70
HCD-DZ110/DZ111/DZ120/DZ120K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< IC >
IC801 6-600-349-21 IC NJL23H400A
IC802 8-759-643-83 IC uPD16315GB-3BS
< TRANSISTOR >
Q450 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
(DZ110/DZ111/DZ120)
Q451 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
(DZ110/DZ111/DZ120)
Q460 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
(DZ110/DZ111/DZ120)
Q461 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
(DZ110/DZ111/DZ120)
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R436 1-216-834-11 METAL CHIP 12K 5% 1/10W
R437 1-216-835-11 METAL CHIP 15K 5% 1/10W
R450 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ110/DZ111/DZ120)
R451 1-216-801-11 METAL CHIP 22 5% 1/10W
(DZ110/DZ111/DZ120)
R452 1-216-805-11 METAL CHIP 47 5% 1/10W
(DZ110/DZ111/DZ120)
R453 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ110/DZ111/DZ120)
R454 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ110/DZ111/DZ120)
R460 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ110/DZ111/DZ120)
R461 1-216-801-11 METAL CHIP 22 5% 1/10W
(DZ110/DZ111/DZ120)
R462 1-216-805-11 METAL CHIP 47 5% 1/10W
(DZ110/DZ111/DZ120)
R463 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ110/DZ111/DZ120)
R464 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ110/DZ111/DZ120)
R800 1-216-821-11 METAL CHIP 1K 5% 1/10W
R811 1-216-844-11 METAL CHIP 82K 5% 1/10W
R812 1-216-845-11 METAL CHIP 100K 5% 1/10W
R813 1-216-845-11 METAL CHIP 100K 5% 1/10W
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-809-11 METAL CHIP 100 5% 1/10W
R816 1-216-809-11 METAL CHIP 100 5% 1/10W
R817 1-216-821-11 METAL CHIP 1K 5% 1/10W
R819 1-216-805-11 METAL CHIP 47 5% 1/10W
R820 1-216-845-11 METAL CHIP 100K 5% 1/10W
R823 1-216-864-11 SHORT CHIP 0
*************************************************************
A-1176-126-A I/O BOARD, COMPLETE (DZ120)
A-1177-714-A I/O BOARD, COMPLETE (DZ120K)
*******************
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-115-156-11 CERAMIC CHIP 1uF 10V
C203 1-115-156-11 CERAMIC CHIP 1uF 10V
C204 1-115-156-11 CERAMIC CHIP 1uF 10V
C205 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C210 1-126-925-91 ELECT 470uF 20% 10V
C212 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C213 1-126-933-11 ELECT 100uF 20% 16V
C214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C224 1-126-916-11 ELECT 1000uF 20% 6.3V
C225 1-126-916-11 ELECT 1000uF 20% 6.3V
C226 1-126-916-11 ELECT 1000uF 20% 6.3V
C227 1-126-933-11 ELECT 100uF 20% 16V
C228 1-126-933-11 ELECT 100uF 20% 16V
C234 1-126-933-11 ELECT 100uF 20% 16V
C235 1-104-662-91 ELECT 22uF 20% 25V
C236 1-104-662-91 ELECT 22uF 20% 25V
C239 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C242 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C333 1-126-933-11 ELECT 100uF 20% 16V
C334 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C336 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C337 1-104-662-91 ELECT 22uF 20% 25V
C338 1-126-933-11 ELECT 100uF 20% 16V
C339 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C340 1-104-662-91 ELECT 22uF 20% 25V
C341 1-104-662-91 ELECT 22uF 20% 25V
C342 1-104-662-91 ELECT 22uF 20% 25V
C345 1-126-796-11 ELECT 22uF 20% 50V
C346 1-126-796-11 ELECT 22uF 20% 50V
C348 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C349 1-126-796-11 ELECT 22uF 20% 50V
C350 1-104-662-91 ELECT 22uF 20% 25V
C351 1-126-947-11 ELECT 47uF 20% 35V
C352 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C354 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C355 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C356 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C357 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(DZ120K)
C358 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(DZ120K)
C359 1-126-960-11 ELECT 1uF 20% 50V
C360 1-126-960-11 ELECT 1uF 20% 50V
C362 1-104-662-91 ELECT 22uF 20% 25V
C363 1-104-662-91 ELECT 22uF 20% 25V
(DZ120K)
C374 1-126-960-11 ELECT 1uF 20% 50V
(DZ120K)
C375 1-126-960-11 ELECT 1uF 20% 50V
(DZ120K)
C376 1-126-933-91 ELECT 100uF 20% 16V
(DZ120K)
C377 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(DZ120K)
C378 1-126-957-91 ELECT 0.22uF 20% 50V
(DZ120K)
C379 1-126-933-91 ELECT 100uF 20% 16V
(DZ120K)
I/OFL
Ver. 1.3
