61 DIODE 1SS355TE-17
D503 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-988-61 DIODE 1SS355TE-17
D506 8-719-988-61 DIODE 1SS355TE-17
D507 8-719-988-61 DIODE 1SS355TE-17
D508 8-719-988-61 DIODE 1SS355TE-17
D509 8-719-988-61 DIODE 1SS355TE-17
D510 8-719-988-61 DIODE 1SS355TE-17
D511 8-719-988-61 DIODE 1SS355TE-17
D950 8-719-028-23 DIODE D3SBA20-4101
D959 8-719-028-23 DIODE D3SBA20-4101
D961 8-719-988-61 DIODE 1SS355TE-17
D962 8-719-988-61 DIODE 1SS355TE-17
D971 8-719-200-82 DIODE 11ES2
D972 8-719-200-82 DIODE 11ES2
D973 8-719-200-82 DIODE 11ES2
D974 8-719-200-82 DIODE 11ES2
D975 8-719-200-82 DIODE 11ES2
D981 8-719-200-82 DIODE 11ES2
D982 8-719-200-82 DIODE 11ES2
D983 8-719-200-82 DIODE 11ES2
D984 8-719-200-82 DIODE 11ES2
< FRONT END >
FE2 1-693-478-11 FRONT END (FM3 GANGS)
< IC >
IC11 8-759-828-33 IC LA1845
IC51 8-759-590-13 IC LC72131D
IC301 8-759-652-02 IC HA12226F
IC302 8-759-143-54 IC uPC1330HA
IC303 8-759-656-83 IC NJM4580MD-(TE2)
IC304 8-759-656-83 IC NJM4580MD-(TE2)
IC401 6-800-712-01 IC M30622MGA-A72FP
IC501 8-759-635-63 IC M51943BSL-TP
< IFT >
IFT11 1-435-848-12 TRANSFORMER,IF(CERAMIC FILTER)
< JUMPER RESISTOR >
JR1 1-216-864-11 METAL CHIP 0 5% 1/16W
JR2 1-216-864-11 METAL CHIP 0 5% 1/16W
JR3 1-216-864-11 METAL CHIP 0 5% 1/16W
JR4 1-216-864-11 METAL CHIP 0 5% 1/16W
JR5 1-216-864-11 METAL CHIP 0 5% 1/16W
JR6 1-216-864-11 METAL CHIP 0 5% 1/16W
JR7 1-216-864-11 METAL CHIP 0 5% 1/16W
JR8 1-216-864-11 METAL CHIP 0 5% 1/16W
JR10 1-216-864-11 METAL CHIP 0 5% 1/16W
JR12 1-216-864-11 METAL CHIP 0 5% 1/16W
JR15 1-216-864-11 METAL CHIP 0 5% 1/16W
JR19 1-216-864-11 METAL CHIP 0 5% 1/16W
JR22 1-216-864-11 METAL CHIP 0 5% 1/16W
JR24 1-216-864-11 METAL CHIP 0 5% 1/16W
JR25 1-216-864-11 METAL CHIP 0 5% 1/16W
JR26 1-216-864-11 METAL CHIP 0 5% 1/16W
JR27 1-216-864-11 METAL CHIP 0 5% 1/16W
JR29 1-216-864-11 METAL CHIP 0 5% 1/16W
JR30 1-216-864-11 METAL CHIP 0 5% 1/16W
JR31 1-216-864-11 METAL CHIP 0 5% 1/16W
JR32 1-216-864-11 METAL CHIP 0 5% 1/16W
JR33 1-216-864-11 METAL CHIP 0 5% 1/16W
JR34 1-216-864-11 METAL CHIP 0 5% 1/16W
JR271 1-216-864-11 METAL CHIP 0 5% 1/16W
JR272 1-216-864-11 METAL CHIP 0 5% 1/16W
JR273 1-216-864-11 METAL CHIP 0 5% 1/16W
JR400 1-216-864-11 METAL CHIP 0 5% 1/16W
JR416 1-216-864-11 METAL CHIP 0 5% 1/16W
JR418 1-216-864-11 METAL CHIP 0 5% 1/16W
JR420 1-216-864-11 METAL CHIP 0 5% 1/16W
JR462 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L301 1-410-780-11 INDUCTOR 27MH
L302 1-414-193-41 INDUCTOR 220uH
L303 1-414-193-41 INDUCTOR 220uH
L351 1-410-780-11 INDUCTOR 27MH
L971 1-410-478-11 INDUCTOR 47uH
< FILTER >
LPF11 1-234-612-11 FILTER, LOW PASS
LPF12 1-234-612-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-055-80 TRANSISTOR 2SC1674LK-TP
Q2 8-729-422-57 TRANSISTOR UN4111
Q11 8-729-620-05 TRANSISTOR 2SC2603-EF
Q12 8-729-620-05 TRANSISTOR 2SC2603-EF
Q111 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q112 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q113 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q114 8-729-900-36 TRANSISTOR DTC124ES
Q121 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q141 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q171 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q301 8-729-801-93 TRANSISTOR 2SD1387-3
Q302 8-729-142-46 TRANSISTOR 2SC2001-LK
Q303 8-729-142-46 TRANSISTOR 2SC2001-LK
Q304 8-729-900-63 TRANSISTOR DTA124ES
Q305 8-729-900-80 TRANSISTOR DTC114ES
Q391 8-729-140-04 TRANSISTOR 2SB1116A-L
Q392 8-729-900-80 TRANSISTOR DTC114ES
Q393 8-729-140-04 TRANSISTOR 2SB1116A-L
Q394 8-729-900-80 TRANSISTOR DTC114ES
Q395 8-729-900-80 TRANSISTOR DTC114ES
Q396 8-729-116-57 TRANSISTOR 2SB1068-K
Q397 8-729-900-80 TRANSISTOR DTC114ES
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-900-63 TRANSISTOR DTA124ES
Q503 8-729-900-63 TRANSISTOR DTA124ES
Q504 8-729-900-63 TRANSISTOR DTA124ES
Q505 8-729-900-36 TRANSISTOR DTC124ES
Q506 8-729-119-78 TRANSISTOR 2SC2785-HFE
