86
HCD-DZ110/DZ111/DZ120/DZ120K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< TRANSISTOR >
0 Q901 8-729-140-04 TRANSISTOR 2SD1616A-TP-LK
0 Q921 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
Q943 1-801-806-11 TRANSISTOR DTC144EKA
Q945 6-550-718-01 TRANSISTOR RSR025N03TL
Q947 1-801-806-11 TRANSISTOR DTC144EKA
< RESISTOR >
0 R901 1-219-759-11 METAL 1M 5% 1/2W
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 R902 1-219-769-11 METAL 3.3M 5% 1/2W
(DZ120: US, CND/DZ120K: MX, TW)
0 R903 1-215-926-00 METAL OXIDE 33K 5% 3W
(DZ120: US, CND/DZ120K: MX, TW)
0 R903 1-215-929-11 METAL OXIDE 100K 5% 3W
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 R904 1-215-926-00 METAL OXIDE 33K 5% 3W
(DZ120: US, CND/DZ120K: MX, TW)
0 R904 1-215-929-11 METAL OXIDE 100K 5% 3W
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 R905 1-216-797-11 METAL CHIP 10 5% 1/10W
0 R906 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
0 R907 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R908 1-260-105-11 CARBON 3.3K 5% 1/2W
0 R909 1-216-845-11 METAL CHIP 100K 5% 1/10W
0 R910 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R911 1-216-813-11 METAL CHIP 220 5% 1/10W
0 R912 1-216-361-61 METAL OXIDE 0.22 5% 2W
(DZ120: US, CND/DZ120K: MX, TW)
0 R912 1-216-363-00 METAL OXIDE 0.33 5% 2W
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 R913 1-216-361-61 METAL OXIDE 0.22 5% 2W
(DZ120: US, CND/DZ120K: MX, TW)
0 R914 1-219-718-11 METAL 0.1 10% 5W
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 R914 1-243-669-11 METAL 0.05 5% 5W
(DZ120: US, CND/DZ120K: MX, TW)
0 R919 1-216-836-11 METAL CHIP 18K 5% 1/10W
0 R922 1-216-793-11 METAL CHIP 4.7 5% 1/10W
0 R923 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0 R925 1-216-797-11 METAL CHIP 10 5% 1/10W
0 R926 1-216-855-11 METAL CHIP 680K 5% 1/10W
0 R927 1-216-348-00 METAL OXIDE 0.82 5% 1W
(DZ120: US, CND/DZ120K: MX, TW)
0 R927 1-216-349-00 METAL OXIDE 1 5% 1W
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 R929 1-249-478-11 CARBON 2.2 5% 1/2W
R931 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
(DZ120K: E32)
R931 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W
(EXCEPT DZ120K: E32)
R932 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R933 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R934 1-216-821-11 METAL CHIP 1K 5% 1/10W
R935 1-216-821-11 METAL CHIP 1K 5% 1/10W
R936 1-216-853-11 METAL CHIP 470K 5% 1/10W
R937 1-216-833-11 METAL CHIP 10K 5% 1/10W
R938 1-216-821-11 METAL CHIP 1K 5% 1/10W
R939 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W
R940 1-216-833-11 METAL CHIP 10K 5% 1/10W
R941 1-216-864-11 SHORT CHIP 0
R943 1-216-864-11 SHORT CHIP 0
R946 1-216-811-11 METAL CHIP 150 5% 1/10W
R948 1-216-833-11 METAL CHIP 10K 5% 1/10W
R949 1-216-821-11 METAL CHIP 1K 5% 1/10W
R951 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R952 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R953 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R954 1-216-837-11 METAL CHIP 22K 5% 1/10W
R955 1-216-817-11 METAL CHIP 470 5% 1/10W
R956 1-216-821-11 METAL CHIP 1K 5% 1/10W
R957 1-216-841-11 METAL CHIP 47K 5% 1/10W
R958 1-216-821-11 METAL CHIP 1K 5% 1/10W
R965 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R966 1-216-821-11 METAL CHIP 1K 5% 1/10W
R967 1-216-821-11 METAL CHIP 1K 5% 1/10W
0 R968 1-216-821-11 METAL CHIP 1K 5% 1/10W
R969 1-216-821-11 METAL CHIP 1K 5% 1/10W
R971 1-216-864-11 SHORT CHIP 0
R974 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
< TRANSFORMER >
0 T901 1-443-649-11 TRANSFORMER, CONVERTER
(DZ120: US, CND/DZ120K: MX, TW)
0 T901 1-443-874-11 TRANSFORMER, CONVERTER
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 T902 1-443-650-11 TRANSFORMER, CONVERTER
< THERMISTOR >
0 TH901 1-805-841-21 THERMISTOR, NTC 3.0
(DZ120: US, CND/DZ120K: E32, MX, TW)
0 TH901 1-805-842-21 THERMISTOR, NTC 6.0
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, RU, AR, EA)
< VARISTOR >
0 VDR901 1-805-482-11 VARISTOR
*************************************************************
SPEAKER BOARD
**************
< CAPACITOR >
C301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C303 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C304 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C305 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C306 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C307 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C308 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C309 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C310 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C311 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
POWER
Ver. 1.3
