HCD-DZ110/DZ111/DZ120/DZ120K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< COIL >
L201 1-469-525-91 INDUCTOR 10uH
L231 1-469-525-91 INDUCTOR 10uH
L300 1-469-525-91 INDUCTOR 10uH
L350 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q271 1-801-806-11 TRANSISTOR DTC144EKA
Q272 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q273 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q274 1-801-806-11 TRANSISTOR DTC144EKA
Q275 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q276 1-801-806-11 TRANSISTOR DTC144EKA
Q277 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q279 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q300 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q310 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q320 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q395 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q396 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R209 1-216-864-11 SHORT CHIP 0
R214 1-218-285-11 METAL CHIP 75 5% 1/10W
R215 1-218-285-11 METAL CHIP 75 5% 1/10W
R216 1-218-285-11 METAL CHIP 75 5% 1/10W
R225 1-218-285-11 METAL CHIP 75 5% 1/10W
R227 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R228 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R229 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R230 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R231 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R232 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R244 1-218-285-11 METAL CHIP 75 5% 1/10W
R245 1-218-285-11 METAL CHIP 75 5% 1/10W
R246 1-218-285-11 METAL CHIP 75 5% 1/10W
R247 1-216-864-11 SHORT CHIP 0
R248 1-216-864-11 SHORT CHIP 0
R249 1-216-864-11 SHORT CHIP 0
R250 1-216-864-11 SHORT CHIP 0
R251 1-216-864-11 SHORT CHIP 0
R271 1-216-821-11 METAL CHIP 1K 5% 1/10W
R272 1-216-841-11 METAL CHIP 47K 5% 1/10W
R273 1-216-849-11 METAL CHIP 220K 5% 1/10W
R274 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R275 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R276 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R277 1-216-821-11 METAL CHIP 1K 5% 1/10W
R278 1-216-837-11 METAL CHIP 22K 5% 1/10W
R279 1-216-815-11 METAL CHIP 330 5% 1/10W
R280 1-216-815-11 METAL CHIP 330 5% 1/10W
R281 1-216-815-11 METAL CHIP 330 5% 1/10W
R282 1-216-815-11 METAL CHIP 330 5% 1/10W
R284 1-216-833-11 METAL CHIP 10K 5% 1/10W
R285 1-216-833-11 METAL CHIP 10K 5% 1/10W
R286 1-216-821-11 METAL CHIP 1K 5% 1/10W
R301 1-216-821-11 METAL CHIP 1K 5% 1/10W
R302 1-216-821-11 METAL CHIP 1K 5% 1/10W
R310 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R311 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R312 1-216-833-11 METAL CHIP 10K 5% 1/10W
R313 1-216-841-11 METAL CHIP 47K 5% 1/10W
R314 1-216-841-11 METAL CHIP 47K 5% 1/10W
R316 1-216-833-11 METAL CHIP 10K 5% 1/10W
R320 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R321 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R322 1-216-833-11 METAL CHIP 10K 5% 1/10W
R323 1-216-841-11 METAL CHIP 47K 5% 1/10W
R324 1-216-841-11 METAL CHIP 47K 5% 1/10W
R326 1-216-833-11 METAL CHIP 10K 5% 1/10W
R331 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R332 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R335 1-216-841-11 METAL CHIP 47K 5% 1/10W
R336 1-216-841-11 METAL CHIP 47K 5% 1/10W
R338 1-216-833-11 METAL CHIP 10K 5% 1/10W
R339 1-216-841-11 METAL CHIP 47K 5% 1/10W
R340 1-216-841-11 METAL CHIP 47K 5% 1/10W
R341 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R342 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R345 1-216-841-11 METAL CHIP 47K 5% 1/10W
R346 1-216-841-11 METAL CHIP 47K 5% 1/10W
R348 1-216-833-11 METAL CHIP 10K 5% 1/10W
R349 1-216-841-11 METAL CHIP 47K 5% 1/10W
R350 1-216-841-11 METAL CHIP 47K 5% 1/10W
R351 1-216-845-11 METAL CHIP 100K 5% 1/10W
R352 1-216-845-11 METAL CHIP 100K 5% 1/10W
R353 1-216-841-11 METAL CHIP 47K 5% 1/10W
R355 1-216-817-11 METAL CHIP 470 5% 1/10W
R356 1-216-833-11 METAL CHIP 10K 5% 1/10W
R357 1-216-821-11 METAL CHIP 1K 5% 1/10W
R358 1-216-833-11 METAL CHIP 10K 5% 1/10W
R359 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R360 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R361 1-216-845-11 METAL CHIP 100K 5% 1/10W
R362 1-216-845-11 METAL CHIP 100K 5% 1/10W
R363 1-216-841-11 METAL CHIP 47K 5% 1/10W
R365 1-216-817-11 METAL CHIP 470 5% 1/10W
R366 1-216-864-11 SHORT CHIP 0
R367 1-216-864-11 SHORT CHIP 0
R399 1-216-821-11 METAL CHIP 1K 5% 1/10W
*************************************************************
A-1144-767-A JACK BOARD, COMPLETE
(DZ110/DZ111/DZ120)
A-1177-703-A JACK BOARD, COMPLETE (DZ120K)
*********************
< CAPACITOR >
C401 1-124-589-11 ELECT 47uF 20% 16V
C403 1-124-584-00 ELECT 100uF 20% 10V
C404 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C405 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C406 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
(DZ120K)
C410 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C411 1-126-157-11 ELECT 10uF 20% 16V
I/O SCART JACK
Ver. 1.3
