Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
36
HCD-EP404
DISPLAY
R321 1-216-821-11 METAL CHIP 1K 5% 1/16W
R322 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R323 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R324 1-249-409-11 CARBON 220 5% 1/4W F
R325 1-216-849-11 METAL CHIP 220K 5% 1/16W
R326 1-216-821-11 METAL CHIP 1K 5% 1/16W
R327 1-216-837-11 METAL CHIP 22K 5% 1/16W
R328 1-216-815-11 METAL CHIP 330 5% 1/16W
R329 1-216-837-11 METAL CHIP 22K 5% 1/16W
R330 1-216-857-11 METAL CHIP 1M 5% 1/16W
R331 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R332 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R335 1-249-417-11 CARBON 1K 5% 1/4W F
R336 1-216-049-11 RES-CHIP 1K 5% 1/10W
R337 1-249-417-11 CARBON 1K 5% 1/4W F
R338 1-247-887-00 CARBON 220K 5% 1/4W
R339 1-216-841-11 METAL CHIP 47K 5% 1/16W
R340 1-249-437-11 CARBON 47K 5% 1/4W
R341 1-249-429-11 CARBON 10K 5% 1/4W
R342 1-249-429-11 CARBON 10K 5% 1/4W
R345 1-249-417-11 CARBON 1K 5% 1/4W F
R346 1-249-417-11 CARBON 1K 5% 1/4W F
R347 1-249-417-11 CARBON 1K 5% 1/4W F
R351 1-216-821-11 METAL CHIP 1K 5% 1/16W
R352 1-216-821-11 METAL CHIP 1K 5% 1/16W
R353 1-216-837-11 METAL CHIP 22K 5% 1/16W
R354 1-216-821-11 METAL CHIP 1K 5% 1/16W
R355 1-249-417-11 CARBON 1K 5% 1/4W F
R356 1-249-417-11 CARBON 1K 5% 1/4W F
R357 1-216-841-11 METAL CHIP 47K 5% 1/16W
R358 1-216-821-11 METAL CHIP 1K 5% 1/16W
R360 1-216-821-11 METAL CHIP 1K 5% 1/16W
R361 1-249-417-11 CARBON 1K 5% 1/4W F
R363 1-216-821-11 METAL CHIP 1K 5% 1/16W
R364 1-216-845-11 METAL CHIP 100K 5% 1/16W
R365 1-216-845-11 METAL CHIP 100K 5% 1/16W
R366 1-216-845-11 METAL CHIP 100K 5% 1/16W
R368 1-216-821-11 METAL CHIP 1K 5% 1/16W
R369 1-216-049-11 RES-CHIP 1K 5% 1/10W
R370 1-216-049-11 RES-CHIP 1K 5% 1/10W
R372 1-216-821-11 METAL CHIP 1K 5% 1/16W
R373 1-216-837-11 METAL CHIP 22K 5% 1/16W
R374 1-216-841-11 METAL CHIP 47K 5% 1/16W
R375 1-216-841-11 METAL CHIP 47K 5% 1/16W
R378 1-249-429-11 CARBON 10K 5% 1/4W
R379 1-249-417-11 CARBON 1K 5% 1/4W F
R380 1-249-433-11 CARBON 22K 5% 1/4W
R381 1-216-864-11 METAL CHIP 0 5% 1/16W
R382 1-216-849-11 METAL CHIP 220K 5% 1/16W
R384 1-249-429-11 CARBON 10K 5% 1/4W
R385 1-216-864-11 METAL CHIP 0 5% 1/16W
R386 1-216-073-91 RES-CHIP 10K 5% 1/10W
R387 1-216-821-11 METAL CHIP 1K 5% 1/16W
R388 1-216-841-11 METAL CHIP 47K 5% 1/16W
R389 1-216-833-11 METAL CHIP 10K 5% 1/16W
R391 1-249-417-11 CARBON 1K 5% 1/4W F
R392 1-249-417-11 CARBON 1K 5% 1/4W F
R395 1-216-864-11 METAL CHIP 0 5% 1/16W
R396 1-249-417-11 CARBON 1K 5% 1/4W F
R397 1-249-417-11 CARBON 1K 5% 1/4W F
R398 1-249-417-11 CARBON 1K 5% 1/4W F
R399 1-249-417-11 CARBON 1K 5% 1/4W F
< JUMPER RESISTOR>
RJ312 1-216-295-91 SHORT 0
RJ319 1-216-295-91 SHORT 0
RJ320 1-216-864-11 METAL CHIP 0 5% 1/16W
RJ326 1-216-864-11 METAL CHIP 0 5% 1/16W
RJ351 1-216-864-11 METAL CHIP 0 5% 1/16W
RJ356 1-216-295-91 SHORT 0
RJ361 1-216-295-91 SHORT 0
RJ362 1-216-295-91 SHORT 0
< SWITCH >
SW301 1-570-472-11 SWITCH, KEY BOARD (?/1)
SW302 1-570-472-11 SWITCH, KEY BOARD (TUNER)
SW303 1-570-472-11 SWITCH, KEY BOARD (TAPE)
SW304 1-570-472-11 SWITCH, KEY BOARD (CD)
SW305 1-570-472-11 SWITCH, KEY BOARD (PLAY MODE)
SW306 1-570-472-11 SWITCH, KEY BOARD (x)
SW307 1-570-472-11 SWITCH, KEY BOARD (X)
SW308 1-570-472-11 SWITCH, KEY BOARD (N)
SW309 1-570-472-11 SWITCH, KEY BOARD (TUNER MEM/ENTER)
SW310 1-570-472-11 SWITCH, KEY BOARD (PRESET-)
SW311 1-570-472-11 SWITCH, KEY BOARD (PRESET+)
SW312 1-570-472-11 SWITCH, KEY BOARD (DISPLAY)
SW313 1-554-088-00 SWITCH, KEY BOARD (TUNING- .m)
SW314 1-554-088-00 SWITCH, KEY BOARD (TUNING+ M>)
SW315 1-570-472-11 SWITCH, KEY BOARD (MUSIC MENU)
SW316 1-570-472-11 SWITCH, KEY BOARD (MEGA BASS)
SW317 1-570-472-11 SWITCH, KEY BOARD (z)
< VIBRATOR >
X301 1-795-436-11 VIBRATOR, CRYSTAL 4.19MHz
< IC >
X302 6-600-092-01 IC RPM7138-V4
< ENCODER >
X303 1-476-916-11 ENCODER (VOLUME)
**************************************************************
A-4729-694-A HEADPHONE BOARD, COMPLETE
***************************
< JACK >
JK501 1-815-813-11 JACK (LARGE TYPE) (PHONES)
< RESISTOR >
R501 1-249-410-11 CARBON 270 5% 1/4W F
R502 1-249-410-11 CARBON 270 5% 1/4W F
**************************************************************
HEADPONE
