Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC709iP/EC909iP
4949
R337 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R340 1-216-833-11 METAL CHIP 10K 5% 1/10W
R341 1-216-797-11 METAL CHIP 10 5% 1/10W
R342 1-216-809-11 METAL CHIP 100 5% 1/10W
R343 1-216-809-11 METAL CHIP 100 5% 1/10W
R344 1-216-833-11 METAL CHIP 10K 5% 1/10W
R345 1-216-833-11 METAL CHIP 10K 5% 1/10W
R346 1-216-821-11 METAL CHIP 1K 5% 1/10W
R347 1-216-821-11 METAL CHIP 1K 5% 1/10W
R349 1-216-837-11 METAL CHIP 22K 5% 1/10W
R350 1-216-821-11 METAL CHIP 1K 5% 1/10W
R351 1-249-403-11 CARBON 68 5% 1/4W
R352 1-249-403-11 CARBON 68 5% 1/4W
R353 1-249-403-11 CARBON 68 5% 1/4W
R355 1-216-821-11 METAL CHIP 1K 5% 1/10W
R356 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R357 1-216-819-11 METAL CHIP 680 5% 1/10W
R358 1-216-833-11 METAL CHIP 10K 5% 1/10W
R359 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R360 1-216-809-11 METAL CHIP 100 5% 1/10W
R363 1-216-845-11 METAL CHIP 100K 5% 1/10W
R364 1-216-833-11 METAL CHIP 10K 5% 1/10W
R365 1-216-845-11 METAL CHIP 100K 5% 1/10W
R368 1-216-809-11 METAL CHIP 100 5% 1/10W
R369 1-216-809-11 METAL CHIP 100 5% 1/10W
R370 1-216-809-11 METAL CHIP 100 5% 1/10W
R371 1-216-809-11 METAL CHIP 100 5% 1/10W
R378 1-216-843-11 METAL CHIP 68K 5% 1/10W
R379 1-216-839-11 METAL CHIP 33K 5% 1/10W
R380 1-216-839-11 METAL CHIP 33K 5% 1/10W
R382 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R383 1-216-833-11 METAL CHIP 10K 5% 1/10W
R384 1-216-837-11 METAL CHIP 22K 5% 1/10W
R385 1-216-833-11 METAL CHIP 10K 5% 1/10W
R386 1-216-837-11 METAL CHIP 22K 5% 1/10W
R387 1-216-805-11 METAL CHIP 47 5% 1/10W
R389 1-216-821-11 METAL CHIP 1K 5% 1/10W
R390 1-216-833-11 METAL CHIP 10K 5% 1/10W
R391 1-216-813-11 METAL CHIP 220 5% 1/10W
R392 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R393 1-216-817-11 METAL CHIP 470 5% 1/10W
R394 1-216-821-11 METAL CHIP 1K 5% 1/10W
R395 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC909iP)
R396 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EC709iP)
R397 1-216-851-11 METAL CHIP 330K 5% 1/10W
R398 1-216-833-11 METAL CHIP 10K 5% 1/10W
R399 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC709iP: AUS/EC909iP: AUS)
R401 1-216-833-11 METAL CHIP 10K 5% 1/10W
R403 1-216-833-11 METAL CHIP 10K 5% 1/10W
R404 1-216-845-11 METAL CHIP 100K 5% 1/10W
R405 1-216-838-11 METAL CHIP 27K 5% 1/10W
R406 1-216-833-11 METAL CHIP 10K 5% 1/10W
R407 1-216-833-11 METAL CHIP 10K 5% 1/10W
R408 1-216-833-11 METAL CHIP 10K 5% 1/10W
R409 1-216-821-11 METAL CHIP 1K 5% 1/10W
R410 1-216-845-11 METAL CHIP 100K 5% 1/10W
R412 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S301 1-762-875-21 SWITCH, KEYBOARD (I/1) (EC909iP)
S302 1-762-875-21 SWITCH, KEYBOARD (I/1) (EC709iP)
S304 1-786-417-11 ENCODER, ROTARY (VOLUME)
S310 1-762-875-21 SWITCH, KEYBOARD (x)
S311 1-762-875-21 SWITCH, KEYBOARD (– TUNING, l m)
S312 1-762-875-21 SWITCH, KEYBOARD (u)
S313 1-762-875-21 SWITCH, KEYBOARD (FOLDER –)
S314 1-762-875-21 SWITCH, KEYBOARD (FUNCTION) (EC709iP)
S314 1-762-875-21 SWITCH, KEYBOARD (SUBWOOFER ON/OFF)
(EC909iP)
S315 1-762-875-21 SWITCH, KEYBOARD (FUNCTION) (EC909iP)
S320 1-762-875-21 SWITCH, KEYBOARD (CD)
S321 1-762-875-21 SWITCH, KEYBOARD (iPod & iPhone)
S322 1-762-875-21 SWITCH, KEYBOARD (FOLDER +)
S323 1-762-875-21 SWITCH, KEYBOARD (TUNING +, M L)
S324 1-762-875-21 SWITCH, KEYBOARD (DSGX)
< VIBRATOR >
X301 1-814-067-11 OSCILLATOR, CRYSTAL (32.768kHz)
X302 1-813-548-31 VIBRATOR, CERAMIC (6MHz)
*************************************************************
POWER BOARD
************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C001 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C051 1-126-923-91 ELECT 220uF 20% 10V
C052 1-126-963-11 ELECT 4.7uF 20% 50V
C053 1-126-964-11 ELECT 10uF 20% 50V
C071 1-104-662-91 ELECT 22uF 20% 25V
C072 1-126-960-11 ELECT 1uF 20% 50V
C073 1-126-947-11 ELECT 47uF 20% 35V
C101 1-130-777-00 MYLAR 0.1uF 5% 100V
C102 1-130-777-00 MYLAR 0.1uF 5% 100V
C103 1-126-974-11 ELECT 3300uF 20% 50V
C104 1-126-974-11 ELECT 3300uF 20% 50V
C105 1-126-943-11 ELECT 2200uF 20% 25V
C106 1-126-942-61 ELECT 1000uF 20% 25V
C107 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C108 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C109 1-104-658-91 ELECT 100uF 20% 10V
C110 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C111 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C112 1-126-963-11 ELECT 4.7uF 20% 50V
C113 1-126-962-11 ELECT 3.3uF 20% 50V
C114 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C151 1-126-964-11 ELECT 10uF 20% 50V
C152 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C153 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C154 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C156 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C157 1-126-935-11 ELECT 470uF 20% 16V
C158 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C159 1-126-925-91 ELECT 470uF 20% 10V
C160 1-127-804-91 CERAMIC CHIP 100PF 1% 50V
C161 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C162 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
PANEL POWER
