Sony HCD-EP404 - Page 38

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
38
HCD-EP404
MAIN
C615 1-104-665-11 ELECT 100uF 20.00% 25V
C616 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C617 1-126-933-11 ELECT 100uF 20.00% 16V
C618 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C619 1-126-933-11 ELECT 100uF 20.00% 16V
C620 1-126-933-11 ELECT 100uF 20.00% 16V
C621 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C625 1-104-665-11 ELECT 100uF 20.00% 25V
C626 1-126-934-11 ELECT 220uF 20.00% 16V
C627 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C701 1-163-255-11 CERAMIC CHIP 150PF 5.00% 50V
C702 1-163-255-11 CERAMIC CHIP 150PF 5.00% 50V
C703 1-130-472-00 MYLAR 0.0012uF 5% 50V
C704 1-130-472-00 MYLAR 0.0012uF 5% 50V
C705 1-126-960-11 ELECT 1uF 20.00% 50V
C706 1-126-960-11 ELECT 1uF 20.00% 50V
C707 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C708 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C709 1-126-963-11 ELECT 4.7uF 20.00% 50V
C710 1-126-963-11 ELECT 4.7uF 20.00% 50V
C711 1-126-934-11 ELECT 220uF 20.00% 16V
C712 1-126-934-11 ELECT 220uF 20.00% 16V
C713 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C714 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C715 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C716 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C717 1-126-963-11 ELECT 4.7uF 20.00% 50V
C718 1-126-963-11 ELECT 4.7uF 20.00% 50V
C723 1-130-496-00 MYLAR 0.12uF 5% 50V
C724 1-130-496-00 MYLAR 0.12uF 5% 50V
C725 1-104-760-11 CERAMIC CHIP 0.047uF 10.00% 50V
C726 1-104-760-11 CERAMIC CHIP 0.047uF 10.00% 50V
C727 1-126-956-91 ELECT 0.1uF 20.00% 50V
C728 1-126-956-91 ELECT 0.1uF 20.00% 50V
C729 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C730 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C733 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C734 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C735 1-163-255-11 CERAMIC CHIP 150PF 5.00% 50V
C736 1-163-255-11 CERAMIC CHIP 150PF 5.00% 50V
C737 1-126-934-11 ELECT 220uF 20.00% 16V
C738 1-126-947-11 ELECT 47uF 20.00% 16V
C739 1-126-933-11 ELECT 100uF 20.00% 16V
C740 1-126-934-11 ELECT 220uF 20.00% 16V
C741 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C742 1-126-964-11 ELECT 10uF 20.00% 50V
C743 1-136-967-11 MYLAR 0.012uF 5.00% 50V
C744 1-130-483-00 MYLAR 0.01uF 5% 50V
C745 1-130-471-00 MYLAR 0.001uF 5% 50V
C746 1-130-471-00 MYLAR 0.001uF 5% 50V
C747 1-126-933-11 ELECT 100uF 20.00% 16V
C748 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C750 1-126-934-11 ELECT 220uF 20.00% 16V
C751 1-126-933-11 ELECT 100uF 20.00% 16V
C752 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C753 1-126-934-11 ELECT 220uF 20.00% 16V
C755 1-126-934-11 ELECT 220uF 20.00% 16V
C756 1-126-960-11 ELECT 1uF 20.00% 50V
C757 1-126-960-11 ELECT 1uF 20.00% 50V
C758 1-126-960-11 ELECT 1uF 20.00% 50V
C759 1-126-960-11 ELECT 1uF 20.00% 50V
C766 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C767 1-126-934-11 ELECT 220uF 20.00% 16V
C768 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C781 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C782 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C783 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C784 1-162-979-11 CERAMIC CHIP 0.0027uF 10.00% 50V
C785 1-162-979-11 CERAMIC CHIP 0.0027uF 10.00% 50V
C786 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
< CONNECTOR >
* CN401 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P
* CN402 1-564-713-11 PIN, CONNECTOR (SMALL TYPE)11P
* CN601 1-565-731-11 PLUG, CONNECTOR (2.5mm) 5P
* CN701 1-564-709-11 PIN, CONNECTOR (SMALL TYPE) 7P
* CN704 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P
* CN705 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D102 8-719-991-33 DIODE 1SS133T-77
D103 8-719-070-77 DIODE SVC201SPA-M1-AC
D104 8-719-070-77 DIODE SVC201SPA-M1-AC
D105 8-719-085-35 DIODE SVC348T
D107 8-719-991-33 DIODE 1SS133T-77
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D403 8-719-991-33 DIODE 1SS133T-77
D404 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D601 8-719-991-33 DIODE 1SS133T-77
D604 8-719-991-33 DIODE 1SS133T-77
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-991-33 DIODE 1SS133T-77
D703 8-719-991-33 DIODE 1SS133T-77
D704 8-719-991-33 DIODE 1SS133T-77
D706 8-719-991-33 DIODE 1SS133T-77
< FILTER >
F101 1-234-704-11 FILTER, BAND PASS (FM)
F102 1-760-393-11 FILTER, CERAMIC
F103 1-795-397-11 FILTER, CERAMIC
< IC >
IC101 6-700-580-01 IC LA1823
IC102 8-759-584-70 IC LC72131
IC401 8-759-473-59 IC LC75392
IC601 8-759-803-29 IC LA4270
IC602 8-759-701-59 IC NJM7809FA
IC603 8-759-231-58 IC NJM7812A
IC701 8-759-079-42 IC uPC1330HA-NA
IC702 6-700-579-01 IC AN7312
