14
HCD-EP404
Adjustment Location and Connecting Points
– MAIN BOARD (Component Side) –
L104
}
AM Tracking
TC102 Adjustment
TC102
}
FM Tracking
L102 Adjustment
L103 FM Frequency
Coverage Adjustment
T101 AM Frequency
Coverage Adjustment
IC101
– MAIN BOARD (Conductor Side) –
TP(AM VT)
TP
(FM VT)
