Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
155
HCD-FLX5D/FXL7D
SP RELAY
R851 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R852 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R853 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R854 1-216-837-11 METAL CHIP 22K 5% 1/10W
R856 1-216-839-11 METAL CHIP 33K 5% 1/10W
R857 1-216-833-11 METAL CHIP 10K 5% 1/10W
R858 1-216-833-11 METAL CHIP 10K 5% 1/10W
R859 1-216-809-11 METAL CHIP 100 5% 1/10W
R860 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R861 1-216-841-11 METAL CHIP 47K 5% 1/10W
R862 1-216-837-11 METAL CHIP 22K 5% 1/10W
R863 1-216-837-11 METAL CHIP 22K 5% 1/10W
R864 1-216-849-11 METAL CHIP 220K 5% 1/10W
R865 1-216-841-11 METAL CHIP 47K 5% 1/10W
R866 1-216-843-11 METAL CHIP 68K 5% 1/10W
R867 1-216-843-11 METAL CHIP 68K 5% 1/10W
R868 1-216-843-11 METAL CHIP 68K 5% 1/10W
R869 1-216-841-11 METAL CHIP 47K 5% 1/10W
R870 1-216-843-11 METAL CHIP 68K 5% 1/10W
0R874 1-215-865-11 METAL OXIDE 220 5% 1W F
0R875 1-215-865-11 METAL OXIDE 220 5% 1W F
0R876 1-215-865-11 METAL OXIDE 220 5% 1W F
0R877 1-215-865-11 METAL OXIDE 220 5% 1W F
0R878 1-215-865-11 METAL OXIDE 220 5% 1W F
0R879 1-215-865-11 METAL OXIDE 220 5% 1W F
0R880 1-215-865-11 METAL OXIDE 220 5% 1W F
R889 1-216-833-11 METAL CHIP 10K 5% 1/10W
R890 1-216-820-11 METAL CHIP 820 5% 1/10W
R891 1-216-805-11 METAL CHIP 47 5% 1/10W
< VARIABLE RESISTOR >
RV2 1-241-768-11 RES, ADJ CERMET 220K
RV52 1-241-768-11 RES, ADJ CERMET 220K
RV53 1-238-019-11 RES, ADJ CERMET 47K
< RELAY >
RY801 1-755-416-12 RELAY
RY802 1-755-416-12 RELAY
RY803 1-755-416-12 RELAY
RY804 1-755-416-12 RELAY
RY805 1-755-416-12 RELAY
RY806 1-755-416-12 RELAY
RY807 1-755-416-12 RELAY
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM801 1-694-656-21 TERMINAL BOARD (6CH SPEAKER)
(SPEAKER)
************************************************************
R28 1-216-836-11 METAL CHIP 18K 5% 1/10W
0R29 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
0R30 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
R31 1-216-837-11 METAL CHIP 22K 5% 1/10W
R32 1-216-813-11 METAL CHIP 220 5% 1/10W
R33 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R34 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R35 1-216-845-11 METAL CHIP 100K 5% 1/10W
R36 1-216-833-11 METAL CHIP 10K 5% 1/10W
R39 1-216-833-11 METAL CHIP 10K 5% 1/10W
R40 1-216-833-11 METAL CHIP 10K 5% 1/10W
R41 1-216-821-11 METAL CHIP 1K 5% 1/10W
R42 1-216-821-11 METAL CHIP 1K 5% 1/10W
R43 1-216-861-11 METAL CHIP 2.2M 5% 1/10W
R44 1-216-835-11 METAL CHIP 15K 5% 1/10W
R45 1-216-835-11 METAL CHIP 15K 5% 1/10W
R46 1-216-833-11 METAL CHIP 10K 5% 1/10W
R47 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R48 1-216-837-11 METAL CHIP 22K 5% 1/10W
R49 1-216-833-11 METAL CHIP 10K 5% 1/10W
R50 1-216-833-11 METAL CHIP 10K 5% 1/10W
R51 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R52 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R54 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R55 1-216-841-11 METAL CHIP 47K 5% 1/10W
R56 1-216-837-11 METAL CHIP 22K 5% 1/10W
R58 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R68 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R71 1-216-833-11 METAL CHIP 10K 5% 1/10W
R72 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R90 1-216-864-11 SHORT CHIP 0
0R815 1-215-891-11 METAL OXIDE 680 5% 2W F
0R816 1-215-891-11 METAL OXIDE 680 5% 2W F
R820 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R821 1-216-833-11 METAL CHIP 10K 5% 1/10W
R822 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R823 1-216-833-11 METAL CHIP 10K 5% 1/10W
R824 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R825 1-216-833-11 METAL CHIP 10K 5% 1/10W
R826 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R827 1-216-833-11 METAL CHIP 10K 5% 1/10W
R828 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R829 1-216-833-11 METAL CHIP 10K 5% 1/10W
R830 1-216-833-11 METAL CHIP 10K 5% 1/10W
R831 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R832 1-216-833-11 METAL CHIP 10K 5% 1/10W
R833 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R836 1-216-809-11 METAL CHIP 100 5% 1/10W
R837 1-216-837-11 METAL CHIP 22K 5% 1/10W
R838 1-216-837-11 METAL CHIP 22K 5% 1/10W
R839 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R840 1-216-841-11 METAL CHIP 47K 5% 1/10W
R841 1-216-841-11 METAL CHIP 47K 5% 1/10W
R842 1-216-841-11 METAL CHIP 47K 5% 1/10W
R843 1-216-841-11 METAL CHIP 47K 5% 1/10W
R844 1-216-841-11 METAL CHIP 47K 5% 1/10W
R845 1-216-841-11 METAL CHIP 47K 5% 1/10W
R850 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
