Sony HCD-EX99 - Parts List: Regulator (EX88;EX99)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EX66/EX88/EX99
70
< TRANSISTOR >
Q700 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q701 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q702 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q703 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q704 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q705 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q706 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q707 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q708 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q709 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q711 8-729-038-23 TRANSISTOR RT1N141C-TP-1
< RESISTOR >
R700 1-216-821-11 METAL CHIP 1K 5% 1/10W
R701 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R702 1-216-833-11 METAL CHIP 10K 5% 1/10W
R703 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R704 1-216-845-11 METAL CHIP 100K 5% 1/10W
R705 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R706 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R707 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R708 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R709 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R710 1-216-833-11 METAL CHIP 10K 5% 1/10W
R711 1-216-845-11 METAL CHIP 100K 5% 1/10W
R712 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R713 1-216-853-11 METAL CHIP 470K 5% 1/10W
R715 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R716 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R717 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R718 1-218-835-11 METAL CHIP 330 0.5% 1/10W
R719 1-218-839-11 METAL CHIP 470 0.5% 1/10W
R720 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R721 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W
R722 1-216-821-11 METAL CHIP 1K 5% 1/10W
R723 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R724 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R725 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R726 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R727 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R728 1-216-833-11 METAL CHIP 10K 5% 1/10W
R729 1-216-845-11 METAL CHIP 100K 5% 1/10W
R730 1-216-809-11 METAL CHIP 100 5% 1/10W
R731 1-216-809-11 METAL CHIP 100 5% 1/10W
R732 1-216-821-11 METAL CHIP 1K 5% 1/10W
R733 1-216-821-11 METAL CHIP 1K 5% 1/10W
R734 1-216-837-11 METAL CHIP 22K 5% 1/10W
R737 1-216-849-11 METAL CHIP 220K 5% 1/10W
R738 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R739 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R740 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R741 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R742 1-216-821-11 METAL CHIP 1K 5% 1/10W
R743 1-216-821-11 METAL CHIP 1K 5% 1/10W
R744 1-216-837-11 METAL CHIP 22K 5% 1/10W
R745 1-216-837-11 METAL CHIP 22K 5% 1/10W
R746 1-216-837-11 METAL CHIP 22K 5% 1/10W
R747 1-216-837-11 METAL CHIP 22K 5% 1/10W
*************************************************************
REGULATOR BOARD (EX99)
*****************
7-685-647-71 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
C700 1-126-935-11 ELECT 470uF 20% 16V
C701 1-126-964-11 ELECT 10uF 20% 50V
C702 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C703 1-126-947-11 ELECT 47uF 20% 35V
C705 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C706 1-126-964-11 ELECT 10uF 20% 50V
C707 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C708 1-126-947-11 ELECT 47uF 20% 35V
C709 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C710 1-126-935-11 ELECT 470uF 20% 16V
C713 1-104-658-91 ELECT 100uF 20% 10V
C714 1-135-977-31 ELECT 680uF 20% 10V
C716 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C717 1-126-961-11 ELECT 2.2uF 20% 50V
C718 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C719 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C720 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C721 1-126-963-11 ELECT 4.7uF 20% 50V
C722 1-126-960-11 ELECT 1uF 20% 50V
C723 1-126-960-11 ELECT 1uF 20% 50V
C724 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN700 1-842-654-11 CONNECTOR, BOARD TO BOARD 16P
* CN701 1-794-042-11 CONNECTOR, BOARD TO BOARD 6P
* CN702 1-564-518-11 PLUG, CONNECTOR 3P
< DIODE >
D700 8-719-079-47 DIODE RK36LF-A4
D701 6-502-964-01 DIODE DZ2J047M0L
D702 6-503-020-01 DIODE DZ2J082M0L
D703 6-500-335-01 DIODE MC2838-T112-1
D704 6-502-964-01 DIODE DZ2J047M0L
D705 6-500-848-01 DIODE MC2840-T112-1
D706 6-500-848-01 DIODE MC2840-T112-1
< FERRITE BEAD >
FB700 1-414-594-11 INDUCTOR, FERRITE BEAD
FB701 1-414-594-11 INDUCTOR, FERRITE BEAD
< IC >
IC700 6-712-613-01 IC SI-3010KM-TLS
IC701 6-713-032-01 IC KIA7809API-U/PF
IC702 6-713-793-01 IC SI-3010KFEK
IC703 6-712-617-01 IC SI-8008TM-TLS
< COIL >
L700 1-400-424-11 COIL, CHOKE 47uH
< TRANSISTOR >
Q700 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q701 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q702 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q703 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
REGULATOR (EX88) REGULATOR (EX99)
