40
HCD-EX100
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
LOADING
< IC >
IC651 8-759-673-48 IC SN74HC14ANSR
IC652 8-759-925-90 IC SN74HC74ANSR
< RESISTOR >
R650 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R651 1-216-091-00 METAL CHIP 56K 5% 1/10W
R652 1-216-025-11 RES-CHIP 100 5% 1/10W
R653 1-216-073-91 RES-CHIP 10K 5% 1/10W
R655 1-216-097-11 RES-CHIP 100K 5% 1/10W
R656 1-216-097-11 RES-CHIP 100K 5% 1/10W
R659 1-216-049-11 RES-CHIP 1K 5% 1/10W
******************************************************
1-682-074-11 LED BOARD
*********
< DIODE >
D781 8-719-085-19 DIODE SELS5B20C-TP15
D782 8-719-085-19 DIODE SELS5B20C-TP15
D783 8-719-085-19 DIODE SELS5B20C-TP15
D784 8-719-085-19 DIODE SELS5B20C-TP15
< RESISTOR >
R781 1-216-041-00 METAL CHIP 470 5% 1/10W
R782 1-216-041-00 METAL CHIP 470 5% 1/10W
R783 1-216-041-00 METAL CHIP 470 5% 1/10W
R784 1-216-041-00 METAL CHIP 470 5% 1/10W
******************************************************
1-682-072-11 LOADING BOARD
*************
1-791-868-11 CORD, CONNECTION
< CAPASCITOR >
C351 1-104-665-11 ELECT 100uF 20% 16V
C352 1-163-031-91 CERAMIC CHIP 0.01uF 50V
C354 1-163-031-91 CERAMIC CHIP 0.01uF 50V
< DIODE >
D351 8-719-056-78 DIODE UDZ-TE-17-4.3B
< IC >
IC351 8-759-598-69 IC BA6956AN
< RESISTOR >
R351 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
*******************************************************
A-4725-962-A MAIN BOARD, COMPLETE (US,CND)
A-4725-971-A MAIN BOARD, COMPLETE (AEP,UK)
A-4725-975-A MAIN BOARD, COMPLETE (HK,KR,SP)
A-4726-856-A MAIN BOARD, COMPLETE (CH)
***************************
4-234-982-01 HOUSE, LAMP
4-235-011-01 ILLUMINATOR
< CAPACITOR >
C100 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C101 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C102 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C111 1-136-173-00 MYLAR 0.47uF 5% 50V
C112 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C113 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C114 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C115 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C116 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C117 1-126-964-11 ELECT 10uF 20% 50V
C118 1-126-964-11 ELECT 10uF 20% 50V
C119 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C120 1-136-165-00 MYLAR 0.1uF 5% 50V
C121 1-136-165-00 MYLAR 0.1uF 5% 50V
C131 1-128-834-11 ELECT 470uF 20% 10V
C132 1-128-834-11 ELECT 470uF 20% 10V
C133 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C134 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C135 1-126-964-11 ELECT 10uF 20% 50V
C136 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C137 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C138 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C139 1-164-346-11 CERAMIC CHIP 1uF 16V
C151 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C152 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C161 1-136-173-00 MYLAR 0.47uF 5% 50V
C162 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C163 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C164 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C165 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C166 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C167 1-126-964-11 ELECT 10uF 20% 50V
C168 1-126-964-11 ELECT 10uF 20% 50V
C169 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C170 1-136-165-00 MYLAR 0.1uF 5% 50V
C171 1-136-165-00 MYLAR 0.1uF 5% 50V
C176 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C177 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C299 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C300 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C301 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C302 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C303 1-126-947-11 ELECT 47uF 20% 10V
C304 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C305 1-104-665-11 ELECT 100uF 20% 10V
C306 1-126-964-11 ELECT 10uF 20% 50V
C307 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C308 1-163-217-11 CERAMIC CHIP 1PF 0.25PF 50V
C309 1-163-031-91 CERAMIC CHIP 0.01uF 50V
C311 1-164-346-11 CERAMIC CHIP 1uF 16V
C312 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C313 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C314 1-126-947-11 ELECT 47uF 20% 10V
C321 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C322 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
LEDEJECT
