103
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN88D
1-687-669-11 SW BOARD
********
S751 1-786-514-11 SWITCH, LEVER (SLIDE) (LEVER)
******************************************************
1-686-930-11 TRANS BOARD
***********
< CAPACITOR >
C941 1-128-576-11 ELECT 100uF 20% 63V
< CONNECTOR >
CN997 1-564-509-11 PLUG, CONNECTOR 6P
* CN998 1-564-510-11 PLUG, CONNECTOR 7P
< DIODE >
D977 8-719-024-99 DIODE 11ES2-NTA2B
< FUSE HOLDER >
FH9741 1-533-233-11 FUSE HOLDER
FH9742 1-533-233-11 FUSE HOLDER
FH9751 1-533-233-11 FUSE HOLDER
FH9752 1-533-233-11 FUSE HOLDER
FH9761 1-533-233-11 FUSE HOLDER
FH9762 1-533-233-11 FUSE HOLDER
FH9771 1-533-233-11 FUSE HOLDER
FH9772 1-533-233-11 FUSE HOLDER
FH9781 1-533-233-11 FUSE HOLDER
FH9782 1-533-233-11 FUSE HOLDER
FH9791 1-533-233-11 FUSE HOLDER
FH9792 1-533-233-11 FUSE HOLDER
< RESISTOR >
0 R941 1-217-637-00 FUSIBLE 1 5% 1/4W
******************************************************
A-4732-883-A VIDEO BOARD, COMPLETE (EXCEPT TH)
A-4734-505-A VIDEO BOARD, COMPLETE (TH)
*******************
< CAPACITOR >
C215 1-126-964-11 ELECT 10uF 20% 50V
C216 1-126-964-11 ELECT 10uF 20% 50V
C217 1-126-964-11 ELECT 10uF 20% 50V
C218 1-126-964-11 ELECT 10uF 20% 50V
C219 1-126-964-11 ELECT 10uF 20% 50V
C220 1-126-964-11 ELECT 10uF 20% 50V
C221 1-126-964-11 ELECT 10uF 20% 50V
C222 1-126-964-11 ELECT 10uF 20% 50V
C709 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C710 1-126-964-11 ELECT 10uF 20% 50V
C711 1-126-964-11 ELECT 10uF 20% 50V
C712 1-126-926-11 ELECT 1000uF 20% 10V
C713 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C714 1-126-933-11 ELECT 100uF 20% 16V
C715 1-126-960-11 ELECT 1uF 20% 50V
C716 1-126-960-11 ELECT 1uF 20% 50V
C717 1-126-960-11 ELECT 1uF 20% 50V
C718 1-126-960-11 ELECT 1uF 20% 50V
C719 1-126-960-11 ELECT 1uF 20% 50V
C720 1-126-960-11 ELECT 1uF 20% 50V
C721 1-126-933-11 ELECT 100uF 20% 16V
C722 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C723 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C724 1-126-935-11 ELECT 470uF 20% 6.3V
C725 1-128-551-11 ELECT 22uF 20% 25V
C726 1-126-935-11 ELECT 470uF 20% 6.3V
C727 1-128-551-11 ELECT 22uF 20% 25V
C728 1-126-935-11 ELECT 470uF 20% 6.3V
C729 1-128-551-11 ELECT 22uF 20% 25V
C730 1-126-933-11 ELECT 100uF 20% 16V
C731 1-126-965-91 ELECT 22uF 20% 50V
C732 1-126-933-11 ELECT 100uF 20% 16V
C733 1-126-965-91 ELECT 22uF 20% 50V
C734 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C735 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C736 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C737 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C738 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C739 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C740 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C741 1-126-965-91 ELECT 22uF 20% 50V
C742 1-126-947-11 ELECT 47uF 20% 16V
C848 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C849 1-126-916-11 ELECT 1000uF 20% 6.3V
< CONNECTOR >
CN207 1-779-289-11 CONNECTOR,FFC(LIF(NON-ZIF))21P
CN208 1-779-293-11 CONNECTOR,FFC(LIF(NON-ZIF))25P
* CN710 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN711 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE)2P
CN712 1-779-285-11 CONNECTOR,FFC(LIF(NON-ZIF))17P
< DIODE >
D710 8-719-988-61 DIODE 1SS355TE-17
D711 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB710 1-216-864-11 METAL CHIP 0 5% 1/10W
FB711 1-216-864-11 METAL CHIP 0 5% 1/10W
FB712 1-216-864-11 METAL CHIP 0 5% 1/10W
FB713 1-216-864-11 METAL CHIP 0 5% 1/10W
FB714 1-216-864-11 METAL CHIP 0 5% 1/10W
FB715 1-216-864-11 METAL CHIP 0 5% 1/10W
FB798 1-216-864-11 METAL CHIP 0 5% 1/10W
< IC >
IC710 8-759-295-90 IC NJM2244M-TE2
IC711 6-702-335-01 IC MM1568AJBE
< JACK >
J710 1-793-483-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J711 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
J712 1-537-943-11 TERMINAL, S (S-VIDEO OUT)
< JUMPER RESISTOR >
JR713 1-216-864-11 METAL CHIP 0 5% 1/10W
SW TRANS VIDEO
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
