Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC709iP/EC909iP
48
A-1749-021-A PANEL BOARD, COMPLETE (EC909iP: US, CND)
A-1749-022-A PANEL BOARD, COMPLETE (EC909iP: AUS)
A-1749-023-A PANEL BOARD, COMPLETE (EC709iP: US, CND)
A-1749-024-A PANEL BOARD, COMPLETE (EC709iP: AUS)
*********************
2-649-178-01 PLATE, LIGHT GUIDE
2-649-179-01 SHEET (LCD)
2-665-175-01 SHEET (REFLECTOR)
< CAPACITOR >
C302 1-126-925-91 ELECT 470uF 20% 10V
C304 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C305 1-104-658-91 ELECT 100uF 20% 10V
C306 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C308 1-126-923-91 ELECT 220uF 20% 10V
C310 1-104-658-91 ELECT 100uF 20% 10V
C311 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C312 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C313 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C314 1-126-964-11 ELECT 10uF 20% 50V
C315 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C317 1-126-964-11 ELECT 10uF 20% 50V
C318 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C319 1-104-655-91 ELECT 470uF 20% 6.3V
C321 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C325 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C326 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C327 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C328 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C333 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C334 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C335 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C339 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C340 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C348 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C349 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
< CONNECTOR >
CN301 1-784-786-11 CONNECTOR, FFC 25P
CN302 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN303 1-784-766-11 CONNECTOR, FFC 5P
CN306 1-779-283-11 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
CN308 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
CN312 1-784-766-11 CONNECTOR, FFC 5P
< DIODE >
D303 6-502-773-01 LED SELG2WA10C LF62 (LCD BACKLIGHT)
(EC909iP)
D303 6-503-056-01 LED 1L0341Y23E0CA602-II (LCD BACKLIGHT)
(EC709iP)
D304 6-501-582-01 DIODE 1N4002-A2
D305 6-501-582-01 DIODE 1N4002-A2
D306 6-501-722-01 DIODE MAZ8043GMLS0
D307 6-501-719-01 DIODE MAZ8039GHLS0
D308 6-500-334-01 DIODE MC2836-T112-1
D309 6-501-817-01 DIODE MA2J1110GLS0
D310 6-501-817-01 DIODE MA2J1110GLS0
D311 6-501-582-01 DIODE 1N4002-A2
< IC >
IC301 A-1772-963-B IC MB90F830PF-GE1 (for SERVICE)
IC302 6-600-767-01 IC PNA4823M02S0
< JUMPER RESISTOR >
JR303 1-216-864-11 SHORT CHIP 0
JR304 1-216-864-11 SHORT CHIP 0
JR306 1-216-864-11 SHORT CHIP 0
JR307 1-216-864-11 SHORT CHIP 0
JR308 1-216-864-11 SHORT CHIP 0
JR309 1-216-864-11 SHORT CHIP 0
< LIQUID CRYSTAL DISPLAY >
LCD301 1-802-840-11 DISPLAY PANEL, LIQUID CRYSTAL (EC709iP)
LCD301 1-802-841-12 DISPLAY PANEL, LIQUID CRYSTAL (EC909iP)
< TRANSISTOR >
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q302 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q303 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q305 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q306 8-729-037-13 TRANSISTOR KTA1271Y
Q308 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q309 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q310 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R301 1-216-809-11 METAL CHIP 100 5% 1/10W
R302 1-216-809-11 METAL CHIP 100 5% 1/10W
R303 1-216-809-11 METAL CHIP 100 5% 1/10W
R304 1-216-809-11 METAL CHIP 100 5% 1/10W
R305 1-216-809-11 METAL CHIP 100 5% 1/10W
R306 1-216-809-11 METAL CHIP 100 5% 1/10W
R307 1-216-809-11 METAL CHIP 100 5% 1/10W
R308 1-216-809-11 METAL CHIP 100 5% 1/10W
R309 1-216-809-11 METAL CHIP 100 5% 1/10W
R310 1-216-809-11 METAL CHIP 100 5% 1/10W
R313 1-216-864-11 SHORT CHIP 0
R314 1-216-809-11 METAL CHIP 100 5% 1/10W
R315 1-216-809-11 METAL CHIP 100 5% 1/10W
R316 1-216-809-11 METAL CHIP 100 5% 1/10W
R317 1-216-809-11 METAL CHIP 100 5% 1/10W
R318 1-216-809-11 METAL CHIP 100 5% 1/10W
R319 1-216-809-11 METAL CHIP 100 5% 1/10W
R320 1-216-809-11 METAL CHIP 100 5% 1/10W
R322 1-216-809-11 METAL CHIP 100 5% 1/10W
R323 1-216-809-11 METAL CHIP 100 5% 1/10W
R326 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
(EC909iP)
R328 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R329 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R330 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R331 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R332 1-216-845-11 METAL CHIP 100K 5% 1/10W
R333 1-216-837-11 METAL CHIP 22K 5% 1/10W
R334 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R335 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R336 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
PANEL
