Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< IC >
IC21 8-759-288-54 IC LC72130 (GR8: JE/RX90)
IC41 8-759-176-03 IC LA1835 (GR8: JE/RX90)
IC1701 8-759-063-04 IC IR3R42 (RX90: EE, CIS)
IC1702 8-759-140-53 IC MC14053BCP (RX90: EE, CIS)
IC1751 8-759-963-51 IC NJM4558D (RX90: AEP, G, UK, AED)
IC1752 8-759-450-86 IC BU1922 (RX90: AEP, G, UK, AED)
< IFT >
IFT41 1-409-636-11 TRANSFORMER,IF (CERAMIC FILTER)
(GR8: JE/RX90)
< CHIP CONDUCTOR >
JR2 1-216-295-91 CONDUCTOR, CHIP (2012) (RX90)
JR6 1-216-295-91 CONDUCTOR, CHIP (2012) (RX90)
JR8 1-216-295-91 CONDUCTOR, CHIP (2012) (RX90)
JR9 1-216-295-91 CONDUCTOR, CHIP (2012) (RX90)
JR45 1-216-295-91 CONDUCTOR, CHIP (2012) (GR8: JE)
JR46 1-216-296-91 CONDUCTOR, CHIP (3216) (GR8: JE/RX90)
JR47 1-216-295-91 CONDUCTOR, CHIP (2012) (GR8: JE/RX90)
JR48 1-216-295-91 CONDUCTOR, CHIP (2012) (GR8: JE/RX90)
JR49 1-216-296-91 CONDUCTOR, CHIP (3216) (GR8: JE/RX90)
JR50 1-216-295-91 CONDUCTOR, CHIP (2012) (GR8: JE)
JR51 1-216-295-91 CONDUCTOR, CHIP (2012) (GR8: JE/RX90)
JR52 1-216-295-91 CONDUCTOR, CHIP (2012) (GR8: JE/RX90)
JR53 1-216-296-91 CONDUCTOR, CHIP (3216) (GR8: JE/RX90)
JR54 1-216-295-91 CONDUCTOR, CHIP (2012) (GR8: JE/RX90)
JR1701 1-216-295-91 CONDUCTOR, CHIP (2012) (RX90: EE, CIS)
JR1702 1-216-295-91 CONDUCTOR, CHIP (2012) (RX90: EE, CIS)
JR1703 1-216-295-91 CONDUCTOR, CHIP (2012) (RX90: EE, CIS)
JR1704 1-216-295-91 CONDUCTOR, CHIP (2012) (RX90: EE, CIS)
JR1705 1-216-295-91 CONDUCTOR, CHIP (2012) (RX90: EE, CIS)
< INDUCTOR >
L1 1-410-521-11 INDUCTOR, MICRO 100uH (GR8: JE)
L2 1-414-142-11 INDUCTOR, MICRO 10uH
(RX90: AEP, G, UK, AED)
L3 1-410-521-11 INDUCTOR, MICRO 100uH (GR8: JE/RX90)
L4 1-410-515-11 INDUCTOR, MICRO 33uH
(RX90: AEP, G, UK, AED)
L41 1-410-119-11 MICRO INDUCTOR 1mH (GR8: JE)
L41 1-407-500-00 MICRO INDUCTOR 4.7mH (RX90)
L1701 1-409-497-11 COIL 5.19mH (FILTER)
(RX90: EE, CIS)
L1751 1-410-521-11 INDUCTOR, MICRO 100uH
(RX90: AEP, G, UK, AED)
< LOW-PASS FILTER >
LPF41 1-239-845-11 FILTER, LOW-PASS
LPF42 1-239-845-11 FILTER, LOW-PASS
< TRANSISTOR >
Q1 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L (GR8: JE/RX90)
Q2 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L (GR8: JE/RX90)
Q3 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L (GR8: JE/RX90)
Q4 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L (GR8: JE/RX90)
Q5 8-729-424-08 TRANSISTOR MUN2111T1 (GR8: JE/RX90)
Q8 8-729-033-67 TRANSISTOR 2SK211-Y-TE85L (GR8: JE)
Q9 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6
(GR8: JE/RX90)
Q10 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6 (GR8: JE)
Q11 8-729-421-22 TRANSISTOR MUN2211T1 (RX90)
Q12 8-729-421-22 TRANSISTOR MUN2211T1 (GR8: JE/RX90)
Q13 8-729-421-22 TRANSISTOR MUN2211T1 (GR8: JE/RX90)
Q14 8-729-421-22 TRANSISTOR MUN2211T1 (GR8: JE/RX90)
Q1701 8-729-424-08 TRANSISTOR MUN2111T1 (RX90: EE, CIS)
Q1702 8-729-907-00 TRANSISTOR RT1N141M-TP-1 (RX90: EE, CIS)
Q1703 8-729-421-22 TRANSISTOR MUN2211T1 (RX90: EE, CIS)
< RESISTOR >
R1 1-249-401-11 CARBON 47 5% 1/4W
(GR8: JE/RX90)
R2 1-216-037-00 METAL CHIP 330 5% 1/10W
(GR8: JE/RX90)
R3 1-216-037-00 METAL CHIP 330 5% 1/10W
(GR8: JE/RX90)
R5 1-216-037-00 METAL CHIP 330 5% 1/10W
(GR8: JE/RX90)
R6 1-216-081-00 METAL CHIP 22K 5% 1/10W
(GR8: JE/RX90)
R7 1-216-037-00 METAL CHIP 330 5% 1/10W
(GR8: JE/RX90)
R8 1-216-037-00 METAL CHIP 330 5% 1/10W
(GR8: JE/RX90)
R9 1-216-081-00 METAL CHIP 22K 5% 1/10W
(GR8: JE/RX90)
R10 1-216-037-00 METAL CHIP 330 5% 1/10W
(GR8: JE/RX90)
R11 1-216-081-00 METAL CHIP 22K 5% 1/10W
(GR8: JE/RX90)
R12 1-216-037-00 METAL CHIP 330 5% 1/10W
(GR8: JE/RX90)
R13 1-216-037-00 METAL CHIP 330 5% 1/10W
(GR8: JE/RX90)
R14 1-216-081-00 METAL CHIP 22K 5% 1/10W
(GR8: JE/RX90)
R18 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
(GR8: JE)
R18 1-216-073-00 METAL CHIP 10K 5% 1/10W
(RX90)
R19 1-216-073-00 METAL CHIP 10K 5% 1/10W
(GR8: JE/RX90)
R21 1-216-049-00 METAL CHIP 1K 5% 1/10W
(GR8: JE/RX90: AEP, G, UK, AED)
