18
HCD-FLX5D/FLX7D
3-14. VIDEO BOARD
3-13. CHASSIS (MOLD B) SECTION, STOCKER SECTION, SLIDER (SELECTION)
6
stocker
section
1
three screws
(BVTP M2.6)
2
chassis (mold B) section
3
gear (eject)
4
two step screws
5
two step
screws
7
two screws
(PTPWH M2.6)
8
slider (selection)
9
washer
0
compression
spring
pully (LD)
Note: Rotating the pully (LD),
shift the slider (selection)
to the left.
1
four screws
(BVTP3
×
8
2
VIDEO board
