Sony HCD-EX100 - Page 35

35
HCD-EX100
IC351 BA6956AN (LOADING board)
LEVEL SHIFT
INTERFACE
INTERFACE
INTERFACE
1 2 3 4 5 6 7 8 9 10 11 12 13 14
202122232425262728 19 18 17 16 15
F
R
RF
F
R
RF
R
R
F
F
MUTE
THERMAL
SHUTDOWN
VREFOUT
VREFIN
POWVCC
CH1FIN
CH1RIN
CH2FIN
CH2RIN
CH2OUTR
CH2OUTF
CH1OUTR
CH1OUTF
CAPAIN1 CAPAIN2
GND
PRFVCC MUTE POWVCC CH4SIN' CH4SIN CH4BIN CH3FIN CH3RIN CH3OUTR CH3OUTF CH4OUTR CH4OUTF CAPAIN3 GND
IC302 BA5974FP-E2 (MAIN board (1/3))
1 2 3 4 5 6 7 8
910111213141516
QUAL
RDATA
VREF
VDD1
VSS1
MUX
VSS3
CMP
RCLK XO XI (NC) VDD2 VSS2 T1 T2
8TH SWITCHED
CAPACITOR
FILTER
PLL 57KHz
RDS/ARI
BIPHASE
DECODER
DEFFERENTIAL
DECODER
PLL
1187.5Hz
TEST
CLOCK
IC451 BU1924F (MAIN board (3/3))
1 2 3 4 5 6 7 8 9
CONTROL LOGIC
TSD
VREF
OUT2 OUT1
RNF
VM
VCC
FIN
GND
RIN
