Sony HCD-GN88D - Front Panel Assy; Tuner Pack, Sub Trans Board

9
HCD-GN88D
3-3. FRONT PANEL ASSY
3-4. TUNER PACK, SUB TRANS BOARD
3 Screw (BVTP3 x 10)
2 Four screws (BVTP3 x 10)
8 Front panel ASSY
5 From CN606 on Game in board
4 From deck B head
CN402
CN304
6 From deck A head
7 From CN607 on
Game in board
1 Tw o wires
(flat type)
3 Screw (BVTP3 x 10)
MAIN boar
d
8 Sub trans board
4 CN971
5 CN974
6 CN976
1 Wire (flat type)
(11 core)
3 Tuner pack
2 Tw o screw (BVTP3 x 10)
7 Three screws
(BVTP3 x 10
)
