HCD-DZ110/DZ111/DZ120/DZ120K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C380 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(DZ120K)
C381 1-126-957-91 ELECT 0.22uF 20% 50V
(DZ120K)
C382 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(DZ120K)
C383 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(DZ120K)
C397 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(DZ120K)
C399 1-126-933-91 ELECT 100uF 20% 16V
(DZ120K)
< CONNECTOR >
CN201 1-779-550-21 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN202 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN203 1-568-828-11 CONNECTOR, FFC 9P
CN311 1-794-506-51 CONNECTOR, FFC/FPC 13P
CN312 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P (DZ120)
CN312 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE) 6P (DZ120K)
< DIODE >
D211 8-719-988-61 DIODE 1SS355TE-17 (DZ120K)
D212 8-719-988-61 DIODE 1SS355TE-17 (DZ120K)
D221 8-719-988-61 DIODE 1SS355TE-17 (DZ120K)
D222 8-719-988-61 DIODE 1SS355TE-17 (DZ120K)
D310 8-719-069-54 DIODE UDZSTE-175.1B (DZ120K)
D352 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC201 6-705-602-01 IC MM1623BFBE
IC352 8-759-385-76 IC MC14052 BDR2
IC353 8-759-100-96 IC uPC4558G2
IC356 8-759-100-96 IC uPC4558G2 (DZ120K)
IC357 6-706-078-01 IC M62429FP-TP (DZ120K)
IC360 6-703-550-01 IC TA7809LS
< JACK >
J200 1-764-593-21 JACK 2P (TV/VCR)
J201 1-780-211-11 TERMINAL BOARD (S TERMINAL+1P)
(S VIDEO)(VIDEO)(MONITOR OUT)
J202 1-817-449-11 JACK, PIN 3P (Y,PB/CB,PR/CR)
(COMPONENT VIDEO OUT)
< SHORT >
JR361 1-216-864-11 SHORT CHIP 0 (DZ120K)
< COIL >
L201 1-469-525-91 INDUCTOR 10uH
L202 1-469-525-91 INDUCTOR 10uH
L352 1-469-525-91 INDUCTOR 10uH
L353 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q351 8-729-901-00 TRANSISTOR DTC124EK (DZ120K)
Q353 8-729-901-00 TRANSISTOR DTC124EK
Q354 8-729-901-00 TRANSISTOR DTC124EK
Q355 8-729-901-00 TRANSISTOR DTC124EK (DZ120K)
Q360 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q361 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q362 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R204 1-216-821-11 METAL CHIP 1K 5% 1/10W
R207 1-216-864-11 SHORT CHIP 0
R209 1-216-864-11 SHORT CHIP 0
R228 1-216-833-11 METAL CHIP 10K 5% 1/10W
R229 1-218-285-11 METAL CHIP 75 5% 1/10W
R230 1-218-285-11 METAL CHIP 75 5% 1/10W
R231 1-218-285-11 METAL CHIP 75 5% 1/10W
R232 1-218-285-11 METAL CHIP 75 5% 1/10W
R233 1-218-285-11 METAL CHIP 75 5% 1/10W
R234 1-216-809-11 METAL CHIP 100 5% 1/10W
R235 1-216-809-11 METAL CHIP 100 5% 1/10W
R241 1-218-285-11 METAL CHIP 75 5% 1/10W
R253 1-216-845-11 METAL CHIP 100K 5% 1/10W
R254 1-216-845-11 METAL CHIP 100K 5% 1/10W
R255 1-216-845-11 METAL CHIP 100K 5% 1/10W
R256 1-216-845-11 METAL CHIP 100K 5% 1/10W
R263 1-216-833-11 METAL CHIP 10K 5% 1/10W
R271 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R272 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R273 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R274 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R275 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R276 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R293 1-216-864-11 SHORT CHIP 0 (DZ120)
R294 1-216-864-11 SHORT CHIP 0 (DZ120K)
R330 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R331 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R334 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R335 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ120K)
R337 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ120K)
R340 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ120K)
R343 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R344 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R345 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ120K)
R346 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ120K)
R349 1-216-833-11 METAL CHIP 10K 5% 1/10W
R350 1-216-833-11 METAL CHIP 10K 5% 1/10W
R356 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R357 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R358 1-216-841-11 METAL CHIP 47K 5% 1/10W
R359 1-216-817-11 METAL CHIP 470 5% 1/10W
R360 1-216-817-11 METAL CHIP 470 5% 1/10W
R363 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R364 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R365 1-216-841-11 METAL CHIP 47K 5% 1/10W
R366 1-216-841-11 METAL CHIP 47K 5% 1/10W
R367 1-216-821-11 METAL CHIP 1K 5% 1/10W
R368 1-216-833-11 METAL CHIP 10K 5% 1/10W
