75
HCD-DZ110/DZ111/DZ120/DZ120K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R440 1-216-845-11 METAL CHIP 100K 5% 1/10W
(DZ120K)
R441 1-216-817-11 METAL CHIP 470 5% 1/10W
(DZ120K)
R442 1-216-837-11 METAL CHIP 22K 5% 1/10W
(DZ120K)
R443 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DZ120K)
R444 1-216-835-11 METAL CHIP 15K 5% 1/10W
(DZ120K)
R444 1-216-864-11 SHORT CHIP 0 (DZ110/DZ111/DZ120)
R445 1-216-864-11 SHORT CHIP 0 (DZ110/DZ111/DZ120)
R446 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ120K)
R470 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R471 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R472 1-216-819-11 METAL CHIP 680 5% 1/10W
R477 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R478 1-216-813-11 METAL CHIP 220 5% 1/10W
R479 1-216-864-11 SHORT CHIP 0
R480 1-216-804-11 METAL CHIP 39 5% 1/10W
R481 1-216-845-11 METAL CHIP 100K 5% 1/10W
R482 1-216-833-11 METAL CHIP 10K 5% 1/10W
R487 1-216-864-11 SHORT CHIP 0
R488 1-216-845-11 METAL CHIP 100K 5% 1/10W
R490 1-216-864-11 SHORT CHIP 0
R492 1-216-864-11 SHORT CHIP 0
R494 1-216-864-11 SHORT CHIP 0 (DZ120K)
R495 1-216-864-11 SHORT CHIP 0 (DZ110/DZ111/DZ120)
R496 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ120K)
R821 1-216-864-11 SHORT CHIP 0
R822 1-216-864-11 SHORT CHIP 0
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R853 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R854 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R855 1-216-821-11 METAL CHIP 1K 5% 1/10W
R856 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R857 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S800 1-418-725-51 ENCODER, ROTARY (12 TYPE)
(VOLUME,– +)
S802 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S803 1-762-875-21 SWITCH, KEYBOARD (.)
S804 1-762-875-21 SWITCH, KEYBOARD (X)
S805 1-762-875-21 SWITCH, KEYBOARD (x)
S806 1-762-875-21 SWITCH, KEYBOARD (>)
S807 1-762-875-21 SWITCH, KEYBOARD (A)
S808 1-762-875-21 SWITCH, KEYBOARD (H)
*************************************************************
✩ A-1144-739-A MAIN BOARD, COMPLETE (DZ110)
✩ A-1159-290-A MAIN BOARD, COMPLETE (DZ111)
✩ A-1159-302-A MAIN BOARD, COMPLETE (DZ120: US, CND)
✩ A-1159-317-A MAIN BOARD, COMPLETE (DZ120: AUS)
✩ A-1159-326-A MAIN BOARD, COMPLETE (DZ120K: KR)
✩ A-1159-334-A MAIN BOARD, COMPLETE (DZ120K: E3)
✩ A-1159-365-A MAIN BOARD, COMPLETE (DZ120K: MX, E32)
✩ A-1176-990-A MAIN BOARD, COMPLETE (DZ120: RU)
✩ A-1177-693-A MAIN BOARD, COMPLETE (DZ120K: RU)
✩ A-1177-742-A MAIN BOARD, COMPLETE (DZ120K: EA)
✩ A-1177-764-A MAIN BOARD, COMPLETE (DZ120K: SP, TW)
✩ A-1185-905-A MAIN BOARD, COMPLETE (DZ120K: E12)
✩ A-1185-912-A MAIN BOARD, COMPLETE (DZ120K: AR)
*********************
< CAPACITOR >
C501 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C504 1-126-947-11 ELECT 47uF 20% 35V
C505 1-126-947-11 ELECT 47uF 20% 35V
C506 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C508 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C509 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C511 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C512 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C513 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C517 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C525 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C570 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C571 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C572 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C580 1-104-656-11 ELECT 2200uF 20% 6.3V
C582 1-104-658-91 ELECT 100uF 20% 10V
C583 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C587 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C589 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C598 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C601 1-126-947-11 ELECT 47uF 20% 35V
C602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C603 1-104-658-91 ELECT 100uF 20% 10V
C712 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C716 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C762 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C798 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C799 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C855 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C856 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C875 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1102 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1105 1-126-947-11 ELECT 47uF 20% 35V
C1106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1109 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1110 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1112 1-126-947-11 ELECT 47uF 20% 35V
C1113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1114 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1115 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1117 1-126-795-11 ELECT 10uF 20% 50V
C1118 1-126-795-11 ELECT 10uF 20% 50V
C1119 1-126-795-11 ELECT 10uF 20% 50V
C1120 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
MAIN
✩ New part of EEP ROM (IC1103) on the MAIN board cannot be used.
Therefore, if the mounted MAIN board (A-1144-739-A, etc.) is replaced,
exchange new EEP ROM (IC1103) with that used before the replacement.
JACK
Ver. 1.3
