87
HCD-DZ110/DZ111/DZ120/DZ120K
Ref. No. Part No. Description Remark
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C313 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C314 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C315 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C316 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C317 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C318 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C319 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C320 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C321 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C322 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C323 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C324 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
* CN301 1-564-519-11 PLUG, CONNECTOR 4P
CN302 1-818-651-11 PIN, CONNECTOR 2P
* CN303 1-564-521-11 PLUG, CONNECTOR 6P
< EARTH TERMINAL >
EP301 1-537-770-21 TERMINAL BOARD, GROUND
EP302 1-537-770-21 TERMINAL BOARD, GROUND
< TERMINAL >
TB301 1-780-344-11 TERMINAL BOARD (SPEAKER) 4P
TB302 1-780-343-11 TERMINAL BOARD (SPEAKER) 2P
*************************************************************
SW BOARD
*********
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (?/1)
*************************************************************
Ver. 1.3
MISCELLANEOUS
**************
3 1-693-700-11 TUNER (FM/AM) (TM10SCE) (DZ110/DZ111)
3 1-693-701-11 TUNER (FM/AM) (TM10SKR)
(DZ120: KR, RU/DZ120K: RU)
3 1-693-702-11 TUNER (FM/AM) (TM10SE)
(DZ120: AUS/EXCEPT DZ120K: RU)
3 1-693-703-11 TUNER (FM/AM) (TM10SU) (DZ120: US, CND)
8 1-828-952-11 WIRE (FLAT TYPE)(9 CORE)(DZ120/DZ120K)
8 1-828-962-11 WIRE (FLAT TYPE)(11 CORE)(DZ110/DZ111)
65 1-828-384-11 WIRE (FLAT TYPE)(23 CORE)
104 1-787-331-11 FAN, D.C.
0106 1-751-520-31 CORD, POWER (DZ111)
0106 1-769-079-23 CORD, POWER (DZ120: KR)
0106 1-777-071-22 CORD, POWER (DZ120K: E3, EA, RU)
0106 1-827-226-41 CORD, POWER (DZ120K: MX)
0106 1-827-597-41 CORD, POWER (DZ120K: TW)
0106 1-829-259-11 CORD, POWER (DZ120: AUS)
0106 1-829-387-11 CORD, POWER (DZ120K: AR)
0106 1-830-188-11 CORD, POWER
(DZ110/DZ120: RU/DZ120K: RU, E3, SP, E12, E32)
0106 1-830-190-11 CORD, POWER (DZ120: US, CND)
110 1-828-292-11 WIRE (FLAT TYPE)(5 CORE)
111 1-828-332-11 WIRE (FLAT TYPE)(13 CORE)
112 1-828-300-11 WIRE (FLAT TYPE)(7 CORE)
113 1-828-330-11 WIRE (FLAT TYPE)(13 CORE)
0507 8-820-290-02 DEVICE, OPTICAL KHM-310CAA/C2RP
0F901 1-532-325-00 FUSE (T6.3AL/250V)
(DZ110/DZ111/DZ120: RU, KR, AUS/
DZ120K: E3, SP, AR, RU, EA, E12)
0F901 1-532-749-11 FUSE, GLASS TUBE (8A/125V)
(DZ120: US, CND/DZ120K: MX, TW)
0F901 1-533-949-31 FUSE, CYLINDRICAL(TIME LUG)
(T8AL/250V) (DZ120K: E32)
Ref. No. Part No. Description Remark
