Sony HCD-GR8 - TRANS

– 123 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R1715 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
(RX90: EE, CIS)
R1716 1-216-097-91 METAL CHIP 100K 5% 1/10W
(RX90: EE, CIS)
R1717 1-216-097-91 METAL CHIP 100K 5% 1/10W
(RX90: EE, CIS)
R1718 1-249-429-11 CARBON 10K 5% 1/4W
(RX90: EE, CIS)
R1719 1-216-097-91 METAL CHIP 100K 5% 1/10W
(RX90: EE, CIS)
R1720 1-249-434-11 CARBON 27K 5% 1/4W
(RX90: EE, CIS)
R1721 1-216-073-00 METAL CHIP 10K 5% 1/10W
(RX90: EE, CIS)
R1751 1-247-807-31 CARBON 100K 5% 1/4W
(RX90: AEP, G, UK, AED)
R1752 1-216-073-00 METAL CHIP 10K 5% 1/10W
(RX90: AEP, G, UK, AED)
R1753 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
(RX90: AEP, G, UK, AED)
R1754 1-216-097-91 METAL CHIP 100K 5% 1/10W
(RX90: AEP, G, UK, AED)
R1755 1-216-097-91 METAL CHIP 100K 5% 1/10W
(RX90: AEP, G, UK, AED)
R1756 1-249-401-11 CARBON 47 5% 1/4W
(RX90: AEP, G, UK, AED)
R1757 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(RX90: AEP, G, UK, AED)
< VARIABLE RESISTOR >
RV41 1-238-601-11 ADJ, CARBON 22K (GR8: JE/RX90)
RV42 1-238-600-11 ADJ, CARBON 10K (GR8: JE/RX90)
RV1701 1-238-600-11 ADJ, CARBON 10K (RX90: EE, CIS)
RV1702 1-238-599-11 ADJ, CARBON 4.7K (RX90: EE, CIS)
< COIL >
T1 1-409-505-11 COIL (ANT. SW3) (GR8: JE)
T2 1-402-960-11 COIL (0SC. SW3) (GR8: JE)
< TERMINAL >
TM1 1-537-238-21 TERMINAL BOARD (ANT) (ANTENNA) (GR8: JE)
TM1 1-537-488-11 TERMINAL BOARD (ANT) (ANTENNA) (RX90)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz) (GR8: JE/RX90)
X41 1-760-220-11 FILTER, CERAMIC (10.7MHz) (GR8: JE/RX90)
X42 1-527-981-00 FILTER, CERAMIC (450kHz) (GR8: JE/RX90)
X43 1-577-075-11 OSCILLATOR, CERAMIC (456kHz)
(GR8: JE/RX90)
X1751 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)
(RX90: AEP, G, UK, AED)
**************************************************************
* 1-664-026-11 TRANS BOARD
************
< CONNECTOR >
* CN901 1-564-522-11 PLUG, CONNECTOR 7P
* CN902 1-564-518-11 PLUG, CONNECTOR 3P
CN903 1-564-321-00 PIN, CONNECTOR 2P
< FUSE >
! F901 1-532-203-00 FUSE, TIME-LAG (2A, 250V) (EXCEPT GR8: MX)
! F902 1-532-350-00 FUSE, TIME-LAG (4A, 250V)
(GR8: EA3, E, HK, IA, JE, MX, SP, TW)
< FUSE HOLDER >
FH901 1-533-223-11 HOLDER, FUSE (EXCEPT GR8: MX)
FH902 1-533-223-11 HOLDER, FUSE
(GR8: EA3, E, HK, IA, JE, MX, SP, TW)
FH951 1-533-223-11 HOLDER, FUSE (EXCEPT GR8: MX)
FH952 1-533-223-11 HOLDER, FUSE
(GR8: EA3, E, HK, IA, JE, MX, SP, TW)
< RESISTOR >
! R901 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R902 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R903 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R904 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
< SWITCH >
! S901 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (GR8: EA3, E, HK, IA, JE, SP, TW)
< TRANSFORMER >
! T901 1-429-994-11 TRANSFORMER, POWER
(RX90: AEP, AED, EE, CIS, G, UK)
! T901 1-429-995-11 TRANSFORMER, POWER
(GR8: E, EA4, HK, IA, MX, SAF, SP, TH, TW, AUS, JE)
! T901 1-429-995-21 TRANSFORMER, POWER (GR8: EA3, MY)
**************************************************************
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
TRANS
TCB
