Sony HCD-EX99 - Parts List: Regulator (EX99) & Tuner

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EX66/EX88/EX99
7171
Q704 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q705 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q706 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q707 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q708 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q709 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q710 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q711 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q712 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
< RESISTOR >
R700 1-216-821-11 METAL CHIP 1K 5% 1/10W
R701 1-216-833-11 METAL CHIP 10K 5% 1/10W
R702 1-216-845-11 METAL CHIP 100K 5% 1/10W
R703 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R704 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R705 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R706 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R707 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R708 1-216-841-11 METAL CHIP 47K 5% 1/10W
R709 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R710 1-216-833-11 METAL CHIP 10K 5% 1/10W
R711 1-216-845-11 METAL CHIP 100K 5% 1/10W
R712 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R713 1-216-853-11 METAL CHIP 470K 5% 1/10W
R715 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R716 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R717 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R718 1-218-835-11 METAL CHIP 330 0.5% 1/10W
R719 1-218-839-11 METAL CHIP 470 0.5% 1/10W
R720 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R721 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W
R722 1-216-821-11 METAL CHIP 1K 5% 1/10W
R723 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R724 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R725 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R726 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R727 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R728 1-216-833-11 METAL CHIP 10K 5% 1/10W
R729 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R730 1-216-833-11 METAL CHIP 10K 5% 1/10W
R731 1-216-845-11 METAL CHIP 100K 5% 1/10W
R732 1-216-809-11 METAL CHIP 100 5% 1/10W
R733 1-216-809-11 METAL CHIP 100 5% 1/10W
R734 1-216-821-11 METAL CHIP 1K 5% 1/10W
R735 1-216-821-11 METAL CHIP 1K 5% 1/10W
R736 1-216-821-11 METAL CHIP 1K 5% 1/10W
R739 1-216-849-11 METAL CHIP 220K 5% 1/10W
R740 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R741 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R742 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R743 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R744 1-216-837-11 METAL CHIP 22K 5% 1/10W
R745 1-216-837-11 METAL CHIP 22K 5% 1/10W
R746 1-216-837-11 METAL CHIP 22K 5% 1/10W
R747 1-216-837-11 METAL CHIP 22K 5% 1/10W
R748 1-216-821-11 METAL CHIP 1K 5% 1/10W
R749 1-216-837-11 METAL CHIP 22K 5% 1/10W
R750 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R751 1-216-841-11 METAL CHIP 47K 5% 1/10W
R752 1-216-845-11 METAL CHIP 100K 5% 1/10W
R753 1-216-833-11 METAL CHIP 10K 5% 1/10W
*************************************************************
TUNER BOARD
************
< CAPACITOR >
C501 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C502 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C503 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C505 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C506 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C511 1-124-584-00 ELECT 100uF 20% 10V
C512 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C513 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C514 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C516 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
< CONNECTOR >
CN501 1-568-850-11 CONNECTOR, FFC 7P
* CN502 1-506-680-11 PLUG, CONNECTOR (2.5mm) 3P
(ANTENNA FM/AM)
< DIODE >
D501 6-501-579-01 DIODE MC2837
D502 6-501-579-01 DIODE MC2837
D503 6-501-579-01 DIODE MC2837
< BPF >
FL501 1-236-711-21 FILTER, BAND PASS
< IC >
IC501 6-716-080-01 IC S-815A33AMC-I2STFU
IC502 6-716-361-01 IC RS5B800-0002E2
< JUMPER RESISTOR >
JR501
1-216-864-11 SHORT CHIP 0
JR502 1-216-864-11 SHORT CHIP 0
JR510 1-216-864-11 SHORT CHIP 0
< COIL >
L501 1-457-998-11 COIL, AM ANTENNA
L502 1-481-524-11 INDUCTOR 10uH
L503 1-481-521-11 INDUCTOR 1uH
< RESISTOR >
R501 1-216-809-11 METAL CHIP 100 5% 1/10W
R502 1-216-809-11 METAL CHIP 100 5% 1/10W
R503 1-216-809-11 METAL CHIP 100 5% 1/10W
R504 1-216-833-11 METAL CHIP 10K 5% 1/10W
R505 1-216-864-11 SHORT CHIP 0
R506 1-216-833-11 METAL CHIP 10K 5% 1/10W
R507 1-216-864-11 SHORT CHIP 0
R508 1-216-809-11 METAL CHIP 100 5% 1/10W
R509 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
< VIBRATOR >
X501 1-767-317-11 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
REGULATOR (EX99) TUNER
