Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
35
SECTION 8
ELECTRICAL PARTS LIST
HCD-EP404
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
A-4729-697-A DISPLAY BOARD, COMPLETE
***********************
4-240-243-01 LCD LIGHT GUIDE
4-240-252-01 REMOTE SENSOR HOLDER
4-240-253-01 TIMER LED HOLDER
4-240-254-01 LCD BACKLITE HOLDER
4-240-277-01 LCD DIFFUSE SHEET
4-241-111-01 REC.KNOB LED HOLDER
7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S
< CAPACITOR >
C306 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C307 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C308 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C309 1-126-514-11 ELECT 22uF 20.00% 10V
C310 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C311 1-115-870-11 ELECT 0.47uF 20.00% 50V
C312 1-126-382-11 ELECT 100uF 20.00% 10V
C313 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C314 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C324 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C325 1-126-934-11 ELECT 220uF 20.00% 10V
C326 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C327 1-164-159-11 CERAMIC 0.1uF 50V
C328 1-115-871-11 ELECT 1uF 20.00% 50V
C332 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C333 1-164-159-11 CERAMIC 0.1uF 50V
C335 1-164-159-11 CERAMIC 0.1uF 50V
C336 1-164-159-11 CERAMIC 0.1uF 50V
C337 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C338 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C339 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C340 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C341 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C342 1-162-288-31 CERAMIC 330PF 10% 50V
C343 1-162-288-31 CERAMIC 330PF 10% 50V
< LIQUID CRYSTAL DISPLAY >
CN301 1-804-496-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
D302 8-719-991-33 DIODE 1N4148TP
D303 8-719-991-33 DIODE 1N4148TP
D305 8-719-991-33 DIODE 1N4148TP
D308 8-719-991-33 DIODE 1N4148TP
D309 8-719-991-33 DIODE 1N4148TP
D310 8-719-991-33 DIODE 1N4148TP
D312 8-719-062-11 DIODE SEL2215S-CD (TIMER)
D313 8-719-062-11 DIODE SEL2215S-CD (z)
D316 8-719-991-33 DIODE 1N4148TP
D317 8-719-991-33 DIODE 1N4148TP
D901 8-719-812-44 DIODE SEL2910D (LCD BACK LIGHT)
D902 8-719-812-44 DIODE SEL2910D (LCD BACK LIGHT)
D903 8-719-812-44 DIODE SEL2910D (LCD BACK LIGHT)
< IC >
IC301 6-801-965-01 IC uPD780306GC-A68-8EU
IC302 8-759-251-04 IC ST24C02AB1
IC304 8-759-971-11 IC PST529D
< JUMPER RESISTOR >
J306 1-216-864-11 METAL CHIP 0 5% 1/16W
J340 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L301 1-410-525-11 INDUCTOR 220uH
< TRANSISTOR >
Q301 8-729-281-53 TRANSISTOR 2SC536NP-F
Q304 8-729-281-53 TRANSISTOR 2SC536NP-F
Q305 8-729-281-53 TRANSISTOR 2SC536NP-F
Q306 8-729-281-53 TRANSISTOR 2SC536NP-F
< RESISTOR >
R301 1-216-833-11 METAL CHIP 10K 5% 1/16W
R302 1-216-833-11 METAL CHIP 10K 5% 1/16W
R303 1-216-073-91 RES-CHIP 10K 5% 1/10W
R304 1-216-833-11 METAL CHIP 10K 5% 1/16W
R305 1-216-833-11 METAL CHIP 10K 5% 1/16W
R306 1-249-417-11 CARBON 1K 5% 1/4W F
R307 1-249-418-11 CARBON 1.2K 5% 1/4W F
R308 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R309 1-216-837-11 METAL CHIP 22K 5% 1/16W
R310 1-216-821-11 METAL CHIP 1K 5% 1/16W
R311 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R312 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R313 1-216-821-11 METAL CHIP 1K 5% 1/16W
R314 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R315 1-216-821-11 METAL CHIP 1K 5% 1/16W
R316 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R317 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R318 1-249-426-11 CARBON 5.6K 5% 1/4W
R319 1-216-845-11 METAL CHIP 100K 5% 1/16W
R320 1-216-821-11 METAL CHIP 1K 5% 1/16W
DISPLAY
