Sony HCD-DP900D - Electrical Parts List - Main Board (Cont.); Main Board Resistors List (Cont.)

79
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP900D
MAIN
Q507 8-729-422-57 TRANSISTOR UN4111
< RESISTOR >
R1 1-216-864-11 METAL CHIP 0 5% 1/16W
R3 1-216-805-11 METAL CHIP 47 5% 1/16W
R4 1-216-805-11 METAL CHIP 47 5% 1/16W
R5 1-216-819-11 METAL CHIP 680 5% 1/16W
R6 1-216-815-11 METAL CHIP 330 5% 1/16W
R7 1-216-819-11 METAL CHIP 680 5% 1/16W
R8 1-216-821-11 METAL CHIP 1K 5% 1/16W
R10 1-216-814-11 METAL CHIP 270 5% 1/16W
R12 1-216-833-11 METAL CHIP 10K 5% 1/16W
R13 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R14 1-216-814-11 METAL CHIP 270 5% 1/16W
R15 1-216-843-11 METAL CHIP 68K 5% 1/16W
R16 1-216-837-11 METAL CHIP 22K 5% 1/16W
R17 1-216-839-11 METAL CHIP 33K 5% 1/16W
R18 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R19 1-216-833-11 METAL CHIP 10K 5% 1/16W
R20 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R21 1-216-821-11 METAL CHIP 1K 5% 1/16W
R22 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R23 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R24 1-216-821-11 METAL CHIP 1K 5% 1/16W
R25 1-216-809-11 METAL CHIP 100 5% 1/16W
R26 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R27 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R28 1-216-849-11 METAL CHIP 220K 5% 1/16W
R29 1-216-849-11 METAL CHIP 220K 5% 1/16W
R30 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R31 1-216-864-11 METAL CHIP 0 5% 1/16W
R41 1-216-833-11 METAL CHIP 10K 5% 1/16W
R42 1-216-845-11 METAL CHIP 100K 5% 1/16W
R43 1-216-839-11 METAL CHIP 33K 5% 1/16W
R55 1-216-833-11 METAL CHIP 10K 5% 1/16W
R56 1-216-833-11 METAL CHIP 10K 5% 1/16W
R58 1-216-809-11 METAL CHIP 100 5% 1/16W
R59 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R60 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R61 1-216-809-11 METAL CHIP 100 5% 1/16W
R62 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R63 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R64 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R65 1-216-809-11 METAL CHIP 100 5% 1/16W
R66 1-216-833-11 METAL CHIP 10K 5% 1/16W
R67 1-216-833-11 METAL CHIP 10K 5% 1/16W
R68 1-216-821-11 METAL CHIP 1K 5% 1/16W
R69 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R111 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R112 1-216-841-11 METAL CHIP 47K 5% 1/16W
R113 1-216-837-11 METAL CHIP 22K 5% 1/16W
R114 1-216-849-11 METAL CHIP 220K 5% 1/16W
R115 1-216-837-11 METAL CHIP 22K 5% 1/16W
0 R121 1-215-891-11 METAL OXIDE 680 5% 2W
R122 1-216-821-11 METAL CHIP 1K 5% 1/16W
R124 1-216-837-11 METAL CHIP 22K 5% 1/16W
R141 1-216-821-11 METAL CHIP 1K 5% 1/16W
R142 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R143 1-216-817-11 METAL CHIP 470 5% 1/16W
0 R171 1-215-891-11 METAL OXIDE 680 5% 2W
R172 1-216-821-11 METAL CHIP 1K 5% 1/16W
R174 1-216-837-11 METAL CHIP 22K 5% 1/16W
R175 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R301 1-216-837-11 METAL CHIP 22K 5% 1/16W
R302 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R303 1-216-809-11 METAL CHIP 100 5% 1/16W
R304 1-216-809-11 METAL CHIP 100 5% 1/16W
R305 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R306 1-216-833-11 METAL CHIP 10K 5% 1/16W
R307 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R308 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R309 1-216-837-11 METAL CHIP 22K 5% 1/16W
R311 1-216-857-11 METAL CHIP 1M 5% 1/16W
R312 1-218-745-11 RES-CHIP 160K 5% 1/16W
R313 1-216-845-11 METAL CHIP 100K 5% 1/16W
R315 1-216-833-11 METAL CHIP 10K 5% 1/16W
R316 1-216-839-11 METAL CHIP 33K 5% 1/16W
R317 1-216-833-11 METAL CHIP 10K 5% 1/16W
R318 1-216-833-11 METAL CHIP 10K 5% 1/16W
R319 1-216-852-11 METAL CHIP 390K 5% 1/16W
R320 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R321 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R331 1-216-846-11 METAL CHIP 120K 5% 1/16W
R332 1-216-809-11 METAL CHIP 100 5% 1/16W
R333 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R334 1-218-332-11 RES-CHIP 130K 5% 1/16W
R335 1-216-813-11 METAL CHIP 220 5% 1/16W
R336 1-216-846-11 METAL CHIP 120K 5% 1/16W
R337 1-216-813-11 METAL CHIP 220 5% 1/16W
R338 1-216-837-11 METAL CHIP 22K 5% 1/16W
R339 1-216-834-11 METAL CHIP 12K 5% 1/16W
R340 1-216-850-11 METAL CHIP 270K 5% 1/16W
R341 1-216-813-11 METAL CHIP 220 5% 1/16W
R342 1-216-834-11 METAL CHIP 12K 5% 1/16W
0 R343 1-219-787-17 FUSIBLE 5.6 5% 1/4W
0 R344 1-219-787-17 FUSIBLE 5.6 5% 1/4W
R345 1-216-836-11 METAL CHIP 18K 5% 1/16W
R346 1-216-836-11 METAL CHIP 18K 5% 1/16W
R347 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R348 1-216-820-11 METAL CHIP 820 5% 1/16W
R349 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R351 1-216-837-11 METAL CHIP 22K 5% 1/16W
R352 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R353 1-216-809-11 METAL CHIP 100 5% 1/16W
R354 1-216-809-11 METAL CHIP 100 5% 1/16W
R355 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R356 1-216-833-11 METAL CHIP 10K 5% 1/16W
R357 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R358 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R359 1-216-839-11 METAL CHIP 33K 5% 1/16W
R360 1-216-821-11 METAL CHIP 1K 5% 1/16W
R361 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R362 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R363 1-216-821-11 METAL CHIP 1K 5% 1/16W
R364 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R365 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R366 1-216-841-11 METAL CHIP 47K 5% 1/16W
R367 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
