Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
157
HCD-FLX5D/FXL7D
VIDEO
MISCELLANEOUS
**************
64 1-773-044-11 WIRE (FLAT TYPE) (17 CORE)
65 1-796-910-11 DECK, MECHANICAL (CASSETTE)
108 1-828-354-11 WIRE (FLAT TYPE) (17 CORE)
114 1-500-082-11 CLAMP, SLEEVE FERRITE
(FLX5D: EA, KR, AUS/FLX7D: EA)
156 1-828-429-11 WIRE (FLAT TYPE) (11 CORE)
301 1-782-252-11 WIRE (FLAT TYPE) (9 CORE) (FLX7D)
302 1-824-686-11 WIRE (FLAT TYPE) (13 CORE)
303 1-773-123-11 WIRE (FLAT TYPE) (19 CORE)
308 1-773-049-11 WIRE (FLAT TYPE) (17 CORE)
310 1-824-652-11 WIRE (FLAT TYPE) (29 CORE)
311 1-773-105-11 WIRE (FLAT TYPE) (19 CORE)
312 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
316 1-469-829-11 CORE, FERRITE (FLX7D: EA)
317 1-400-640-11 CORE, FERRITE
(FLX5D: EA, KR, AUS/FLX7D: EA)
318 1-469-854-11 CORE, FERRITE
(FLX5D: EA, KR, AUS/FLX7D: EA)
319 1-400-092-11 CORE, FERRITE
(FLX5D: EA, KR, AUS/FLX7D: EA)
352 1-792-099-11 WIRE (FLAT TYPE) (17 CORE)
353 1-590-218-11 WIRE (FLAT TYPE) (11 CORE)
358 1-693-603-31 TUNER (FM/AM) (EXCEPT FLX5D: KR)
358 1-693-605-11 TUNER (FM/AM) (FLX5D: KR)
0455 1-769-079-23 CORD, POWER (FLX5D: KR)
0455 1-775-786-21 CORD, POWER (FLX5D: EA/FLX7D: EA)
0455 1-777-071-83 CORD, POWER (FLX5D: SP, MY, PH)
0455 1-783-203-13 CORD, POWER (FLX5D: AUS)
0455 1-824-818-11 CORD, POWER (WITH CONNECTOR)
(FLX5D: TH)
0455 1-827-226-11 CORD, POWER
(FLX5D: E2, E3, E15/FLX7D: E15)
0703 A-4713-410-A OPTICAL TRAVERSE UNIT
(DBU-1 ASSY (SERVICE))
705 1-824-106-12 CABLE, FLEXIBLE FLAT (24 CORE)
0F913 1-533-472-12 FUSE, GLASS TUBE (DIA. 5) (5A/250V)
(FLX5D: E2, E3, E15, EA, SP, MY, PH/FLX7D)
0F914 1-576-655-12 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
0F915 1-576-655-12 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
0F916 1-576-655-12 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
0F917 1-576-655-12 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
0F918 1-533-473-12 FUSE, GLASS TUBE (DIA. 5) (6.3A/250V)
0F919 1-533-472-12 FUSE, GLASS TUBE (DIA. 5) (5A/250V)
IC801 6-703-546-01 IC TA7804LS
IC802 8-759-231-53 IC TA7805S
IC803 8-759-231-57 IC TA7810S
IC804 8-759-231-53 IC TA7805S
IC921 8-759-518-68 IC PQ12RF21
IC922 8-759-231-56 IC NJM78M09FA
M301 1-541-632-12 MOTOR, DC (CD DOOR OPEN/CLOSE)
M701 X-4950-341-1 MOTOR (CLAMP) ASSY
(ELEVATOR UP/DOWN)
M702 X-4950-342-1 MOTOR (LOADING) ASSY
M801 1-763-488-51 FAN, DC
PM301 1-454-887-32 SOLENOID, PLUNGER (DECK A)
PM302 1-454-887-32 SOLENOID, PLUNGER (DECK B)
Q864 8-729-209-60 TRANSISTOR 2SB1375
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
C742 1-104-655-91 ELECT 470uF 20% 6.3V
C743 1-126-965-11 ELECT 22uF 20% 50V
C744 1-104-655-91 ELECT 470uF 20% 6.3V
C745 1-126-965-11 ELECT 22uF 20% 50V
C746 1-104-655-91 ELECT 470uF 20% 6.3V
C747 1-126-965-11 ELECT 22uF 20% 50V
C748 1-104-665-11 ELECT 100uF 20% 25V
C749 1-126-965-11 ELECT 22uF 20% 50V
C750 1-104-665-11 ELECT 100uF 20% 25V
C751 1-126-965-11 ELECT 22uF 20% 50V
C761 1-126-960-11 ELECT 1uF 20% 50V
C762 1-126-960-11 ELECT 1uF 20% 50V
C763 1-126-960-11 ELECT 1uF 20% 50V
C764 1-126-960-11 ELECT 1uF 20% 50V
C765 1-126-960-11 ELECT 1uF 20% 50V
C766 1-126-960-11 ELECT 1uF 20% 50V
C780 1-162-207-31 CERAMIC 22PF 5% 50V
C781 1-162-207-31 CERAMIC 22PF 5% 50V
C782 1-162-207-31 CERAMIC 22PF 5% 50V
C784 1-162-207-31 CERAMIC 22PF 5% 50V
C785 1-162-207-31 CERAMIC 22PF 5% 50V
C786 1-162-207-31 CERAMIC 22PF 5% 50V
< CONNECTOR >
CN701 1-816-590-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
< IC >
IC701 6-702-335-01 IC MM1568AJBE
< JACK >
J701 1-793-445-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J702 1-537-943-11 TERMINAL, S (S VIDEO OUT)
J703 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< COIL >
L701 1-410-470-11 INDUCTOR 10uH
< TRANSISTOR >
Q711 8-729-422-57 TRANSISTOR UN4111
Q712 8-729-900-89 TRANSISTOR DTC144ES
< RESISTOR >
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-249-429-11 CARBON 10K 5% 1/4W
R717 1-247-804-11 CARBON 75 5% 1/4W
R718 1-247-804-11 CARBON 75 5% 1/4W
R719 1-247-804-11 CARBON 75 5% 1/4W
R720 1-247-804-11 CARBON 75 5% 1/4W
R721 1-247-804-11 CARBON 75 5% 1/4W
R722 1-247-804-11 CARBON 75 5% 1/4W
R724 1-249-429-11 CARBON 10K 5% 1/4W
R725 1-249-429-11 CARBON 10K 5% 1/4W
***********************************************************
Ver 1.1
