Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EX66/EX88/EX99
6969
R458 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EX99)
R459 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EX99)
R460 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EX99)
R461 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EX99)
R462 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
(EX99)
R463 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EX99)
R464 1-216-845-11 METAL CHIP 100K 5% 1/10W
(EX99)
R465 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EX99)
R466 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EX99)
R467 1-216-845-11 METAL CHIP 100K 5% 1/10W
(EX99)
R468 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EX99)
R469 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EX99)
R470 1-216-845-11 METAL CHIP 100K 5% 1/10W
(EX99)
R471 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R472 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R473 1-216-833-11 METAL CHIP 10K 5% 1/10W
R474 1-216-174-00 METAL CHIP 100 5% 1/8W
R475 1-216-837-11 METAL CHIP 22K 5% 1/10W
R476 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R477 1-216-839-11 METAL CHIP 33K 5% 1/10W
R478 1-216-174-00 METAL CHIP 100 5% 1/8W
R479 1-216-845-11 METAL CHIP 100K 5% 1/10W
R480 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R481 1-216-821-11 METAL CHIP 1K 5% 1/10W
R482 1-216-841-11 METAL CHIP 47K 5% 1/10W
R484 1-216-821-11 METAL CHIP 1K 5% 1/10W
R485 1-216-845-11 METAL CHIP 100K 5% 1/10W
R486 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R487 1-216-841-11 METAL CHIP 47K 5% 1/10W
R488 1-216-845-11 METAL CHIP 100K 5% 1/10W
R489 1-216-833-11 METAL CHIP 10K 5% 1/10W
R491 1-216-821-11 METAL CHIP 1K 5% 1/10W
R492 1-216-845-11 METAL CHIP 100K 5% 1/10W
R493 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R494 1-216-174-00 METAL CHIP 100 5% 1/8W
R495 1-216-833-11 METAL CHIP 10K 5% 1/10W
R496 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R497 1-216-839-11 METAL CHIP 33K 5% 1/10W
R498 1-216-174-00 METAL CHIP 100 5% 1/8W
R499 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S301 1-771-410-21 SWITCH, TACTILE ("/1)
S303 1-771-410-21 SWITCH, TACTILE (NX)
S304 1-786-417-11 ENCODER, ROTARY (VOLUME)
S305 1-771-410-21 SWITCH, TACTILE (Z)
S306 1-771-410-21 SWITCH, TACTILE (FUNCTION)
S307 1-771-410-21 SWITCH, TACTILE (EQ)
S308 1-771-410-21 SWITCH, TACTILE (OPTIONS)
S309 1-771-410-21 SWITCH, TACTILE (TUNING– l m)
S312 1-771-410-21 SWITCH, TACTILE (x)
S313 1-771-410-21 SWITCH, TACTILE (REC TO USB)
S314 1-771-410-21 SWITCH, TACTILE (DSGX)
S315 1-771-410-21 SWITCH, TACTILE (ENTER)
S316 1-771-410-21 SWITCH, TACTILE (TUNING+ M L)
< VIBRATOR >
X301 1-814-067-11 OSCILLATOR, CRYSTAL (32.768kHz)
X302 1-814-474-21 CERAMIC OSCILLATOR (20MHz)
*************************************************************
REGULATOR BOARD (EX88)
****************
7-685-647-71 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
C700 1-126-935-11 ELECT 470uF 20% 16V
C701 1-126-964-11 ELECT 10uF 20% 50V
C702 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C703 1-126-947-11 ELECT 47uF 20% 35V
C705 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C706 1-126-964-11 ELECT 10uF 20% 50V
C707 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C708 1-126-947-11 ELECT 47uF 20% 35V
C709 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C710 1-126-935-11 ELECT 470uF 20% 16V
C713 1-104-658-91 ELECT 100uF 20% 10V
C714 1-135-977-31 ELECT 680uF 20% 10V
C716 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C717 1-126-961-11 ELECT 2.2uF 20% 50V
C718 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C719 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C720 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C721 1-126-963-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
CN700 1-842-654-11 CONNECTOR, BOARD TO BOARD 16P
* CN701 1-564-518-11 PLUG, CONNECTOR 3P
< DIODE >
D700 8-719-079-47 DIODE RK36LF-A4
D701 6-502-964-01 DIODE DZ2J047M0L
D702 6-503-020-01 DIODE DZ2J082M0L
D703 6-500-335-01 DIODE MC2838-T112-1
D704 6-502-964-01 DIODE DZ2J047M0L
< FERRITE BEAD >
FB700 1-414-594-11 INDUCTOR, FERRITE BEAD
FB701 1-414-594-11 INDUCTOR, FERRITE BEAD
< IC >
IC700 6-712-613-01 IC SI-3010KM-TLS
IC701 6-713-032-01 IC KIA7809API-U/PF
IC702 6-713-793-01 IC SI-3010KFEK
IC703 6-712-617-01 IC SI-8008TM-TLS
< COIL >
L700 1-400-424-11 COIL, CHOKE 47uH
PANEL REGULATOR (EX88)
To Next Page
