Sony HCD-GN88D - Page 105

105
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN88D
R768 1-249-419-11 CARBON 1.5K 5% 1/4W F
R769 1-249-419-11 CARBON 1.5K 5% 1/4W F
R770 1-249-421-11 CARBON 2.2K 5% 1/4W F
R771 1-247-843-11 CARBON 3.3K 5% 1/4W
R772 1-249-425-11 CARBON 4.7K 5% 1/4W F
R773 1-249-427-11 CARBON 6.8K 5% 1/4W F
R774 1-249-429-11 CARBON 10K 5% 1/4W
R775 1-249-431-11 CARBON 15K 5% 1/4W
R776 1-249-433-11 CARBON 22K 5% 1/4W
R777 1-249-435-11 CARBON 33K 5% 1/4W
R1001 1-249-413-11 CARBON 470 5% 1/4W F
R1002 1-249-413-11 CARBON 470 5% 1/4W F
R1003 1-249-413-11 CARBON 470 5% 1/4W F
R1004 1-249-413-11 CARBON 470 5% 1/4W F
R1005 1-249-413-11 CARBON 470 5% 1/4W F
R1006 1-249-413-11 CARBON 470 5% 1/4W F
R1007 1-249-413-11 CARBON 470 5% 1/4W F
R1008 1-249-413-11 CARBON 470 5% 1/4W F
R1009 1-249-413-11 CARBON 470 5% 1/4W F
R1010 1-249-413-11 CARBON 470 5% 1/4W F
R1011 1-249-413-11 CARBON 470 5% 1/4W F
R1012 1-249-407-11 CARBON 150 5% 1/4W F
R1013 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S748 1-476-504-11 ENCODER, ROTARY (VOLUME)
S750 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S759 1-771-410-21 SWITCH, TACTILE (SOUND FIELD)
S760 1-771-410-21 SWITCH, TACTILE (P.FILE)
S761 1-771-410-21 SWITCH, TACTILE (ILLUMINATION)
S762 1-771-410-21 SWITCH, TACTILE (GAME EQ)
S763 1-771-410-21 SWITCH, TACTILE (GROOVE)
S765 1-771-410-21 SWITCH, TACTILE (DVD TOP MENU/DIRECTION)
S766 1-771-410-21 SWITCH, TACTILE (FM MODE/REPEAT)
S767 1-771-410-21 SWITCH, TACTILE
(TUNER MEMORY/PLAY MODE)
S768 1-771-410-21 SWITCH, TACTILE (AMP MENU)
S769 1-771-410-21 SWITCH, TACTILE (MUSIC EQ)
S770 1-771-410-21 SWITCH, TACTILE (MOVIE EQ)
S771 1-771-410-21 SWITCH, TACTILE (EFFECT ON/OFF)
S772 1-771-410-21 SWITCH, TACTILE (DVD MENU)
S773 1-786-528-11 SWITCH, ROTARY (<,,,M,m,PUSH ENTER)
******************************************************
MISCELLANEOUS
*************
0 1-569-007-11 ADAPTOR, CONVERSION (E3,E15)
0 1-569-008-21 ADAPTOR, CONVERSION (E51,EA,PH,SP,MY)
0 1-770-019-51 ADAPTOR, CONVERSION PLUG (TH)
6 1-693-603-31 TUNER (FM/AM)
11 1-775-165-11 WIRE (FLAT TYPE) (17 CORE) (220mm)
70 1-773-040-11 WIRE (FLAT TYPE) (17 CORE) (120mm)
73 1-773-110-11 WIRE (FLAT TYPE) (19 CORE)
75 1-796-487-31 DECK, MECHANICAL (CDM43RR23)
79 1-751-688-11 WIRE (FLAT TYPE) (13 CORE)
0 103 1-696-847-21 CORD, POWER (AUS)
0 103 1-777-071-53 CORD, POWER (E51,EA,PH,SP,MY)
0 103 1-824-818-11 CORD, POWER (TH)
0 103 1-827-226-11 CORD, POWER (E15,E3,MX)
152 1-776-182-11 WIRE (FLAT TYPE) (5 CORE)
226 1-775-265-11 WIRE (FLAT TYPE) (29 CORE)
227 1-824-106-12 CABLE, FLEXIBLE FLAT (24 CORE)
0 229 1-477-263-11 OPTICAL PICK-UP (TDP022W)
0 F974 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
0 F975 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
0 F976 1-576-655-11 FUSE, GLASS TUBE (DIA. 5) (8A 250V)
0 F977 1-576-655-11 FUSE, GLASS TUBE (DIA. 5) (8A 250V)
0 F978 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) (4A 250V)
0 F979 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (3.15A 250V)
M741 A-4723-963-A MOTOR ASSY, TABLE
M751 A-4737-553-A MOTOR ASSY, LOADING
M891 1-763-072-11 FAN, DC
RE701 1-477-680-11 ENCODER, ROTARY
0 T910 1-439-741-11 TRANSFORMER, POWER
(AUS,E15,E3,E51,PH,SP,MY,TH)
0 T910 1-439-842-11 POWER TRANSFORMER (EA,MX)
VOLUME
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
