Sony HCD-DP900D - Electrical Parts List - RF-240 and Sensor Boards; RF-240 Board Capacitors List; RF-240 Board Connectors List; RF-240 Board Diodes List

87
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP900D
S1133 1-762-875-21 SWITCH, KEYBOARD (CLOCK/TIMER SET)
S1134 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM)
S1135 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S1136 1-762-875-21 SWITCH, KEYBOARD (TOOL MODE)
S1137 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S1138 1-762-875-21 SWITCH, KEYBOARD (MOVIE MODE)
S1139 1-762-875-21 SWITCH, KEYBOARD (MUSIC MODE)
S1140 1-762-875-21 SWITCH, KEYBOARD (DSP EDIT)
S1141 1-762-875-21 SWITCH, KEYBOARD (GAME MODE)
S1142 1-762-875-21 SWITCH, KEYBOARD (P FILE)
S1143 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S1144 1-762-875-21 SWITCH, KEYBOARD (EFFECT)
S1145 1-762-875-21 SWITCH, KEYBOARD (2CH/MULTI)
S1146 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
S1147 1-762-875-21 SWITCH, KEYBOARD (CD SYNC HI-DUB)
S1148 1-762-875-21 SWITCH, KEYBOARD (DVD MENU)
S1149 1-762-875-21 SWITCH, KEYBOARD (DVD TITLE)
< VIBRATOR >
X1101 1-795-054-51 VIBRATOR, CERAMIC (4MHz)
******************************************************
A-4726-861-A RF-240 BOARD, COMPLETE
********************
< CAPACITOR >
C001 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C002 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C005 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C006 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C007 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C008 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C009 1-124-779-00 ELECT CHIP 10uF 20% 16V
C015 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C016 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C017 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C018 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C019 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C021 1-124-779-00 ELECT CHIP 10uF 20% 16V
C022 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C023 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C024 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C026 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C027 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C028 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C033 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C034 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C036 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C038 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C039 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C040 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C043 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C044 1-124-779-00 ELECT CHIP 10uF 20% 16V
C046 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C048 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN001 1-766-835-21 CONNECTOR, FFC/FPC (ZIF) 26P
CN002 1-784-875-21 CONNECTOR,FFC(LIF(NON-ZIF))25P
CN003 1-784-861-21 CONNECTOR, FFC(LIF(NON-ZIF))9P
CN004 1-784-861-21 CONNECTOR, FFC(LIF(NON-ZIF))9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D004 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 8-759-828-02 IC SP3728AC
< COIL >
L001 1-412-031-11 INDUCTOR CHIP 47uH
L002 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
Q002 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
< RESISTOR >
R002 1-216-809-11 METAL CHIP 100 5% 1/16W
R003 1-216-809-11 METAL CHIP 100 5% 1/16W
R005 1-216-845-11 METAL CHIP 100K 5% 1/16W
R006 1-216-838-11 METAL CHIP 27K 5% 1/16W
R007 1-216-803-11 METAL CHIP 33 5% 1/16W
R008 1-216-803-11 METAL CHIP 33 5% 1/16W
R009 1-216-821-11 METAL CHIP 1K 5% 1/16W
R010 1-216-841-11 METAL CHIP 47K 5% 1/16W
R011 1-216-809-11 METAL CHIP 100 5% 1/16W
R020 1-216-803-11 METAL CHIP 33 5% 1/16W
R023 1-216-803-11 METAL CHIP 33 5% 1/16W
R025 1-216-841-11 METAL CHIP 47K 5% 1/16W
R029 1-216-809-11 METAL CHIP 100 5% 1/16W
R037 1-216-834-11 METAL CHIP 12K 5% 1/16W
R038 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R045 1-216-809-11 METAL CHIP 100 5% 1/16W
******************************************************
1-682-792-11 SENSOR BOARD
***********
< CAPACITOR >
C712 1-164-159-11 CERAMIC 0.1uF 50V
< TRANSISTOR >
Q711 8-729-029-66 TRANSISTOR RT1N141S-TP
Q712 8-729-921-53 TRANSISTOR PT483F1
< RESISTOR >
R711 1-249-417-11 CARBON 1K 5% 1/4W F
R712 1-249-417-11 CARBON 1K 5% 1/4W F
R713 1-249-429-11 CARBON 10K 5% 1/4W
R714 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (BU UP/DOWN)
******************************************************
RF-240 SENSOR
PANEL
