HCD-FLX5D/FLX7D
3-5. MECHANICAL (CASSETTE) DECK
4
Push two plunger solenoids
1
two screws
(BVTP2.6
×
8
1
two screws
(BVTP2.6
×
3)
1
Open the lid (TC)
6
mechanical (cassette) deck
2
cover (TC)
3-6. GC BOARD
4
three screws
(BVTP3
×
8)
2
wire (flat type) (19 core
(CN202)
1
wire (flat type) (17 core)
(CN204)
3
connector
(CN701)
5
