Sony HCD-FLX5D - FRONT PANEL ASSY

13
HCD-FLX5D/FLX7D
3-4. FRONT PANEL ASSY
3 connector
(CN201)
2 wire (flat type) (17 core)
(CN206)
3 two connectors
(CN203, CN208)
3 connector
(CN207)
MC board
1 wire (flat type) (17 core)
(CN109)
6 three connectors
(CN601, CN602,
CN808)
4 two claws
1 screw
(BVTP3
× 8)
1 screw
(BVTP3
× 8)
3 screw
(BVTP3
× 8)
2 two ground
terminals
2 two ground
terminals
5
6
connecto
r
(NO803)
DSP board
7 front panel assy
3 two screws
(BVTP3
× 8)
3 screw
(BVTP3
× 8)
