Sony HCD-DP900D - Electrical Parts List - Trans and Related Boards; Trans Board Parts List; Sub Trans Board Parts List; Video Board Parts List

88
Ref. No. Part No. Description Remarks
Ref. No. Part No. Description Remarks
HCD-DP900D
TRANS
R711 1-249-417-11 CARBON 1K 5% 1/4W F
R712 1-249-417-11 CARBON 1K 5% 1/4W F
R713 1-249-429-11 CARBON 10K 5% 1/4W
R714 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (BU UP/DOWN)
******************************************************
1-680-190-11 SUB TRANS BOARD
**************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
0 C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
C902 1-126-768-11 ELECT 2200uF 20% 16V
C903 1-126-933-11 ELECT 100uF 20% 16V
C904 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
* CN902 1-564-321-21 PIN, CONNECTOR 2P (MX,TH)
CN902 1-568-106-11 PIN, CONNECTOR 4P (E,SP,MY)
CN903 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE)3P
< DIODE >
D901 8-719-911-19 DIODE 1SS119-25
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-024-99 DIODE 11ES2-NTA2B
< FUSE >
0 F911 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (T3.15AL 250V)
(E,SP,MY,EA)
0 F912 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) (T4AL 250V)
(E,SP,MY,EA)
0 F913 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) (T4AL 250V) (TH)
0 F913 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
(E,SP,MY,MX,EA)
< IC >
IC901 8-759-158-62 IC TA78057S
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R902 1-249-429-11 CARBON 10K 5% 1/4W
R903 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-276-11 RELAY, POWER
< SWITCH >
0 S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(E,SP,MY,EA)
< TRANSFORMER >
0 T901 1-435-825-11 TRANSFORMER, POWER
******************************************************
A-4727-081-A SURROUND AMP BOARD, COMPLETE (SP,MY,
EA)
A-4727-093-A SURROUND AMP BOARD, COMPLETE (E,MX)
A-4727-104-A SURROUND AMP BOARD, COMPLETE (TH)
***************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C931 1-126-964-11 ELECT 10uF 20% 50V
C932 1-126-917-11 ELECT 3300uF 20% 6.3V
C933 1-126-964-11 ELECT 10uF 20% 50V
C934 1-126-935-11 ELECT 470uF 20% 10V
C935 1-126-964-11 ELECT 10uF 20% 50V
C936 1-126-917-11 ELECT 3300uF 20% 6.3V
C937 1-126-964-11 ELECT 10uF 20% 50V
C938 1-126-935-11 ELECT 470uF 20% 10V
C1071 1-136-153-00 FILM 0.01uF 5% 50V
C1072 1-136-153-00 FILM 0.01uF 5% 50V
C1073 1-137-844-11 ELECT 2200uF 20% 42V
(SP,MY,TH,EA)
C1073 1-137-838-11 ELECT 2200uF 20% 42V
(E,MX)
C1074 1-137-844-11 ELECT 2200uF 20% 42V
(SP,MY,TH,EA)
C1074 1-137-838-11 ELECT 2200uF 20% 42V
(E,MX)
< DIODE >
D933 8-719-050-84 DIODE RB441Q-40T-77
D934 8-719-050-84 DIODE RB441Q-40T-77
D1071 8-719-510-68 DIODE D5SBA204101
< IC >
IC931 8-759-039-69 IC UPC7805AHF
IC932 8-759-158-62 IC TA78057S
IC933 8-759-445-59 IC BA033T
IC934 8-759-445-59 IC BA033T
< TRANSISTOR >
Q931 8-729-030-19 TRANSISTOR 2SB1640
Q932 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R931 1-249-422-11 CARBON 2.7K 5% 1/4W F
R932 1-249-422-11 CARBON 2.7K 5% 1/4W F
R933 1-249-422-11 CARBON 2.7K 5% 1/4W F
R934 1-249-429-11 CARBON 10K 5% 1/4W
R1071 1-249-441-11 CARBON 100K 5% 1/4W
R1072 1-249-441-11 CARBON 100K 5% 1/4W
******************************************************
1-680-189-11 TRANS BOARD
***********
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C911 1-128-576-11 ELECT 100uF 20% 63V
C912 1-126-960-11 ELECT 1uF 20% 50V
SUB TRANS
SURROUND AMP
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ver 1.1 2002.03
