– 120 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C72 1-126-967-11 ELECT 47uF 20% 16V
(GR8: JE/RX90)
C120 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
(RX90: AEP, G, UK AED)
C1701 1-162-294-31 CERAMIC 0.001uF 10% 50V
(RX90: EE, CIS)
C1702 1-130-014-00 PP FILM 470PF 5% 16V
(RX90: EE, CIS)
C1703 1-126-959-11 ELECT 0.47uF 20% 50V
(RX90: EE, CIS)
C1704 1-126-959-11 ELECT 0.47uF 20% 50V
(RX90: EE, CIS)
C1705 1-163-035-00 CERAMIC CHIP 0.047uF 50V
(RX90: EE, CIS)
C1706 1-126-960-11 ELECT 1uF 20% 50V
(RX90: EE, CIS)
C1707 1-163-129-00 CERAMIC CHIP 330P 5% 50V
(RX90: EE, CIS)
C1710 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
(RX90: EE, CIS)
C1711 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
(RX90: EE, CIS)
C1712 1-130-736-11 PP FILM 0.01uF 5% 16V
(RX90: EE, CIS)
C1713 1-130-736-11 PP FILM 0.01uF 5% 16V
(RX90: EE, CIS)
C1714 1-126-960-11 ELECT 1uF 20% 50V
(RX90: EE, CIS)
C1715 1-126-960-11 ELECT 1uF 20% 50V
(RX90: EE, CIS)
C1716 1-126-960-11 ELECT 1uF 20% 50V
(RX90: EE, CIS)
C1719 1-126-967-11 ELECT 47uF 20% 16V
(RX90: EE, CIS)
C1720 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(RX90: EE, CIS)
C1723 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(RX90: EE, CIS)
C1724 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(RX90: EE, CIS)
C1725 1-126-967-11 ELECT 47uF 20% 16V
(RX90: EE, CIS)
C1726 1-126-960-11 ELECT 1uF 20% 50V
(RX90: EE, CIS)
C1727 1-126-960-11 ELECT 1uF 20% 50V
(RX90: EE, CIS)
C1728 1-126-966-11 ELECT 33uF 20% 16V
(RX90: EE, CIS)
C1751 1-164-159-21 CERAMIC 0.01uF 50V
(RX90: AEP, G, UK, AED)
C1752 1-126-967-11 ELECT 47uF 20% 16V
(RX90: AEP, G, UK, AED)
C1753 1-262-964-11 ELECT 10uF 20% 50V
(RX90: AEP, G, UK, AED)
C1754 1-162-291-31 CERAMIC 560PF 10% 50V
(RX90: AEP, G, UK, AED)
C1755 1-126-964-11 ELECT 10uF 20% 50V
(RX90: AEP, G, UK, AED)
C1756 1-126-961-11 ELECT 2.2uF 20% 50V
(RX90: AEP, G, UK, AED)
C1757 1-162-288-31 CERAMIC 330PF 10% 50V
(RX90: AEP, G, UK, AED)
C1758 1-163-031-11 CERAMIC (2012) 10000PF 50V
(RX90: AEP, G, UK, AED)
C1759 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
(RX90: AEP, G, UK, AED)
C1760 1-163-031-11 CERAMIC (2012) 10000PF 50V
(RX90: AEP, G, UK, AED)
C1761 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
(RX90: AEP, G, UK, AED)
C1762 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
(RX90: AEP, G, UK, AED)
< CERAMIC FILTER >
CF1 1-567-389-11 FILTER, CERAMIC (GR8: JE/RX90: EE, CIS)
CF1 1-579-374-11 FILTER, CERAMIC (RX90: AEP, G, UK, AED)
CF2 1-760-393-11 FILTER, CERAMIC (RX90: AEP, G, UK, AED)
CF3 1-567-389-11 FILTER, CERAMIC (GR8: JE/RX90: EE, CIS)
CF3 1-760-393-11 FILTER, CERAMIC (RX90: AEP, G, UK, AED)
< CONNECTOR >
* CN1 1-568-834-11 SOCKET, CONNECTOR 15P (GR8: JE/RX90)
< TRIMMER >
CT1701 1-141-444-11 CAP, CERAMIC TRIMMER 50PF (RX90: EE, CIS)
CV1 1-141-227-00 CAP, TRIMMER 20PF (GR8: JE)
CV2 1-141-227-00 CAP, TRIMMER 20PF (GR8: JE)
< DIODE >
D1 8-719-976-30 DIODE KV1560NT (GR8: JE)
D21 8-719-976-99 DIODE UDZ-TE-17-5.1B (GR8: JE/RX90)
D41 8-719-016-74 DIODE 1SS352-TPH3 (GR8: JE/RX90)
D42 8-719-987-63 DIODE 1N4148M-TA (RX90: AEP, G, UK, AED)
D42 8-719-016-74 DIODE 1SS352-TPH3 (RX90: EE, CIS)
D43 8-719-016-74 DIODE 1SS352-TPH3 (RX90: EE, CIS)
D1701 8-719-016-74 DIODE 1SS352-TPH3 (RX90: EE, CIS)
D1702 8-719-016-74 DIODE 1SS352-TPH3 (RX90: EE, CIS)
D1703 8-719-987-63 DIODE 1N4148M-TA (RX90: EE, CIS)
D1704 8-719-016-74 DIODE 1SS352-TPH3 (RX90: EE, CIS)
D1751 8-719-016-74 DIODE 1SS352-TPH3 (RX90: AEP, G, UK, AED)
< TUNER UNIT >
FE1 1-693-251-11 FRONT END (GR8: JE)
FE1 1-693-357-11 FRONT END (4 GANG) (RX90: AEP, G, UK, AED)
FE1 1-693-335-11 FRONT END (3 GANG) (RX90: EE, CIS)
FE2 1-233-262-11 ENCAPSULATED COMPONENT (GR8: JE)
FE2 1-233-514-11 ENCAPSULATED COMPONENT (RX90)
