Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
41
HCD-EP404
POWER
< TERMINAL >
SPK601 1-537-238-11 TERMINAL BOARD (SPEAKER)
< COIL >
T101 1-424-877-11 COIL (AM OSC)
T102 1-424-876-11 COIL (AM)
T701 1-424-933-11 COIL (BIAS)
< TRIMMER >
TC101 1-141-304-21 CAP, TRIMMER 10PF
TC102 1-141-227-00 CAP, TRIMMER 20PF
< VIBRATOR >
X101 1-795-396-11 DISCRIMINATOR, CERAMIC 10.7MHz
X102 1-577-126-11 VIBRATOR, CRYSTAL 7.2MHz
< DIODE >
ZD601 8-719-929-15 DIODE MTZJ-T-72-9.1B
ZD602 8-719-109-93 DIODE MTZJ-T-72-6.2B
**************************************************************
A-4729-696-A POWER BOARD, COMPLETE
***********************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C201 1-126-968-11 ELECT 100uF 20.00% 50V
C202 1-128-551-11 ELECT 22uF 20.00% 25V
C204 1-126-963-11 ELECT 4.7uF 20.00% 50V
C206 1-101-005-00 CERAMIC 22000PF 50V
C208 1-101-005-00 CERAMIC 22000PF 50V
C209 1-101-005-00 CERAMIC 22000PF 50V
0 C210 1-117-698-11 CERAMIC 680PF 10.00% 250V
C211 1-101-005-00 CERAMIC 22000PF 50V
C212 1-101-005-00 CERAMIC 22000PF 50V
C213 1-101-005-00 CERAMIC 22000PF 50V
C214 1-101-005-00 CERAMIC 22000PF 50V
C215 1-126-935-11 ELECT 470uF 20.00% 16V
C216 1-101-005-00 CERAMIC 22000PF 50V
C218 1-101-005-00 CERAMIC 22000PF 50V
C219 1-101-005-00 CERAMIC 22000PF 50V
C220 1-101-005-00 CERAMIC 22000PF 50V
C222 1-101-005-00 CERAMIC 22000PF 50V
C223 1-101-005-00 CERAMIC 22000PF 50V
C226 1-126-943-11 ELECT 2200uF 20.00% 25V
C241 1-101-005-00 CERAMIC 22000PF 50V
C243 1-126-960-11 ELECT 1uF 20.00% 50V
< CONNECTOR >
* CN505 1-506-709-11 PLUG, CONNECTOR (2.5mm) 7P
< DIODE >
D201 8-719-077-63 DIODE 1N5402
D202 8-719-077-63 DIODE 1N5402
D203 8-719-077-63 DIODE 1N5402
D204 8-719-077-63 DIODE 1N5402
D205 8-719-200-02 DIODE 1N4001
D206 8-719-200-02 DIODE 1N4001
D207 8-719-200-02 DIODE 1N4001
D208 8-719-200-02 DIODE 1N4001
D212 8-719-991-33 DIODE 1N4148TP
D213 8-719-991-33 DIODE 1N4148TP
D215 8-719-200-02 DIODE 1N4001
D216 8-719-200-02 DIODE 1N4001
D217 8-719-200-02 DIODE 1N4001
D218 8-719-200-02 DIODE 1N4001
D221 8-719-200-02 DIODE 1N4001
< FUSE >
0 F201 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) T4AL/250V
0 F202 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) T2AL/250V
< COIL >
L202 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q205 8-729-173-38 TRANSISTOR 2SA608SP-G
Q206 8-729-281-53 TRANSISTOR 2SC536NP-F
< RESISTOR >
R201 1-249-408-11 CARBON 180 5% 1/4W F
R202 1-249-424-11 CARBON 3.9K 5% 1/4W F
R204 1-249-434-11 CARBON 27K 5% 1/4W
R218 1-249-437-11 CARBON 47K 5% 1/4W
R219 1-249-417-11 CARBON 1K 5% 1/4W F
R221 1-249-437-11 CARBON 47K 5% 1/4W
R222 1-249-393-11 CARBON 10 5% 1/4W F
R223 1-249-437-11 CARBON 47K 5% 1/4W
< RELAY >
0 RE201 1-755-446-11 RELAY
< TRANSFORMER >
0 T202 1-437-815-11 TRANSFORMER, POWER
< DIODE >
Z201 8-719-109-97 DIODE MTZJ-T-72-6.8B
Z202 8-719-109-93 DIODE MTZJ-T-72-6.2B
**************************************************************
MISCELLANEOUS
**************
3 1-500-712-11 CORE, FERRITE
0 6 1-555-750-00 CORD, POWER (AEP)
0 6 1-696-535-11 CORD, POWER (UK)
8 1-823-170-11 CORD (WITH CONNECTOR) (FM ANT)
65 1-796-543-11 DECK, MECH (CFL4318)
157 1-471-144-11 MAGNET
0 166 1-796-189-11 MECH, CD
0 F201 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) T4AL/250V
0 F202 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) T2AL/250V
SW600 1-692-960-21 SWITCH, PUSH (1 KEY) (Z PUSH OPEN/CLOSE)
0 T201 1-437-513-11 TRANSFORMER, POWER
MAIN
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ver 1.1 2002.07
