74
HCD-DZ110/DZ111/DZ120/DZ120K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C412 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C413 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C420 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C421 1-126-157-11 ELECT 10uF 20% 16V
C422 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C423 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C431 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C432 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C433 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C434 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C440 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(DZ120K)
C441 1-126-157-11 ELECT 10uF 20% 16V
(DZ120K)
C442 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(DZ120K)
C443 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(DZ120K)
C444 1-126-157-11 ELECT 10uF 20% 16V
(DZ120K)
C450 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(DZ110/DZ111/DZ120)
C460 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(DZ110/DZ111/DZ120)
C471 1-124-222-91 ELECT 22uF 20% 6.3V
C473 1-162-995-11 CERAMIC CHIP 0.022uF 50V
(DZ120K)
C490 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C493 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C819 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C820 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CNP802 1-779-550-21 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
< DIODE >
D433 8-719-988-61 DIODE 1SS355TE-17
D470 8-719-988-61 DIODE 1SS355TE-17
D490 6-501-193-01 DIODE 1SS355WTE-17 (DZ110/DZ111/DZ120)
D491 6-501-193-01 DIODE 1SS355WTE-17 (DZ110/DZ111/DZ120)
D496 6-501-193-01 DIODE 1SS355WTE-17
D497 6-501-193-01 DIODE 1SS355WTE-17
< FERRITE BEAD >
FB410 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB420 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB450 1-216-864-11 SHORT CHIP 0 (DZ110/DZ111/DZ120)
FB460 1-216-864-11 SHORT CHIP 0 (DZ110/DZ111/DZ120)
FB470 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB471 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB472 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB474 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB475 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB476 1-469-144-21 FERRITE, EMI (SMD) (2012) (DZ120K)
FB479 1-500-284-21 INDUCTOR, FERRITE BEAD
(DZ110/DZ111/DZ120)
< IC >
IC401 8-759-100-96 IC uPC4558G2
IC402 8-759-100-96 IC uPC4558G2
< JACK >
J401 1-819-878-11 JACK (AUDIO IN)
J402 1-819-878-11 JACK (PHONES)
< SHORT >
JR811 1-216-864-11 SHORT CHIP 0
JR813 1-216-864-11 SHORT CHIP 0
JR814 1-216-864-11 SHORT CHIP 0
JR815 1-216-864-11 SHORT CHIP 0
JR816 1-216-864-11 SHORT CHIP 0
JR817 1-216-864-11 SHORT CHIP 0
JR901 1-216-864-11 SHORT CHIP 0
JR902 1-216-864-11 SHORT CHIP 0
JR903 1-216-864-11 SHORT CHIP 0
JR904 1-216-864-11 SHORT CHIP 0
JR905 1-216-864-11 SHORT CHIP 0
JR907 1-216-864-11 SHORT CHIP 0
JR908 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q470 1-801-806-11 TRANSISTOR DTC144EKA
Q471 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q472 8-729-048-50 TRANSISTOR 2SK3018-T106
Q473 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q474 8-729-027-24 TRANSISTOR DTA114TKA-T146
Q475 1-801-806-11 TRANSISTOR DTC144EKA
Q476 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q477 8-729-027-23 TRANSISTOR DTA114EKA-T146 (DZ120K)
Q478 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (DZ120K)
< RESISTOR >
R401 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R402 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R403 1-216-821-11 METAL CHIP 1K 5% 1/10W
R404 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ120K)
R405 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ120K)
R410 1-216-845-11 METAL CHIP 100K 5% 1/10W
R411 1-216-817-11 METAL CHIP 470 5% 1/10W
R412 1-216-837-11 METAL CHIP 22K 5% 1/10W
R413 1-216-821-11 METAL CHIP 1K 5% 1/10W
R414 1-216-835-11 METAL CHIP 15K 5% 1/10W
R415 1-216-821-11 METAL CHIP 1K 5% 1/10W
R416 1-216-801-11 METAL CHIP 22 5% 1/10W
R420 1-216-845-11 METAL CHIP 100K 5% 1/10W
R421 1-216-817-11 METAL CHIP 470 5% 1/10W
R422 1-216-837-11 METAL CHIP 22K 5% 1/10W
R423 1-216-821-11 METAL CHIP 1K 5% 1/10W
R424 1-216-821-11 METAL CHIP 1K 5% 1/10W
R431 1-216-864-11 SHORT CHIP 0
R432 1-216-837-11 METAL CHIP 22K 5% 1/10W
R433 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R434 1-216-864-11 SHORT CHIP 0
R435 1-216-857-11 METAL CHIP 1M 5% 1/10W
JACK
Ver. 1.2
