89
Ref. No. Part No. Description Remarks
Ref. No. Part No. Description Remarks
HCD-DP900D
C911 1-128-576-11 ELECT 100uF 20% 63V
C912 1-126-960-11 ELECT 1uF 20% 50V
C913 1-126-968-11 ELECT 100uF 20% 50V
C915 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN913 1-564-518-11 PLUG, CONNECTOR 3P
* CN914 1-564-525-11 PLUG, CONNECTOR 10P
* CN915 1-564-519-11 PLUG, CONNECTOR 4P
< DIODE >
D911 8-719-024-99 DIODE 11ES2-NTA2B
D912 8-719-983-88 DIODE MTZJ-T-72-33C
D913 8-719-118-56 DIODE RD4.7F-T7B1
< FUSE >
0 F916 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
0 F917 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
0 F918 1-533-472-11 FUSE, GLASS TUBE (DIA. 5) (T5AL 250V)
0 F919 1-533-472-11 FUSE, GLASS TUBE (DIA. 5) (T5AL 250V)
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
0 R911 1-219-124-11 FUSIBLE 0.68 5% 1/4W
R913 1-249-429-11 CARBON 10K 5% 1/4W
R914 1-249-429-11 CARBON 10K 5% 1/4W
R915 1-247-807-31 CARBON 100 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
< TRANSFORMER >
0 T911 1-437-509-11 TRANSFORMER, POWER
******************************************************
1-682-902-11 VIDEO BOARD
**********
< CONNECTOR >
CN601 1-779-274-11 CONNECTOR, FFC(LIF(NON-ZIF))6P
< DIODE >
D601 8-719-056-83 DIODE UDZ-TE-17-6.8B
D602 8-719-056-83 DIODE UDZ-TE-17-6.8B
D603 8-719-056-83 DIODE UDZ-TE-17-6.8B
D604 8-719-056-83 DIODE UDZ-TE-17-6.8B
D605 8-719-056-83 DIODE UDZ-TE-17-6.8B
D606 8-719-056-83 DIODE UDZ-TE-17-6.8B
< JACK >
J601 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
J602 1-537-943-11 TERMINAL, S (S VIDEO OUT)
******************************************************
*************
MISCELLANEOUS
*************
14 1-823-367-11 WIRE (FLAT TYPE) (9 CORE)
15 1-823-370-11 WIRE (FLAT TYPE) (6 CORE)
16 1-823-368-11 WIRE (FLAT TYPE) (25 CORE)
68 1-796-001-11 TOUCH PAD
102 1-773-042-11 WIRE (FLAT TYPE) (17 CORE)
103 1-757-419-11 WIRE (FLAT TYPE) (21 CORE)
104 1-757-420-11 WIRE (FLAT TYPE) (23 CORE)
105 1-823-369-11 WIRE (FLAT TYPE) (12 CORE)
0 110 1-777-071-81 CORD, POWER (SP,MY,EA)
0 110 1-791-901-11 CORD, POWER (E,MX,TH)
111 1-569-008-21 ADAPTOR, CONVERSION (SP,MY,EA)
155 1-454-887-32 SOLENOID, PLUNGER
161 X-3378-241-1 MOTOR ASSY
209 X-3378-241-1 MOTOR ASSY
259 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
0 277 8-820-144-06 OPTICAL PICK-UP KHM-240AAA (TYPE A)
0 277 A-6062-709-A SERVICE ASSY, KHM-270AAA (TYPE B)
283 1-823-621-11 CABLE, FLEXIBLE FLAT (26 CORE)
284 1-823-622-11 WIRE (FLAT TYPE) (9 CORE)
FL1101 1-518-722-11 INDICATOR TUBE, FLUORESCENT
M721 A-4672-826-A MOTOR ASSY
M961 1-763-072-11 FAN, DC
0 T911 1-437-509-11 TRANSFORMER, POWER
TRANS VIDEO
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ver 1.3 2003.01
