72
HCD-DZ110/DZ111/DZ120/DZ120K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R369 1-216-821-11 METAL CHIP 1K 5% 1/10W
R370 1-216-833-11 METAL CHIP 10K 5% 1/10W
R371 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ120K)
R374 1-216-841-11 METAL CHIP 47K 5% 1/10W
R375 1-216-821-11 METAL CHIP 1K 5% 1/10W
R376 1-216-864-11 SHORT CHIP 0
R377 1-216-841-11 METAL CHIP 47K 5% 1/10W
R378 1-216-841-11 METAL CHIP 47K 5% 1/10W
R380 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ120K)
R381 1-216-841-11 METAL CHIP 47K 5% 1/10W
R382 1-216-841-11 METAL CHIP 47K 5% 1/10W
R384 1-216-841-11 METAL CHIP 47K 5% 1/10W
R385 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R386 1-216-841-11 METAL CHIP 47K 5% 1/10W
R387 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
(DZ120K)
R388 1-215-865-11 METAL OXIDE 220 5% 1W
(DZ120K)
R391 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ120K)
R392 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ120K)
R393 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ120K)
R395 1-216-837-11 METAL CHIP 22K 5% 1/10W
(DZ120K)
R396 1-216-837-11 METAL CHIP 22K 5% 1/10W
(DZ120K)
R399 1-216-849-11 METAL CHIP 220K 5% 1/10W
(DZ120K)
*************************************************************
A-1146-119-A I/O SCART BOARD, COMPLETE (DZ110/DZ111)
*************************
< CAPACITOR >
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C202 1-126-925-91 ELECT 470uF 20% 10V
C203 1-126-933-11 ELECT 100uF 20% 16V
C204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C206 1-126-964-11 ELECT 10uF 20% 50V
C208 1-115-156-11 CERAMIC CHIP 1uF 10V
C209 1-115-156-11 CERAMIC CHIP 1uF 10V
C210 1-115-156-11 CERAMIC CHIP 1uF 10V
C214 1-126-916-11 ELECT 1000uF 20% 6.3V
C215 1-126-933-11 ELECT 100uF 20% 16V
C216 1-126-933-11 ELECT 100uF 20% 16V
C225 1-126-916-11 ELECT 1000uF 20% 6.3V
C231 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C232 1-126-933-11 ELECT 100uF 20% 16V
C233 1-126-933-11 ELECT 100uF 20% 16V
C234 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C238 1-115-156-11 CERAMIC CHIP 1uF 10V
C239 1-115-156-11 CERAMIC CHIP 1uF 10V
C240 1-115-156-11 CERAMIC CHIP 1uF 10V
C244 1-126-916-11 ELECT 1000uF 20% 6.3V
C245 1-126-916-11 ELECT 1000uF 20% 6.3V
C246 1-126-916-11 ELECT 1000uF 20% 6.3V
C271 1-126-933-11 ELECT 100uF 20% 16V
C295 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C296 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C303 1-126-947-11 ELECT 47uF 20% 35V
C304 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C305 1-126-933-11 ELECT 100uF 20% 16V
C306 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C310 1-104-662-91 ELECT 22uF 20% 25V
C311 1-104-662-91 ELECT 22uF 20% 25V
C320 1-104-662-91 ELECT 22uF 20% 25V
C321 1-104-662-91 ELECT 22uF 20% 25V
C331 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C332 1-104-662-91 ELECT 22uF 20% 25V
C333 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C334 1-104-662-91 ELECT 22uF 20% 25V
C341 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C342 1-104-662-91 ELECT 22uF 20% 25V
C343 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C344 1-104-662-91 ELECT 22uF 20% 25V
C351 1-104-662-91 ELECT 22uF 20% 25V
C352 1-104-662-91 ELECT 22uF 20% 25V
C354 1-126-960-11 ELECT 1uF 20% 50V
C355 1-126-933-11 ELECT 100uF 20% 16V
C356 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C358 1-126-933-11 ELECT 100uF 20% 16V
C359 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C361 1-104-662-91 ELECT 22uF 20% 25V
C362 1-104-662-91 ELECT 22uF 20% 25V
C364 1-126-960-11 ELECT 1uF 20% 50V
C365 1-104-662-91 ELECT 22uF 20% 25V
C366 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C389 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C390 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN201 1-779-550-21 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN301 1-794-194-51 CONNECTOR, FFC/FPC 13P
CN302 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
CN303 1-816-955-11 CONNECTOR, FFC/FPC 11P
CN304 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< DIODE >
D271 8-719-988-61 DIODE 1SS355TE-17
D272 8-719-988-61 DIODE 1SS355TE-17
D300 8-719-058-24 DIODE RB501V-40TE-17
< IC >
IC201 6-707-489-01 IC BH7868FS-E2
IC230 6-707-489-01 IC BH7868FS-E2
IC300 6-703-550-01 IC TA7809LS
IC350 8-759-385-76 IC MC14052 BDR2
IC360 8-759-100-96 IC uPC4558G2
< JACK >
J203 1-819-925-11 JACK, PIN 5P (COMPONENNT VIDEO OUT)
(AUDIO IN)(LINE)
J230 1-815-911-11 CONNECTOR, SQUARE TYPE 21P
(EURO AV T OUT PUT (TO TV))
I/O I/O SCART
Ver. 1.1
