HCD-FLX5D/FLX7D
7070
7-37. PRINTED WIRING BOARDS – CHANGER Section – • See page 41 for Circuit Boards Location. :Uses unleaded solder.
12
1
2
CLAMP MOTOR BOARD
INIT/COUNT SW BOARD SENSOR 2 BOARD OUT/MIDOUT SW BOARD
IN/MIDIN SW BOARD
CONNECT BOARD
SENSOR BOARD
LOADING MOTOR BOARD
M
1-683-901-
11
(11)
1-683-897-
11
(11)
1-683-900-
11
(11)
1-683-898-
11
(11)
1-683-895-
11
(11)
1
9
14
ON : WHEN SUB TRAY
SET TO PLAY
POSITION
S704
(IN)
DISC IN
DETECT
SENSOR
ON : WHEN SUB TRAY
MOVE BETWEEN
TRAY AND STOCKER
S703
(MIDIN)
1-683-896-
11
(11)
1-683-899-
11
(11)
1-683-902-
11
(11)
1
3
41 41
12
31
F
GC BOARD
CN204
E
15
13
DISK TRAY
ADDRESS DETECT
S707
ROTARY ENCODER
S705 (INIT)
ON : WHEN ELEVATOR DOWN
TO BOTTOM
S706 (COUNT) ON : WHEN ELEVATOR UP/DOWN
EACH SUB TRAY STOCK POSITION
G
GC BOARD
NO805
Q703
DISK IN DETECT
SENSOR
S708
(OUT)
ON : WHEN
TRAY IS OPEN
S701
(MIDOUT)
ON : WHEN TRAY IS
GOING TO OPEN/CLOSE
S702 (LID) ON : WHEN CD LID
IS CLOSE
1
4
M
(LOADING)
ELEVATOR
UP/DOWN
1
9
IC701
IC702
A
B
C
D
E
F
1 2 3 4 5 6 7 8 9
(Page 68)
(Page 68)
D701 B-3
D702 F-8
D704 F-5
IC701 B-2
IC702 F-2
Q701 C-7
Q703 A-6
• Semiconductor
Location
